This ec motors is published with the manufacturer’s full specification — power supply DC 9-36V, model number SZWL-IOTV001. Made by Chengdu Shangzhi Smart Iot Technology Co., Ltd. (3 years on the platform, typical reply ≤17h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of These Ec Motors
- Model Number: SZWL-IOTV001
- Power Supply: DC 9-36V
- Place Of Origin: Sichuan, China
- Application: Acquisition data transmission
- Supplier Type: customizable
- Interface Type: 1DI/2AI/1DO/1RS485/1RS232
Technical Specifications
| Chipset | esp-32 |
|---|---|
| Application | Acquisition data transmission |
| Place Of Origin | Sichuan, China |
| Model Number | SZWL-IOTV001 |
| Brand Name | shangzhi |
| Supplier Type | customizable |
| Power Supply | DC 9-36V |
| Interface Type | 1DI/2AI/1DO/1RS485/1RS232 |
| Size | 86*54*10 MM |
| Module Type | 4G CAT1 |
| MOQ | 1PCS |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Existing project customization services
New project customization service
Model | IOTV02 | |||
Name | Smart IoT data collection terminal | |||
Interface Type | RS232, RS485, switching quantity, analog quantity (other customized) | |||
Applicable Area | Global customized 4G network | |||
Maximum Working Current | <500mA | |||
Operating Voltage | DC 5-36V | |||
Basic Parameters | power supply | 5-36V Wide voltage power supply External DC power supply. | ||
Network module type | 4G CAT1 | |||
Temperature working range | -20℃ from +70℃ | |||
Working humidity range | 1% to 99% non condensing | |||
Waterproof and dustproof | IP54 (customizable higher waterproof rating) | |||
Appearance size | 82mm x 94mm x 23mm | |||
Network parameters | 4G cat1 (other customizable) | ：LTE-TDD:B34/B38/B39/B40/B41 LTE-FDD:B1/B3/B5/B8 | ||
hardware interface | 1 RS232 | standard RS232 interface | ||
1 RS485 | Standard RS485 interface | |||
1 relay output | Maximum controllable voltage 250V AC5A circuit (special values can be customized) | |||
2 Analog inputs | Supports 0-2.5V or 4-20mA | |||
1-channel switch input | Supports 5V to 28V DC switch input | |||
Network parameters | Frequency band | LTE-TDD:B34/B38/B39/B40/B41 LTE-FDD:B1/B3/B5/B8 | ||
data | LTE-TDD: Up and down ratio 2 Maximum 8Mbps (DL)/Maximum 2Mbps (UL) Upstream and downstream ratio 1 Maximum 6Mbps (DL)/Maximum 4Mbps (UL) LTE-FDD: Maximum 10Mbps (DL)/Maximum 5Mbps (UL)“ | |||
Transmission interface | network stack | TCP/UDP/PPP/FTP/HTTP/NITZ/CMUX/NDIS/NTP/ HTTPS/PING/FTPS/FILE/MQTT | ||
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–199 piece: US $35 / piece
- 200–499 piece: US $30 / piece
- 500–999 piece: US $25 / piece
- 1000+ piece: US $20 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this ec motors?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the ec motors be supplied for my local voltage?
The standard configuration is DC 9-36V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Chengdu Shangzhi Smart Iot Technology Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, Trading Company. Browse the full Chengdu Shangzhi Smart Iot Technology Co., Ltd. range on HVACR Nexus.
