Air Source Heat Pump, Inverter, 35c, 10kw, 20kw

Air source heat pump — 220V, 13KW. The complete factory specification follows. Made by Guangzhou Yoomi Swimming Pool Equipment Co., Ltd. (3 years on the platform, typical reply ≤2h). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Air Source Heat Pump

• Model Number: YMIV30D
• Voltage: 220V
• Heating Capacity: 13KW
• Housing Material: Galvanized Sheet
• Refrigerant: R32/R410A
• Place Of Origin: Guangdong, China

Technical Specifications

Product Details

What is DC Inverter Air to Water Heat Pump?

The frequency conversion technology is an emerging technology in the heat pump industry. The inverter heat pump is a technology that changes the frequency of the power supply through the frequency converter, thereby changing the operating speed of the compressor. The core of frequency conversion technology is the frequency converter, which realizes automatic adjustment of the motor operating speed by converting the power supply frequency.

Why Choose YOOMI Inverter Heat Pump?

1. High Energy Efficiency

The DC inverter heat pump is 30% more efficient than the ordinary fixed speed heat pump

2. Comfort

The characteristic of the DC inverter heat pump is that the compressor speed can be adjusted according to the temperature (load) of the swimming pool to achieve a constant temperature state of the swimming pool

3. Safety

The DC inverter heat pump avoids direct contact between the electric heating element and water through medium heat exchange, thus solving the leakage risk of electric heating. Secondly, because the raw material is air, it also eliminates the possibility of gas explosion or gas poisoning in gas water heaters, making people use it more comfortable and worry-free.

4. Environmental Protection

The DC inverter heat pump uses air to transfer heat energy and does not emit exhaust gas and toxic gases. It is not only safe, but also creates a pollution-free living environment.

5. Low Noise

No noise fan motor, super quite heat pump with centrifugal fan, noise less than 40dB.

6. Intelligent Controller Intelligent controller with LCD display control panel. Intellectual control over water pump, water supplement, water discharge and defrosting system. 7. Automatic Defrosting Automatic defrosting function included (with reverse valve inside)

Model

Speed

YMIV30D

YMIV50D

40℃/-10-15℃

50℃/-10-15℃

60℃/-10-15℃

40℃/-10-15℃

50℃/-10-15℃

60℃/-10-15℃

Heating Capacity (KW)

30rps

3~7

2.5~6.2

1.8~5.5

3.9~10

3.3~8.9

2.8~7.6

Input Power (KW)

1.08~1

1.25~1.35

1.45~1.7

1.35~1.32

1.6~1.8

1.9~2.2

Current(A

8.5~8.3

9.8~10.5

11.2~13

10.6~9.48

12.4~12.56

14.1~16

COP

2.9~7.5

2.9~7.5

1.45~3.5

2.9~7.5

2.1~5.0

1.45~3.5

Heating Capacity (KW)

60rps

6~15

5~13

4.5~11.5

8.2~21

7~18.7

5.8~16.1

Input Power (KW)

2.2~2.0

2.3~2.9

3.0~3.5

2.89~2.95

3.5~3.8

4.1~4.7

Current(A

9~8.5

10.5~11

12.1~14

11.4~10.4

13.2~14

15.8~17.5

COP

2.84~7.5

2.1~5

1.5~3.5

2.84~7.5

2.1~5

1.5~3.5

Heating Capacity(KW)

90rps

10~23

8~21

7~18

12.9~33.2

11~29.3

9.2~25.2

Input Power(KW)

3.5~3.4

4.2~4.6

5.0~5.9

4.83~4.74

5.74~6.3

6.7~7.8

Current(A

11~10

12.5~13.5

14.8~17.2

14.1~13.3

16.9~17.6

20.2~22.3

COP

2.7~7

2.0~4.6

1.5~3.2

2.7~7

2.0~4.6

1.5~3.2

Voltage

110V-460V/0-60HZ

Water Flow

3m3/h

5m3/h

Refrigerant

R410/R32

Protection Level

IPX4

Heat Exchanger

Hydrophilic thread aluminum sheet

Condenser

High-efficiency internal thread

Size

1120*490*1260mm

Weight

100KGS

152KGS

Noise

≤45dB

≤55dB

Pipe Size

DN25

YOOMI Factory

Guangzhou Yoomi Swimming Pool Equipment CO.,LTD is in Guangdong provice, our factory is located in Shishan industrial zone, Nanhai District, Foshan city, which covers an area of 15,000 square meters. Our products had sold to more than 100 countries such as the United Arab Emirates, Saudi Arabia, Canada, America, Mexico, New Zealand, Mauritius, Malaysia, Singapore, Vietnam, Philippines, South Korea ect.

Customer Feedback

1.YOOMI DC inveter heat pump can sure delivery heat pump within 15~25 working days as we have spare parts in warehouse stock.
2.DC inverter Heat pump with strong plywood pallet , strong plywood box for loading, make sure no problem happen during rude
transporattion .
3. All spare parts of the DC inverter heat pump will package together, one time finished shipment to buyer.
4. Take video of the DC inverter heat pump for buyer before package to 100% sure buyer get product same as order.
5.YOOMI DC inverter heat pump will test for more than 10 times to ensure all function can work normal before shipment.

Certification

FAQ

Q1: Are you a manufacturer?

A1: Yes, YOOMI with experienced and improved R&D, production, sales and service supplying.

Q2: Can you provide a sample?

A2: Yes, sample order is acceptable.

Q3: How long is your Heat Pump delivery time?

A3: It is 1-7 working days if the goods are in stock. if the goods are not in stock, Generally 15-25 working days, it is according to quantity.

Q4: How long is the quality guarantee period?

A4: Our quality guarantee period is 12 months.

Q5: Can you send products to my country?

A5: Sure, we can. If you do not have your own ship forwarder, we can help you.

Q6: What's your payment terms ?

A6: 50% deposit in advance, balance 50% before shipment.

Q7: When can I get the quotation ?

A7: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.

Ordering and Pricing

• Minimum order quantity: 1 set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air source heat pump?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

Can the air source heat pump be supplied for my local voltage?

The standard configuration is 220V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
