Axial flow fan — 220V, blade material Cast Iron. The complete factory specification follows. Made by Zhejiang Larissa Mechanical Electric Technology Co., Ltd. (9 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Axial Flow Fan
- Model Number: YWF350
- Voltage: 220V
- Blade Material: Cast Iron
- Material: Steel
- Frame Material: Galvanised Steel
- Warranty: 1 Year
Technical Specifications
| Voltage | 220V |
|---|---|
| Blade Material | Cast Iron |
| Electric Current Type | AC |
| Mounting Type | Duct Fan |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Place Of Origin | Zhejiang, China |
| Brand Name | Larissa |
| Model Number | YWF350 |
| Product Name | 350mm 220V condenser fan axial flow fan with external rotor motor |
| Color | Black |
| Bearing Type | Ball |
| Frequency | 50 Hz |
| Size | 350mm |
| Material | Steel |
| Current | 0.7A |
| Noise | 64dB(A) |
| Application | Industrial Equipment |
| Frame Material | Galvanised Steel |
| Selling Units | Single item |
| Single Package Size | 42X42X30 cm |
| Single Gross Weight | 10.0 kg |
Product Details
1),YWF series axial fan motors are external rotor fan motors with the characteristics of compact structure,
convenient installation, reliable operation, low noise, energy saving and high efficiency.
2), AC Axial Fan YWF are divided into singlephrase asynchronous capacitor fan motor and threephrases
asynchronous fan motor which are widely used in condenser,
evaporator and other refrigeration equipment and ventiliating cycle areas.
3),The standard length of the electrical wire on the fan is 1.5m,
and we can also provide connection box to fan motors for clients' choices.
4),The applicable environment temperature of the fan motors used in condensers is from 0oC to +60oC,
and that of the fan motors used in evaporators is from -30oC to 0oC.
Advantages
1) Compact design for shorter axial dimension
2) Smooth start-up and operating, less noise
3) Less heat and long life
4) Extensive applications
Technical Parameters
| MODEL | Frequency | Voltage | Max . Current | Max. Powerinput | Speed | Capacitance | Noise | Air Flow |
| Hz | V | A | W | r/min | µ F | dBA | m³/h | |
| FZY4D-350 | 50 | 380 | 0.40 | 150 | 1450 | – | 64 | 2280 |
| FZY4E-350 | 50 | 220 | 0.70 | 150 | 1450 | 4 | 64 | 2230 |
| FZY6D-350 | 50 | 380 | 0.30 | 90 | 960 | – | 53 | 1520 |
| FZY6E-350 | 50 | 220 | 0.40 | 70 | 960 | 2 | 52 | 1500 |
 |  |
 |  |
· Customizing the fans according to customers' requirements.
· Delivery time for sample order: 1-5 days, for pallets order 7-20 days after receiving clear payment
· Warranty: 1 year for repairing or replacment of fans, customs duty & freight not included
Q: What is the MOQ?
R: 100 pieces, accept sample.
Q: When you ship my order
R: Normally continer need 25-40days, sample
Q: How about the quality guarantee period?
R: One year.
Q: Do you have the certificates?
R: Yes, we have passed the CE and CCC certifacation.
Q: Do you offer ODM & OEM service.
R: Yes, we can custom design for specific application.
Q: When can I get the quotation?
R:We usually quote within 24 hours after we get your inquiry. If you are urgent to get the price, please send the message on trade management or call us directly.
Q: How can I get a sample to check your quality?
R:After price confirmed, you can requiry for samples to check quality.
If you need the samples, we will charge for the sample cost. But the sample cost can be refundable when your quantity of first order is above the MOQ
Q: What is your main market?
R:Southeast Asia, South America,Middle East.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $29 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this axial flow fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the axial flow fan be supplied for my local voltage?
The standard configuration is 220V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Zhejiang Larissa Mechanical Electric Technology Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Zhejiang Larissa Mechanical Electric Technology Co., Ltd. range on HVACR Nexus.
