Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - view 3
Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - view 4
Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - view 5
Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - view 6

ModelKYDBL4850-1E

Bldc Motor, Brushless, 1kW, 1.5kW, 3kW

$139.00

Bldc Motor. Key specification: 48V, model number KYDBL4850-1E. Ships factory-direct with the manufacturer’s data sheet.

Rated Voltage
48V
Warranty
1 year
Model Number
KYDBL4850-1E
Place Of Origin
Shandong, China
  • Reply within one working day
  • Factory-direct pricing, OEM & ODM accepted
  • Full specification and test reports supplied

Get Factory Pricing

Price, MOQ and lead time direct from the manufacturer. Free, no account needed.

Enquiring about Bldc Motor, Brushless, 1kW, 1.5kW, 3kW

Bldc motor — 48V, model number KYDBL4850-1E. The complete factory specification follows. Made by Jinan Keya Electron Science And Technology Co., Ltd. (19 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Bldc Motor

  • Model Number: KYDBL4850-1E
  • Output Power: 1000W
  • Rated Voltage: 48V
  • Voltage: 48 V
  • Voltage Output: DC 10-55V
  • Warranty: 1 year

Technical Specifications

Rated Voltage 48V
Output Power 1000W
Voltage 48 V
Protection Class (IP) IP20
Maximum Current 50A
Warranty 1 year
Controller Model KYDBL4850-1E
Model Number KYDBL4850-1E
Brand Name KEYA
Place Of Origin Shandong, China
Dimensions 211*115*45mm
Rated Current 30A
Voltage Output DC 10-55V
Feedback Incremental Encoder, Hall feedback
Working Mode speed, torque, position
Control Method RS232;CAN2.0;RC;0-5V;PWM
Working Tempeture -25℃-+55℃
Protective Requirement dust, moisture and salt spray
Over Current Time 500ms
Cooling Method natural cooling
Selling Units Single item
Single Package Size 20X15X10 cm
Single Gross Weight 1.56 kg

Product Details

Product Description
Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 1Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 2
Specification

Single Channel BLDC Motor Drivers Series

Model

KYDBL4850-1E

KYDBL4875-1E

KYDBL48150-1E

Parameters

Operating Voltage

DC 24/48V

Ultimate Supply Voltage

DC 1055V

Adaptable Motor Power

Below 1000W

Below 1500W

Below 3000W

Rated Current

30A

40A

80A

Instantaneous Max.Current

50A

75A

150A

Over current Time

500mS

Signal Feedback

Incremental encoder ,Hall feedback

Working Mode

Speed Mode,Torque Mode,Position Mode

Cooling Method

Natural Cooling

Control Method

RS232;CAN2.0;RC;0-5V;PWM

Operating Temp.

-25℃-+55℃

Storage Temp.

-35℃-+65℃

Insulating Properties

The output and input are insulated to DC600V from the chassis, leakage current is 0.07mA, insulation resistance is above 20MΩ.

Protective Properties

Dust-proof, Moisture-proof, Salt Spray-proof

Protective Function

Over current delay/Over voltage/Under voltage/Over heated/Short-circuit

Controllable Speed Range

0-6000RPM

Protection Level

IP20

Dimension

211*115*45mm

147*117*75mm

210*140*75mm

Weight

0.56kg

1.05kg

2.4kg

Wiring Harness Standard

1M



Selling Point



1.Rated Voltage: DC24-96V
2. Rated current: 10-500A
3. SVPWM space vector control (effectively reducing power loss and improving power transmission efficiency.)
4. Adopt high-performance DSP and intelligent PID motion control algorithm (fast system response and hign control accuracy).
5. National patent of dual-channel scynchronization technology (ZL2021 0928503.5), making control more convenient.
6. Supporting multiple encoder feedback methods eg incremental encoder, absolute encoder, magnetic encoder.
7. Mutiple control methods: CAN2.0, CANopen, RC, RS232, RS485, Pulse, 0-5V
8. Discount on buying servo motors/reducers
Company Introduction

Jinan Keya Electronic Co., Ltd. has been committed to the trade, research&development, manufacturing, and sales of electric drives and automatic control systems. With a versatile range of production equipment and a swift, flexible service system, we are devoted to offering our customers innovative solutions with superior quality. Our team of skilled professionals and continuous pursuit of advancements ensure our commitment to providing responsive and comprehensive services.

