This exhaust fan is published with the manufacturer’s full specification — 110V/ 220V, 220/380, 28000m3/h/36000m3/h/51020m3/h. Made by Shandong Fuma Agriculture And Technology Co., Ltd. (10 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Exhaust Fan
- Model Number: FMH-1000(36”), FMH-1380(50”)
- Power Source: Electric
- Input Power: 550W/750W/1100W
- Voltage: 110V/ 220V, 220/380
- Airflow: 28000m3/h/36000m3/h/51020m3/h
- Blade Material: Stainless Steel
Technical Specifications
| Voltage | 110V/ 220V, 220/380 |
|---|---|
| Type | exhaust fan |
| Blade Material | Stainless Steel |
| Mounting Type | Wall Fan |
| Bearing Type | Sleeve Bearing |
| Power Source | Electric |
| Warranty | 2 Years |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM |
| Place Of Origin | Shandong, China |
| Brand Name | FM |
| Model Number | FMH-1000(36”), FMH-1380(50”) |
| Product Name | Exhaust Fan |
| Material | Galvanized |
| Size | 1000*1000*1150MM/1100*1100*1150MM/1380*1380*1300MM |
| Blades Rotational Speed: | 438rpm/600rpm/439rpm |
| Motor Rotational Speed: | 1400rpm |
| Airflow | 28000m3/h/36000m3/h/51020m3/h |
| Total Pressure | 70pa/70pa/80pa |
| Noise Level | <64 |
| Input Power | 550W/750W/1100W |
| Frequency | 50HZ/60HZ |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Product Application:
Model | Drive | Blades Diameter(mm) | Blades Rotational Speed(rpm) | Motor Rotational Speed(rpm) | Air Flow (m³/h) | Input Power (W) | Noise (db) |
FM-1000 | Belt | 910(36in) | 500 | 1400 | 28000 | 550 | <64 |
FM-1380 | Belt | 1270(50in) | 458 | 1400 | 51020 | 1100 | <64 |
1.Using advanced front double door opening device,small wind resistance, good sealing, high efficiency
2.Lengthened cone design improves exhaust power.
Hot Galvanized sheet with zinc thickness of 275g/㎡, avoiding rust effectively.
Rubber sealing device is equipped for the double door close to avoid the air backflow. Greatly improved the running efficiency
compared with the same power fan.
1. Material : Krupp 430 stainless steel, thickness 1.2mm
2. Diameter: 1270mm, Large air flow, no deformation, no fracture, no dust, attractive and durable.
1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor
2. Motor Protection Grade: IP55
3. Isulation Class: F grade
A: We are manufacturer , we have our factory and design team
Q: Why your price more expensive than other China suppliers ?
A: Our material we use is much better than other suppliers
Q: Can you cheaper ?
A: We have many quality stage products for client choose , different stage price will be different , if you really want low price we will suggest you choose lower stage product , in our company , we don't have bad quality products , you can reassure about the quality .
Q:When can I get the price?
A:We usually quote in 24 hours after receiving your inquiry.
Ordering and Pricing
- Minimum order quantity: 1 square meter
- Volume pricing:
- 1+ square meter: US $168 / square meter
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this exhaust fan?
The standard minimum order quantity is 1 square meter. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the exhaust fan be supplied for my local voltage?
The standard configuration is 110V/ 220V, 220/380. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shandong Fuma Agriculture And Technology Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Shandong Fuma Agriculture And Technology Co., Ltd. range on HVACR Nexus.
