Water heater — power source Electric, Gas, Solar, material Stainless-steel SUS304. The complete factory specification follows. Made by Changzhou Wangao Energy Technology Co., Ltd. (4 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Water Heater
- Power Source: Electric, Gas, Solar
- Housing Material: Galvanized sheet
- Material: Stainless-steel SUS304
- Warranty: 3 Years
- Certification: CE CCC
- Place Of Origin: China
Technical Specifications
| Type | Air Source Heat Pump |
|---|---|
| Application | Outdoor, Hotel, Garage, Commercial, Household |
| Storage / Tankless | Storage |
| Installation | Freestanding |
| App-Controlled | No |
| Housing Material | Galvanized sheet |
| Power Source | Electric, Gas, Solar |
| Warranty | 3 Years |
| After-Sales Service Provided | Free Spare Parts |
| Place Of Origin | China |
| Function | House Heating Cooling Hot Water |
| Heat Exchanger | Built-in SUS304/SUS316L/copper Coils |
| Heat Source | Gas Boiler |
| Water Tank Volume | 150/200/250/300 |
| Material | Stainless-steel SUS304 |
| Product Name | Ground Source Hot Water Heat Pump |
| Certification | CE CCC |
| Main Heat Source | Air Source 75%+25% |
| Source | 75% Air Energy+ 25% Electricity |
| Color | White |
| Packaging Details | WOODEN CASE /CARTON |
| Port Of Dispatch | Shanghai |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
| Supply Ability | 2000 sets per Month |
Product Details
Products Specification:
Supply Ability: 2000sets/ per mouth
Packing detail: Carton Box/Plywood Bar or Box
Port : shanghai
Capactiy | Diameter | Outer Casing | Inner Tank | Working Pressure | Insulation | Tank size | ||||
(L) | Inner/outer (mm) | Material | Thickness | Material | Thickness | Bar | mm | mm | ||
30L | 290/380 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 380*540 | ||
40L | 315/420 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 420*600 | ||
50L | 365/470 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 470*550 | ||
60L | 365/470 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 470*630 | ||
80L | 365/470 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 470*830 | ||
100L | 365/470 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 470*1030 | ||
150L | 365/470 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 470*1440 | ||
200L | 440/540 | Pre-painting | 0.5mm | SUS304/316 | 1.2mm | 0.8 | 50 | 540*1440 | ||
300L | 480/570 | Pre-painting | 0.5mm | SUS304/316 | 1.5mm | 0.8 | 50 | 570*1780 | ||
400L | 600/700 | Pre-painting | 0.5mm | SUS304/316 | 2.0mm | 0.8 | 50 | 700*1510 | ||
500L | 600/700 | Pre-painting | 0.5mm | SUS304/316 | 2.0mm | 0.8 | 50 | 700*1850 | ||
600L | 650/750 | Pre-painting | 0.5mm | SUS304/316 | 2.0mm | 0.8 | 50 | 650*1900 | ||
700L | 700/800 | Pre-painting | 0.5mm | SUS304/316 | 2.0mm | 0.8 | 50 | 800*1850 | ||
800L | 800/900 | Pre-painting | 0.5mm | SUS304/316 | 2.5mm | 0.8 | 50 | 900*1680 | ||
900L | 800/900 | Pre-painting | 0.5mm | SUS304/316 | 2.5mm | 0.8 | 50 | 900*1880 | ||
1000L | 800/900 | Pre-painting | 0.5mm | SUS304/316 | 2.5mm | 0.8 | 50 | 900*2080 | ||
Procucts Work with Partner
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–19 set: US $360 / set
- 20–49 set: US $350 / set
- 50–99 set: US $340 / set
- 100+ set: US $330 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this water heater?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this water heater carry?
It is supplied with CE CCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Changzhou Wangao Energy Technology Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Changzhou Wangao Energy Technology Co., Ltd. range on HVACR Nexus.