Our company specializes in the following product categories:

1. Alternating and direct current servo control systems, PWM brush DC motor variable speed series, controllable silicon DC motor variable speed series, and brushless DC motor variable speed products. The PWM series has achieved European CE certification.
2. ZYT series DC motors, SZ series DC motors, DC series motors, J-ZYT(SZ)-PX series DC speed-lowering motors, and NMRV series DC speed-lowering motors.

Our products are widely adopted in various fields, such as mechanical equipment, testing machines, digital-controlled machine tools, medical instruments, laboratory equipment, packaging and printing mechanisms, textile machinery, plastic machinery, food machinery, cable equipment, welding equipment, and electric vehicles. Our products are recognized for their superior performance, remarkable features, reliability, and comprehensive functions, gained from the extensive experience of our R&D team.

Our company adheres to the guiding ideology of "survival by quality, creation by science and technology" and operates under the principles of honesty, precision, and pragmatism. By continuously focusing on the development and manufacturing of new products, we strive to create the best solution for our clients with a strong emphasis on customer orientation.

Our primary tenet is to prioritize "reputation above all" and prioritize our customers' needs. They are the cornerstone of our success. We welcome the opportunity to establish close, cooperative relationships with our global customers and to join hands with you in creating a bright and thriving future. Let us work together for a prosperous tomorrow.

Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 3Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 4Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 5Bldc Motor, Brushless, 1kW, 1.5kW, 3kW - detail 6

FAQ

1. who are we?
We are based in Shandong, China, start from 2003,sell to Domestic Market(80.00%),Eastern Europe(5.00%),North America(2.00%),Oceania(2.00%),Western Europe(2.00%),Southern Europe(2.00%),Northern Europe(2.00%),South America(1.00%),Eastern Asia(1.00%),Central America(1.00%),Mid East(1.00%),Southeast Asia(1.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
DC Servo Motor, Auto Steering Motor, DC Servo Controller

4. why should you buy from us not from other suppliers?
In-House R&D Team
15+ engineers specializing in dc servo motor with 20+ years of OEM/ODM experience.
Capable of customizing technical solutions within 72 hours (e.g., voltage/frequency adjustments, housing redesign).
Hold 8 patents and pass CE, RoHS,

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency: USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken: English,Chinese



Contact

 Hans

WhatsApp 0086-15106990389

Ordering and Pricing

  • Minimum order quantity: 2 piece
  • Volume pricing:
    • 2–9 piece: US $159 / piece
    • 10–99 piece: US $149 / piece
    • 100+ piece: US $139 / piece
  • Ships from: China
  • Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this bldc motor?

The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 year warranty. Spare parts and technical support remain available after the warranty period.

Can the bldc motor be supplied for my local voltage?

The standard configuration is 48V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Jinan Keya Electron Science And Technology Co., Ltd., based in China. The company 19 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Jinan Keya Electron Science And Technology Co., Ltd. range on HVACR Nexus.

Rated Voltage

48V

Output Power

1000W

Voltage

48 V

Protection Class (IP)

IP20

Maximum Current

50A

Warranty

1 year

Controller Model

KYDBL4850-1E

Model Number

KYDBL4850-1E

Brand Name

KEYA

Place Of Origin

Shandong, China

Dimensions

211*115*45mm

Rated Current

30A

Voltage Output

DC 10-55V

Feedback

Incremental Encoder, Hall feedback

Working Mode

speed, torque, position

Control Method

RS232;CAN2.0;RC;0-5V;PWM

Working Tempeture

-25℃-+55℃

Protective Requirement

dust, moisture and salt spray

Over Current Time

500ms

Cooling Method

natural cooling

Selling Units

Single item

Single Package Size

20X15X10 cm

Single Gross Weight

1.56 kg
