Air Source Heat Pump, 110V, 9kw

Air source heat pump — 110V/220V/380V, 9kw/15.2kw/16.3kw/30kw/60kw. The complete factory specification follows. Made by Luohe Xingdian Electromechanical Equipment Co., Ltd. (6 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Air Source Heat Pump

• Model Number: XD-9kw
• Power Source: Electric
• Voltage: 110V/220V/380V
• Heating Capacity: 9kw/15.2kw/16.3kw/30kw/60kw
• Housing Material: Plastic
• Refrigerant: R410

Technical Specifications

Product Details

Product Overview

New Energy Household Air Source Heat Pump Water Heater

Commercial air source heat pump .They are widely suitable for sanitary hot water at residential or commercial places.It can provide stable 55℃ hot water,max hot water temp up to 60℃ working good at -7℃~-30℃ above area

FEATURES AT A GLANCE

⭐ Features 1. Dual energy fast heating 2. Intelligent constant temperature 3. Separation of water and electricity 4. Automatic water supplement 5. Automatic locking 6. Efficient thermal insulation

1.Based on reverse Carnot cycle, the refrigerant in the evaporator absorbs a large amount of energy from the air, which is then compressed into high temperature and high pressure gas by the compressor and finally exchanging heat through the heat ex-changer, so as to provide house heating and hot water.

2.Another biggest attraction of air source heat pumps is that they do not produce carbon emissions when in operation, unlike a gas boiler. Instead, they use a small amount of electricity to run but their high efficiency makes them the far more environmentally friendly choice. The eco-friendly refrigerant is non-toxic, no smell or chlorine element, which would not damage the ozone layer and thus reduce the greenhouse effect.

3.Because the heating elements of electric water heaters are directly in contact with the water flow, once the equipment is aging or some errors occur, there may be leakage accidents. With air to water heat pumps, water and electricity are separated, without any hidden danger.

PRODUCT SPECIFICATIONS

Rated heat	9 (KW)
Heating input power	2.68
Rated input current	13(A)
Rated outlet water temperature	55(℃)
Maximum outlet water temperature	60(℃)
Water yield	240 (L/H)
Voltage	110V/220V/380V
Nozzle size/internal thread	DN25(mm)
Unit noise	≤ 55(dB (A))
Packaging host size	780 * 710 * 850(mm)
Weight	96kg

Details Images

Packing and shipping:

Company information:

Our services:

1) Highly inspecting equipments in every working procedure, quality comes first; Fast & Safe Delivery;
2) Assisting our clients for foundation construction of equipment;
3) Dispatching engineers to install and debug equipment;
4) Training the first-line operators on site;
5) Regularly visit clients to solve production problems;
6) Providing life-long maintenance service;
7)Providing technical exchanging;

FAQ:

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1+ set: US $1600 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air source heat pump?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the air source heat pump be supplied for my local voltage?

The standard configuration is 110V/220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Luohe Xingdian Electromechanical Equipment Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Luohe Xingdian Electromechanical Equipment Co., Ltd. range on HVACR Nexus.
