Key specification for this water heater: 220V~50Hz, 24000w. Everything below is reproduced from the factory data sheet. Made by Guangxi Yangzi Energy saving Technology Co., Ltd. (2 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Water Heater
- Model Number: YZDLR-45GXSBP
- Power Source: Electric
- Power Supply Specification: 220V~50Hz
- Heating Capacity: 24000w
- Housing Material: Stainless Steel
- Refrigerant: R410A
Technical Specifications
| Type | Air Source Heat Pump |
|---|---|
| Heating Capacity | 24000w |
| Energy Efficiency Rating | Class I/IPX4 |
| Application | Commercial |
| Refrigerant | R410A |
| Storage / Tankless | Instant / Tankless |
| Compressor | other |
| Installation | Freestanding |
| App-Controlled | Yes |
| Housing Material | Stainless Steel |
| Feature | Eco-Friendly, Easy Installation, Easy Operation, Energy-Saving |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Operating Language | English |
| Private Mold | Yes |
| Packaging Types | Corrugated Box |
| Place Of Origin | Guangxi, China |
| Brand | Yangzi |
| Model Number | YZDLR-45GXSBP |
| Power Supply Specification | 220V~50Hz |
| Inlet And Outlet Pipe Size | G1(nternal thread)/DN25 |
| Waterproof Class | IPX4 |
| Electric Shock Protection Type | Class 1 |
| Logo/Pattern | Silk screen printing, Laser Printing |
| Function | Water heating and cooling |
| Selling Units | Single item |
| Single Package Size | 120X200X180 cm |
| Single Gross Weight | 50.0 kg |
Product Details
Products Description
5G iot intelligent control technology Make an appointment in advance, and enjoy customized warmth at home. Remotely monitor product operation in real time through WiFi Full DC frequency conversion technology Well-known brand EVI DC speed regulating compressor, improve compressor efficiency, high frequency and high efficiency heating, low frequency energy saving Ultra-low temperature jet enthalpy increasing technology Increase the refrigerant flow in the condenser, increase the enthalpy difference of the main circulation loop to increase the heat production and reduce the vortex temperature to ensure the safe operation of minus 40 degrees Super wide ring temperature, easy to cope with cold and heat Operating temperature range :-40°~43 ° C, low temperature strong heating design, stable and efficient operation Smart defrosting technology Anti-icing design at the bottom, dynamic adaptive technology, automatic adjustment of defrosting cycle, improve heating capacity and energy efficiency ratio Safety protection, worry free Compressor high and low pressure protection, frequent start and stop protection, anti-freezing protection A number of safety protection, improve the reliability of the unit and long service life
Model | YZDLR-45GXSBP | |||||||||
Rated Heating(A7W45) | Heating Capacity | W | 45000 | |||||||
Power | W | 14500 | ||||||||
COP | W/W | 3.10 | ||||||||
Rated Cooling(A35W7) | Cooling Capacity | W | 26000 | |||||||
Power | W | 10000 | ||||||||
Energy efficiency ratio/EER | W/W | 2.60 | ||||||||
Nominal Heating (A-12W41) | Heating Capacity | W | 28000 | |||||||
Power | W | 19000 | ||||||||
Energy efficiency ratio/COP | W/W | 2.35 | ||||||||
Radiant Heating (A-12W35) | Heating Capacity | W | 28000 | |||||||
Power | W | 18000 | ||||||||
Energy efficiency ratio/COP | W/W | 2.6 | ||||||||
Convective Heating (A-12W50) | Heating Capacity | W | 25000 | |||||||
Power | W | 12400 | ||||||||
Energy efficiency ratio/COP | W/W | 2.02 | ||||||||
Low Temperature Heatin (A-20W41) | Heating Capacity | W | 24000 | |||||||
Power | W | 11900 | ||||||||
Energy efficiency ratio/COP | W/W | 2.02 | ||||||||
Radiant Low Temperature Heating (A-20W35) | Heating Capacity | W | 24100 | |||||||
Power | W | 10700 | ||||||||
Energy efficiency ratio/COP | W/W | 2.25 | ||||||||
Convective Low Temperature Heating (A-20W50) | Heating Capacity | W | 21400 | |||||||
Power | W | 11800 | ||||||||
Energy efficiency ratio/COP | W/W | 1.81 | ||||||||
HSPF Performance Coefficient41℃/35℃/50℃ | 3.10 | |||||||||
IPLV(H)41℃/35℃/55℃ | W/W | 2.00 | ||||||||
APF | 2.66 | |||||||||
Max Input Power (kW) | kW | 18 | ||||||||
Max Input Current (A) | A | 32 | ||||||||
Power Specification | 380V 3N~50Hz | |||||||||
Inlet and outlet pipe size | G1-1/2 /DN40 | |||||||||
Refrigerant Type | Type | R410A | ||||||||
Outdoor Unit Dimensions | (L/W/H) | 1050×1050×1550 | ||||||||
Outdoor Unit Packaging Dimensions | (L/W/H) | 1060×1060×1660 | ||||||||
Unit Net Weight | Kg | 240kg | ||||||||
Unit Noise | dB(A) | 65 | ||||||||
Waterproof Rating | IPX4 | |||||||||
Electric Shock Protection Type | I类 | |||||||||
CLICK HERE TO RETURN TO THE HOMEPAGE |
Company Profile
About us
Guangxi Yangzi Energy saving Technology Co., Ltd. is a strategic cooperation unit under China Yangzi Group. Yangzi Group was established in 1980 and is a national first level enterprise group with 26 subsidiaries and total assets of 5 billion yuan. Our company is a well-known domestic professional company engaged in the research and development, design, manufacturing, and provision of energy-saving product solutions for solar energy, air source heat pumps, air conditioning, and other industries. We have also built a comprehensive laboratory representing the cutting-edge level of the industry, which can simulate air source heat pump products at temperatures ranging from minus 30 degrees Celsius to 43 degrees Celsius. At present, we have obtained product certifications such as ISO9001 Quality System Certification, ISO14001 Environmental Management System Certification, and OHSAS18001 Occupational Health and Safety System Certification. The company's products adopt mature design and advanced technology, and are crafted with care and intelligence, dedicating the combination of technology and art to consumers. Committed to building an outstanding brand in the world's energy-saving industry, dedicated to providing consumers with more efficient and high-quality products and services, creating value for consumers, and making contributions to society.
Team Photos
Sample Display
Production process
Exhibition
Certifications
Customer Photos
Q 1. Are you a manufacturer or a trading company ? A: A: We are the direct manufacturer of in China, we also have our own professional sales team, you can see our many advantages in product, delivery, quality assurance, service and so on.
Q 2. How long the warranty is ? A: Warranty is 1year.
Q 3. Can I visit your factory? A: Yes, we warmly welcome you come to visit us any time.
Q 4. How long is your delivery? A: 35-40 days after we get your deposit.
Q 5. Can I buy a sample for testing? A: Yes. we have the sample in stock. we welcome you to test our products. We believe that you will have the next order after testing the sample.
Q 6. I want to use our own brand , is it ok? A: Of course it's OK , we can make OEM products and also can provide our own brand products ,it's all by your request .
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–99 piece: US $2490 / piece
- 100–999 piece: US $2281 / piece
- 1000+ piece: US $2088 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this water heater?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the water heater be supplied for my local voltage?
The standard configuration is 220V~50Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangxi Yangzi Energy saving Technology Co., Ltd., based in China. The company 2 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Guangxi Yangzi Energy saving Technology Co., Ltd. range on HVACR Nexus.
