Key specification for this dc brushless motors: 24V, type Brushless Motor. Everything below is reproduced from the factory data sheet. Made by Changzhou Sunlight Electrical Appliance Co., Ltd. (11 years on the platform, typical reply ≤7h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of These Dc Brushless Motors
- Model Number: Brushless dc motor
- Rated Power: 27W
- Rated Output Power: 26W
- Voltage: 24V
- Speed(RPM): 4000±10% rpm
- No Load Speed: 5000rpm
Technical Specifications
| Commutation | Brushless |
|---|---|
| Rated Power | 27W |
| Speed(RPM) | 4000±10% rpm |
| Efficiency | IE3 |
| Type | Brushless Motor |
| Construction | Permanent Magnet |
| Frame | 42 mm(1.65in) |
| Motor Mounting Type | Flange Mount |
| Protect Feature | Totally Enclosed |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance, Other |
| Warranty | 3 months ~ 1 year |
| Continuous Current(A) | 1.65A |
| Model Number | Brushless dc motor |
| Torque | 0.063N.m(0.05lb.ft) |
| Place Of Origin | Jiangsu, China |
| Brand Name | SLT |
| Name | Brushless dc motor |
| Voltage | 24V |
| Poles | 4 |
| No Load Speed | 5000rpm |
| Rated Torque | 0.063N.m |
| Rated Speed | 4000 rpm |
| Rated Output Power | 26W |
| Rated Current | 1.65A |
| Insulation Class | B |
| Application | robot or home appliance |
| Selling Units | Single item |
| Single Package Size | 30X20X15 cm |
| Single Gross Weight | 0.5 kg |
Product Details
Our principle: Quality is our life, technical is the basic, be honest and faithful to our partners. At the same time, we pay more attention on team work and improving the staff skills.Customer requirements and the innovation of technology as our guide, try to be the market leader of Motor business.
A:Please specify the specs of the motor fan,such as diameter size,voltage,power and no-load speed of the required motor.
2.Q:Could I take samples to test quality and market in advance?
A:Yes, welcome to take samples to test our quality and service.
3.Q:What's the total cost for samples?
A:Total sample cost= sample cost + freight
We will give u the best shipping cost after knowing your requirements .
4.Q:How do you ship samples?
A:Considering sample quantity is not big, we support ship samples by DHL,UPS,TNT or Fedex , fast and less damages.
5.Q:What's your minimum order quantity?
A:10sets, one or two samples are ok .
6.Q:Could I use my own forwarder?
A:Yes
7.Q:I am new to international business,could you find an experienced forwarder to organize shipment for us?
A:Yes, we will assist and guild you to work out the shipping and import process.
8.Q:Is the sample same with formal orders?
A:Yes, sample's specification, performance, quality are totally same with formal orders.
9.Q:What's your delivery time?
A:For samples: within 7days; For orders: within 25days.
Ordering and Pricing
- Minimum order quantity: 5 piece
- Volume pricing:
- 5–99 piece: US $15.2 / piece
- 100–999 piece: US $12.43 / piece
- 1000+ piece: US $11.58 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this dc brushless motors?
The standard minimum order quantity is 5 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 months ~ 1 year warranty. Spare parts and technical support remain available after the warranty period.
Can the dc brushless motors be supplied for my local voltage?
The standard configuration is 24V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Changzhou Sunlight Electrical Appliance Co., Ltd., based in China. The company 11 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Changzhou Sunlight Electrical Appliance Co., Ltd. range on HVACR Nexus.
