Fan Coil Unit, Ceiling, Ducted, Wall

Key specification for this fan coil unit: voltage AC 230 V, 220V/1P/50/60Hz. Everything below is reproduced from the factory data sheet. Made by Henan Abot Trading Co., Ltd. (8 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.

Key Features of This Fan Coil Unit

• Power Supply: 220V/1P/50/60Hz
• Voltage: AC 230 V
• Warranty: 3 Years
• Place Of Origin: Guangdong, China
• Feature: Easy Installation
• Type: Air Conditioning

Technical Specifications

Product Details

Product Description

Features for floor ceiling type fan coil unit:

1.3 or 4 rows coil are optional for whole series .

2. 2-Pipe and 4-Pipe are optional for whole series.
3. Ultra-thin with 200 mm thickness.
4. Floor standing/Horizontal/ Concealed type installation available (For floor standing : The footing is optional).
5. The wired controller(KJRP-86I/MFK-E or KJRP-86A/BMFNKD-E) can be installed inside the unit.
6. Floor standing unit with multi casing options can be installed quickly and easily in new or existing facilities in a variety of applications.
7. The AC Series comes with 3 fan speed option to meet the needs of different indoor conditions.
8. The Floor Standing Unit has three appearance options to meet different installation requirement, the H3 (concealed)
unit is designed to be concealed in wall while the H1 (front air intake) and H2 (underside air intake) offer a choice of air intake options.
9. The ceiling and floor unit offers exposed installation. The installation and maintenance is easy. The maintenance of the
machine is quite easy and the key components can be accessed from the bottom of the machine.
10. The unit is uniquely designed with the possibility to be installed beneath the ceiling or sitting on the floor to suit any
interior design requirements.

Features for 4-way cassette type fan coil:

1. 4-way air supply panel as standard, new 360°air supply panel is optional.

2. Built-in PCB and drain pump with pump head-750mm.
3. Remote controller with LED display is standard, wired controller is optional.
4. Safety grill for safety maintenance.
5. Optional extended drainage pan for protecting your ceiling better.
6. Compatible with 0-10V output function(customized).
7. Available for 2/4 pipe system.
8. Auxiliary electric heater (AEH) is optional (for 2-Pipe 4-Way Cassette).
9. 360° airflow for immediate, equal distribution of wider-angle cooling and heating, ideal for standard ceilings.

10. In the event of a sudden power failure during operation,unit restarts automatically and the unit will operate based on the previous setting (operating mode, temperature setting and fan speed).

11. The height of models 600 to 750 is just 230mm whilst models 850 to 1500 is 300mm, making the Four-way Cassette ideal for standard ceilings.

12. The Individual louver control can control the motors separately, making it possible to control all four louvers independently

Features for 1-way cassette type fan coil:

1. The central controllers can be connected through the customized Network Module MD-NIM01.

2. Remote on/off function can be applied to turn on/off the unit.
3. Wired controller KJR-75A is optional.
4. Compact design, ultra slim body with a minimum thickness of 153mm.

5. Standard built-in drain pump with 750mm pump head.
6. One way cassette has a compact size, it's suitable for applicaion in narrow space such as the aisle, small office, elevator space etc.
7. The AC Series comes with 3 fan speed option to meet the needs of different indoor conditions.
8. One direction air flow guarantees quick cooling, flexible installation positioning.
9. Compact design, ultra slim body with a minimum thickness of 153mm, especially suitable for narrow ceiling, such as in lobbies and small meeting rooms.
10. In the event of a sudden power failure during operation,unit restarts automatically and the unit will operate based on the previous setting (operating mode, temperature setting and fan speed).

Features for duct type fan coil:

1. 3 or 4 row for 2-pipe system and 3 row for 4-pipe system.

2. Versions for standard, A4 and large difference temperature type.

3. Washable filter: Iron frame filter is standard, and aluminum frame filter can be customized.

4. Compatible with two types of air return: Back return is standard ,bottom return is optional.

5. Left or right hand piping connections are easily change in filed.

6. AEH is optional (for 3-Row, 4-Row Duct).

7. All the units are 241mm hight，easy for limited space to installation.

8. The AC Series comes with 3 fan speed option to meet the needs of different indoor conditions.

9. Slim, compact design for limited space with duct distribution to the indoor space.

Features of wall mounted fan coil unit:

1.Display shut off (for Type A and P panels though Wireless Remote Controllers RM12F/BGF-E ).

2. Built-in 3-way electromagnetic valve.
3. Remote controller as standard, wired controller is optional.
4. Easy and low cost installation.
5. The panel can be easily removed, simple maintenance and easy to change filter.
6. Multi-directional outlet pipe feature: left/right/rear, to meet the needs of different rooms.
7. Compatible with 0-10V output function(Customized)
8. Auxiliary electric heater (AEH) is optional.
9. Stylish panel, ideal for rooms with no or narrow ceilings.
10. Indoor unit displays can be shut off at night, creating a better environment for rest.

11. The AC Series supplies 3 indoor fan speeds to meet the needs of different indoor conditions.

12. The Auto Swing Louver function ensures that the air direction corresponds to the mode selected.

13. Removable front panel making maintenance convenient.

14. The Wall Mounted can be installed against wall, no need ceilings, simplifying installation.

Contact Us

Ordering and Pricing

• Minimum order quantity: 10 set
• Volume pricing:
  • 10+ set: US $82 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this fan coil unit?

The standard minimum order quantity is 10 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.

Can the fan coil unit be supplied for my local voltage?

The standard configuration is AC 230 V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Henan Abot Trading Co., Ltd., based in China. The company 8 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Henan Abot Trading Co., Ltd. range on HVACR Nexus.
