This electric compressor is published with the manufacturer’s full specification — model number EC112. Made by Suzhou Ranlly Motor Co., Ltd. (1 year on the platform, typical reply ≤13h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Electric Compressor
- Model Number: EC112
- Rated Power: 50W-20000W
- AC Voltage: 24V-800V
- Rated Speed: 3200rpm-6000rpm
- Warranty: 2 Years
- Place Of Origin: Jiangsu, China
Technical Specifications
| AC Voltage | 24V-800V |
|---|---|
| Rated Power | 50W-20000W |
| Rated Speed | 3200rpm-6000rpm |
| Frame | No Frame |
| Motor Mounting Type | Built-in |
| Warranty | 2 Years |
| Model Number | EC112 |
| Brand Name | Ranlly |
| Place Of Origin | Jiangsu, China |
| Rated Current | 6A-32A |
| Stator Outer Diameter | 112mm |
| Stator Stacking Height | 25mm-38mm |
| Insulation Grade | E |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Please feel free to contact us for more details and requirements.
Model | EC112-110 | EC112-450 |
Rated Voltage | 110V | 450V |
Rated Speed | 5000rpm | 4000rpm |
Rated Current | 16.5A | 9.3A |
Stator Outer Diameter | 112mm | 112mm |
Rated Torque | 3.5Nm | 4.3Nm |
Efficiency | 91% | 91% |
Stator Stack Height | 25mm | 38mm |
Rated Power | 1.8kw | 1.8Kw |
Insulation Class | E | E |
Suzhou Ranlly Motor Co., Ltd.
Manufacturing equipment
Ordering and Pricing
- Minimum order quantity: 100 set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this electric compressor?
The standard minimum order quantity is 100 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the electric compressor be supplied for my local voltage?
The standard configuration is 24V-800V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Suzhou Ranlly Motor Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Suzhou Ranlly Motor Co., Ltd. range on HVACR Nexus.
