The fan coil unit listed here carries 110V/220V/380/415V, 257.23kw, documented exactly as the manufacturer publishes it. Made by Jiangsu Gmusem Ventilation System Manufacture Co., Ltd. (3 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Fan Coil Unit
- Voltage: 110V/220V/380/415V
- Heating Capacity: 257.23kw
- Cooling Capacity: 156.66kw
- Maximum Airflow: 16000CMH
- Airflow: 1000-25000CBM(optional)
- Material Thickness: 1mm
Technical Specifications
| Type | ceiling ventilator |
|---|---|
| Application | Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Home Office, Bathroom, Kitchen, Courtyard, Farmhouse, Park, Other |
| Voltage | 110V/220V/380/415V |
| Refrigerant Type | WATER |
| Heating Capacity | 257.23kw |
| Maximum Airflow | 16000CMH |
| Temperature Control Range | 80-130f |
| Material Thickness | 1mm |
| Feature | Flexible, Easy Installation |
| Warranty | 1 Year |
| After-Sale Service | Online Technical Support |
| Design Style | Contemporary |
| Project Solution Capability | total solution for projects |
| Place Of Origin | Jiangsu, China |
| Cooling Capacity | 156.66kw |
| Brand Name | GMUSEM |
| Applicable Industries | Garment Shops Building Material Shops Manufacturing Plant Machinery |
| Airflow | 1000-25000CBM(optional) |
| Motor | AC/DC/EC optional |
| Selling Units | Single item |
| Single Package Size | 98X65X24 cm |
| Single Gross Weight | 31.0 kg |
Product Details
FAN COIL UNITS
cool or heat the air recirculating within a room. Some will also add fresh air to the space.
The units are quite common and can be found in most commercial or residential applications.
Typically, to operate in cooling mode, the fan will blow air across the chilled water coil that is fed from the building central
system, with the cooled conditioned air flowing back into the room, cooling the space.
Typically, to operate in heating mode, the fan will blow air across the heating coil that is fed from the building central system,
with the heated conditioned air flowing back into the room, heating the space.
The heating coil could also be an electric type.
·Heating/Cooling Coil: Core element for temperature regulation.
·Fan: Circulates air over the coil.
Operation:
Fan coils work by drawing in ambient air, passing it over the coil (either heated or cooled by the larger HVAC system), and
redistributing the conditioned air back
into the room. They can be standalone systems or connected to a central plant.
Wet-film humidifier |
1.Working principle of wet-film humidifier The working principle of the wet film direct drainage and humidification system:the clean tap water passing through the solenoid valve is sent to the water distributor on the top of the wet film through the water supply pipeline,and the water flows down along the surface of the wet film under the action of gravity,thereby moistening the surface of the wet film and flowing to the connection The water in the water pan is discharged into the sewer pipe through the drainage elbow,that is,the water is not recycled. |
2.Operating conditions of wet-film humidifier Ambient temperature:the main body of the wet film is 5~100℃,the electric control box is 5~50℃.below 90%RH. Critical fan speed:3.75m/s or less. Water supply quality:tap water or the same type of water. Water supply temperature:5~40℃. Water supply pressure:0.15~0.75MPa. |
3.Features of wet film humidifier There is no"white powder"phenomenon in the humidification and cooling of clean humidification and humid film. The humidification section is short and the vaporization space of the wet film humidification and cooling system is only the thickness of the wet film body. High saturation efficiency-the saturation efficiency of the wet film humidification and cooling system can be as high as 90%or more. Safe and reliable. |
Ordering and Pricing
- Minimum order quantity: 1 box
- Volume pricing:
- 1–9 box: US $370 / box
- 10–49 box: US $351 / box
- 50+ box: US $309 / box
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this fan coil unit?
The standard minimum order quantity is 1 box. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the fan coil unit be supplied for my local voltage?
The standard configuration is 110V/220V/380/415V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Jiangsu Gmusem Ventilation System Manufacture Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Jiangsu Gmusem Ventilation System Manufacture Co., Ltd. range on HVACR Nexus.
