This air handling unit is published with the manufacturer’s full specification — refrigerant Water, type Air Handling Unit. Made by Guangzhou Jetex -Lloyd`s Machinery Limited (1 year on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Air Handling Unit
- Model Number: JTAHM Series
- Refrigerant: Water
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
- Application: Cleanroom
- Type: Air Handling Unit
Technical Specifications
| Type | Air Handling Unit |
|---|---|
| Refrigerant | Water |
| Mounting Type | Floor Standing |
| Fan Motors Type | Brushless |
| Motor Type | Brushless Motor |
| Filter Type | High-Efficiency Particulate Air Filter, Regular Filter, Activated Carbon Filter |
| Application | Cleanroom |
| Key Selling Points | Eco-Friendly, Low Maintenance Cost, Accurate Temperature Control, High air speed and high air capacity |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 600 |
| Brand Name | Jetex |
| Model Number | JTAHM Series |
| Dimension(L*W*H) | customizable |
| Frame | Thermal break aluminum alloy frame with high-density sealing gasket |
| Casing Structure & Insulation | double-skin with Polyurethane foam insulation |
| Cooling/Heating Coil | High-quality copper tubes with blue-wave aluminum fins |
| Filters | G4 panel-type filters, F5~F9 bag-type,H11~14 filters,HEPA filter |
| Other Functions | customization is available based on customer requirements |
| Sterilization Devices | UV-C Germicidal Lamp,Plasma Air Sterilizer |
| Sterilization Components | HEPA / ULPA Filtration Section,Ozone Sterilization Module |
| Humidifier | Electrode Steam Humidifier,Dry Steam Humidifier |
| Humidifier Type | Wetted Media ,High-pressure Spray Humidifier |
| Heater | hot water,PTC heater,Electric Heater,Steam |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Product Description
Cleanroom Air Handling Unit with HEPA Filter | Pharmaceutical / Laboratory / Electronics AHU
Over the 30 years, Jetex has been committed to the research and development of air conditioning equipment for industrial and biological purification. Our AHUs offer a flexible range of air volumes, from 2600 m³/h to 400,000 m³/h, allowing customization for various needs.
JTAHM-series adopts the modular design,with an air volume range of 2,600 – 40,000 m³/h,the units can withstand a pressure of up to 2,500 Pa.This series of products have comprehensive air treatment functions,including cooling,dehumidification,heating,humidification,filtration,purification and sterilization.through flexible combinations of different functional sections ,they can meet diverse application requirements of users.
Design basis： 1.GB/T17758-2010 Unitary Air Conditioners 2.GB 50333-2021 – Architectural Technical Code for Clean Operating Department in Hospitals 3. GB 50591-2010 – Code for Construction and Acceptance of Clean rooms 4. GB/T19569-2004 – Air Conditioning Units for Clean Operating Rooms 5. GB/T25130 – Safety Requirements for Unitary Air Conditioners 6. GB/T7249 – Terminology of Refrigeration Equipment
Features: *Specially designed for clean operating rooms and other areas to solve the problem of high energy consumption of *constant temperature and humidity air handling unit. *The Circulating unit conducts temperature adjustment treatment, eliminating the need for a large amount of reheat, which significantly saves energy. *The air handling unit equipped with two or three stage filters to ensure clean air supply. *The air handling unit adopts modular flexible design with compact structure. *The air handling unit is suitable for on-site applications lacking heating/cooling sources or retrofit projects. *The system features modular design and smart centralized control, with proven multi-project application experience to ensure high-efficiency and stable operation of HVAC systems.
Applications
* Pharmaceutical cleanrooms
*Pharmaceutical cleanrooms
*Hospital operating rooms & ICU
*Laboratories and research centers
*Electronics & semiconductor factories
*Food & beverage clean production areas
*Biotechnology and medical device plants
* Pharmaceutical cleanrooms
*Pharmaceutical cleanrooms
*Hospital operating rooms & ICU
*Laboratories and research centers
*Electronics & semiconductor factories
*Food & beverage clean production areas
*Biotechnology and medical device plants
Pharmaceutical Cleanrooms
Hospitals
medical facilities
Specification
Company Profile
Guangzhou Jetex-Lloyd’s Machinery Ltd. is a professional manufacturer specializing in the R&D, production and engineering solutions of air handling equipment for over 30 years. With a 10,000+ m2 factory, advanced manufacturing facilities and an experienced technical team, we provide high-quality HVAC terminal products widely used in pharmaceutical plants, cleanrooms, laboratories, electronics, lithium battery production, commercial buildings, hotels and shopping malls.
We are also a long-term supplier of Foxconn for more than 20 years, serving multiple Fortune 500 companies and international partners.
Our Worldwide Successful Cases
Guangzhou NanFang Hospital
The Second People's Hospital of Shenzhen
Beijing You'an Hospital
RayBiotech Guangzhou Co., Ltd.
Yangzijiang Pharmaceutical Group
Livzon Group Pharmaceutical
Exhibition
Packing & Delivery
For Shipment: The unit is wrapped with anti-collision foam and film, or packed in a wooden case.
FAQ
Q1: Can you manufacture non-standard machine?
A1: Yes, our factory has 30 years of manufacturing experience. Just provide us with your technical parameters and our engineers will develop a solution.
Q2: How about the quality of your product?
A2: Our products are manufactured strictly according to national and international standards. We have ISO and CRAA certifications.Every product will be tested before shipment.
Q3: How to choose a suitable model?
A3: Please provide your specifications and building drawings. Our professional technical engineers will assist you in selecting the right solution.
A1: Yes, our factory has 30 years of manufacturing experience. Just provide us with your technical parameters and our engineers will develop a solution.
Q2: How about the quality of your product?
A2: Our products are manufactured strictly according to national and international standards. We have ISO and CRAA certifications.Every product will be tested before shipment.
Q3: How to choose a suitable model?
A3: Please provide your specifications and building drawings. Our professional technical engineers will assist you in selecting the right solution.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–4 set: US $4800 / set
- 5–9 set: US $4700 / set
- 10+ set: US $4500 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air handling unit?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangzhou Jetex -Lloyd`s Machinery Limited, based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Guangzhou Jetex -Lloyd`s Machinery Limited range on HVACR Nexus.
