The heat air conditioner listed here carries capacity 9000-24000, power type AC, documented exactly as the manufacturer publishes it. Made by Moyu Technology Co., Ltd. Zhuhai (6 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Heat Air Conditioner
- Model Number: MYSS-09HR32-MW
- Power Type: AC
- Power Source: Electric
- Power (W): 2068
- Capacity (Btu): 9000-24000
- Cooling Capacity: 2.2-7.1kw
Technical Specifications
| Application | Hotel, Car, Garage, RV, Commercial, Household |
|---|---|
| Capacity (Btu) | 9000-24000 |
| Cooling/Heating | Cooling/Heating |
| Fixed Frequency/Variable Frequency | Variable Frequency |
| Recommended Room Size（Square Feet） | 500 |
| Eer | 4.1-6 |
| Feature | self diagnosis |
| Warranty | 5 year |
| After-Sales Service Provided | Free Spare Parts, Return and Replacement |
| Power Type | AC |
| App-Controlled | Yes |
| Remote Control | Yes |
| Timer | Yes |
| Private Mold | No |
| Power Source | Electric |
| Place Of Origin | Guangdong, China |
| Brand Name | Gree |
| Maximum Airflow Rate | 1200㎡/h |
| Power (W) | 2068 |
| Model Number | MYSS-09HR32-MW |
| Product Name | wall type split air conditioner |
| Refrigerant | R410a |
| Cooling Capacity | 2.2-7.1kw |
| Heating Capacity | 2.5-7.5kw |
| NOISE LEVEL | 35 DB |
| Function | CoolingHeating |
| Use | Room |
| Condition | New |
| Certification | ce |
| Selling Units | Single item |
Product Details
MODEL | GWH09QB-K3DNB6B | GWH12QC-K3DNB6B | GWH18QD-K3DNB6B | GWH24QE-K3DNB6B |
Function | Cooling/Heating | Cooling/Heating | Cooling/Heating | Cooling/Heating |
Capacity-Cooling/BTU | 9000 | 12000 | 17981 | 22000 |
Capacity-Heating/BTU | 9600 | 13000 | 19005 | 23000 |
EER | 3.21 | 3.21 | 3.21 | 3.21 |
Power Supply | 1PH,220-240V,50HZ | 1PH,220-240V,50HZ | 1PH,220-240V,50HZ | 1PH,220-240V,50HZ |
Power Input-Cooling/W | 825 | 1090 | 1640 | 2010 |
Power Input-Heating/W | 775 | 1050 | 1540 | 1870 |
Rated Current-Cooling/A | 6.3 | 6.9 | 13.5 | 11 |
Rated Current-Heating/A | 6.9 | 7.3 | 13.8 | 12 |
Airflow Volume-Indoor | 560/490/430/330 | 600/540/460/330 | 850/800/700/570 | 1100/1000/950/850 |
Sound Pressure Level-Indoor | 39/36/32/25 | 41/37/33/29 | 47/43/39/35 | 46/44/40/36 |
Outline Dimension-W*H*D/mm | 790*275*200 | 845*289*209 | 970*300*224 | 1078*325*246 |
Package Dimension-W*H*D/mm | 866*357*271 | 921*379*281 | 948*645*420 | 1029*750*458 |
Net Weight/Gross Weight-Indoor/kg | 9/11 | 11/13 | 13.5/16.5 | 16/19.5 |
Sound Pressure Level-Outdoor | 49 | 51 | 55 | 56 |
Piping Connection-Gas/mm | φ9.52 | φ9.52 | φ12 | φ16 |
Piping Connection-Liquid/mm | φ6 | φ6 | φ6 | φ6 |
Outline Dimension-W*H*D/mm | 710*550*318 | 710*550*318 | 899*596*378 | 955*700*396 |
Package Dimension-W*H*D/mm | 774*607*351 | 774*607*351 | 948*645*420 | 1029*750*458 |
Net Weight/Gross Weight-Outdoor/kg | 28/30 | 30/32 | 41/44.5 | 46/50.5 |
Loading Quantity-40'GP/sets | 234 | 225 | 156 | 118 |
Loading Quantity-40'HQ/sets | 270 | 261 | 179 | 131 |
Ordering and Pricing
- Minimum order quantity: 2 unit
- Volume pricing:
- 2–9 unit: US $245 / unit
- 10–49 unit: US $240 / unit
- 50+ unit: US $230 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this heat air conditioner?
The standard minimum order quantity is 2 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 5 year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this heat air conditioner carry?
It is supplied with ce documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Moyu Technology Co., Ltd. Zhuhai, based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Moyu Technology Co., Ltd. Zhuhai range on HVACR Nexus.
