This air conditioner is published with the manufacturer’s full specification — type Refrigeration Compressor. Made by Shandong Archean Refrigeration Technology Co., Ltd. (5 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Air Conditioner
- Warranty: Unavailable
- Place Of Origin: Thailand
- Application: Refrigeration Parts
- Type: Refrigeration Compressor
- Marketing Type: Ordinary Product
- Single Package Size: 60X30X30 cm
Technical Specifications
| Application | Refrigeration Parts |
|---|---|
| Type | Refrigeration Compressor |
| Warranty | Unavailable |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Weight (Kg) | 16 |
| Place Of Origin | Thailand |
| Marketing Type | Ordinary Product |
| Selling Units | Single item |
| Single Package Size | 60X30X30 cm |
| Single Gross Weight | 20.000 kg |
Product Details
Model | Displ.(cm3/rev) | Cooling capacity | Power (W) | COP (W/W) | Capacitor | ||
W | Btu/h | ||||||
PH225X2C-4FT1 | 22.4 | 3890 | 13273 | 1205 | 3.23 | 35/370 | |
GMCC Compressor 220/240V 50Hz | ||||||||||||
Model | Displacement | Cooling Capacity | Power | Cop | Compressor | |||||||
Height | ||||||||||||
W | Btu/h | W | W/W | mm | ||||||||
PH300G2C-4KU1 | 29.8 | 5340 | 18220 | 1645 | 3.25 | 297 | ||||||
PH310G2C-4KU1 | 30.8 | 5515 | 18817 | 1695 | 3.25 | 310 | ||||||
PH340G2C-4KU1 | 33.7 | 6030 | 20575 | 1865 | 3.23 | 310 | ||||||
PH340G2C-4KU | 33.7 | 6050 | 20643 | 1805 | 3.35 | 310 | ||||||
PH360G2C-4KU1 | 36 | 6475 | 22093 | 2005 | 3.23 | 324 | ||||||
PH370G2CS-4KU1 | 37 | 6650 | 22690 | 2065 | 3.22 | 324 | ||||||
PH370G2C-4KU | 37 | 6660 | 22724 | 2020 | 3.3 | 324 | ||||||
PH400G2CS-4KU1 | 39.8 | 7100 | 24226 | 2255 | 3.15 | 354 | ||||||
PH400G2C-4KU | 39.8 | 7095 | 24209 | 2215 | 3.2 | 354 | ||||||
PH420G2CS-4KU1 | 42.3 | 7420 | 25318 | 2390 | 3.1 | 354 | ||||||
PH420G2C-4KU | 42.3 | 7555 | 25778 | 2365 | 3.2 | 354 | ||||||
PH440G2C-4KU | 43.5 | 7810 | 26648 | 2390 | 3.27 | 354 | ||||||
PH460X3CS-4MU1 | 45.9 | 8080 | 27569 | 2600 | 3.1 | 396.5 | ||||||
PH480X3CS-4MU1 | 47.9 | 8460 | 28866 | 2730 | 3.1 | 396.5 | ||||||
Model Name | Displ. (cm3/rev) | Capacity (±5%W) | Power (±5%W) | COP (±5%) | R22 Max (kg) | Wt. (kg) |
PH108X1CY-8BGD2 | 10.8 | 1820 | 595 | 3.06 | 0.7 | 10.7 |
PH120X1CY-8BGD2 | 12.2 | 2090 | 675 | 3.1 | 0.7 | 10.7 |
PH135X1C-8DZD2 | 13.6 | 2280 | 750 | 3.04 | 0.85 | 12 |
PH150X1C-8DZD2 | 14.8 | 2500 | 820 | 3.05 | 0.85 | 12 |
PH155X1C-8DZD2 | 15.4 | 2600 | 850 | 3.06 | 0.85 | 12 |
PH160X1C-8DZD2 | 16.1 | 2720 | 890 | 3.06 | 0.85 | 12 |
PH165X1C-8DZD2 | 16.5 | 2810 | 920 | 3.05 | 0.85 | 12 |
PH170X1C-8DZD2 | 17.1 | 2920 | 960 | 3.04 | 0.85 | 12 |
PH180X1C-8DZD2 | 17.8 | 3050 | 1025 | 2.98 | 0.85 | 12 |
PH195X2C-8FTC | 19.3 | 3330 | 1080 | 3.08 | 1.1 | 15.1 |
PH200X2C-8FTC | 20 | 3470 | 1135 | 3.06 | 1.1 | 15.1 |
PH215X2C-8FTC | 21.6 | 3750 | 1210 | 3.1 | 1.2 | 15.8 |
PH225X2C-8FTC | 22.4 | 3870 | 1250 | 3.1 | 1.2 | 15.8 |
PH230X2C-8FTC | 23.1 | 3990 | 1310 | 3.05 | 1.2 | 15.8 |
PH240X2C-8FTC | 23.9 | 4140 | 1355 | 3.06 | 1.2 | 15.8 |
PH260X2C-8FTC1 | 26.2 | 4600 | 1510 | 3.05 | 1.3 | 16.3 |
PH280X2C-8FTC1 | 28 | 4900 | 1570 | 3.12 | 1.3 | 17.1 |
PH290X2C-8FTC1 | 29 | 5110 | 1650 | 3.1 | 1.3 | 17.1 |
PH295X2C-8FTC1 | 29.4 | 5180 | 1670 | 3.1 | 1.3 | 17.1 |
PH295X2CS-8KUC1 | 29.4 | 5200 | 1700 | 3.06 | 1.8 | 17.7 |
PH310X2CS-8KUC1 | 30.8 | 5410 | 1815 | 2.98 | 1.8 | 17.7 |
PH330X2CS-8KUC3 | 32.8 | 5720 | 1920 | 2.98 | 1.8 | 17.7 |
PH340X2CS-8KUC1 | 33.8 | 5860 | 1890 | 3.1 | 1.8 | 18.1 |
PH340X3C-8KUC1 | 34.2 | 5950 | 1945 | 3.06 | 1.8 | 20.6 |
PH360X3C-8KUC1 | 35.7 | 6220 | 2040 | 3.05 | 1.8 | 20.6 |
PH400X3C-8KUC1 | 40.2 | 6920 | 2245 | 3.08 | 2.1 | 23.3 |
PH420X3C-8KUC1 | 42 | 7400 | 2370 | 3.12 | 2.1 | 23.3 |
PH440X3C-8KUC1 | 43.5 | 7650 | 2510 | 3.05 | 2.1 | 23.3 |
PH460X3C-8KUC1 | 45.9 | 8060 | 2600 | 3.1 | 2.45 | 25.2 |
PH480X3C-8KUC1 | 47.9 | 8460 | 2730 | 3.1 | 2.45 | 25.2 |
the world and have been well received. The company has accumulated strong experience in the compressor market, rich technical
support, and a satisfactory one-stop procurement solution. You can rest assured You don't need to worry about this series, from placing an order to receiving the goods. We provide a complete solution to serve customers well, which is our purpose of
hospitality.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $50 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air conditioner?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a Unavailable warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shandong Archean Refrigeration Technology Co., Ltd., based in China. The company 5 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Shandong Archean Refrigeration Technology Co., Ltd. range on HVACR Nexus.
