Water soure heat pump — 12KW, power source Electric. The complete factory specification follows. Made by Guangdong Macon New Energy Technology Co., Ltd. (18 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Water Soure Heat Pump
- Model Number: MWCHRA040ZC
- Power Source: Electric
- Power: 220V/1PH/60Hz
- Heating Capacity: 12KW
- Housing Material: metal sparying
- Refrigerant: R410A
Technical Specifications
| Type | Water Source Heat Pump |
|---|---|
| Application | Hotel, Commercial, Household |
| Storage / Tankless | Storage |
| Installation | Freestanding |
| App-Controlled | No |
| Housing Material | metal sparying |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Place Of Origin | Guangdong, China |
| Brand | MACON or OEM |
| Model Number | MWCHRA040ZC |
| Function | Heating,cooling,hot water |
| COP | 4.25 |
| Refrigerant | R410A |
| Power | 220V/1PH/60Hz |
| Heating Capacity | 12KW |
| Compressor | Scroll |
| Heat Exchanger | Plate Heat Exchanger |
| Max Hot Water Temperature | 60 degree |
| Sound Level | 53dB(1m) |
| Controller | LED controller |
| Packaging Details | Plywood case |
| Port Of Dispatch | Shunde,Guangzhou |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
| Supply Ability | 2000 units per Month |
Product Details
Macon geothermal water to air heat pump
♣Feature
domestic hot water and comprehensive energy demand application site of SPA,the best choice for public places hot and
cold applications demand, such as villa, hotels, restaurants, office buildings, cinemas, shopping malls, stadiums, hospitals and other public places.
2. Patent product with Multi-usage function.Multi-function patent with five modes : air heating, air cooling, domestic hot water,
air heating &domestic hot water at the same time, air cooling+ domestic hot water at the same time.
3. High efficiency and energy saving.Using energy efficient scroll compressors and 2 plate heat exchanger to improve energy efficiency.
Comprehensive energy consumption is only 75% of the solar energy water heater,25% of electric water heater. When it is cooling + hot water, the COP will be more than 7.5.
4. Three-core design.Heat pump, electric auxiliary heat and solar heater integrated together (optional), super energy,
which can meet all-weather hot water supply.The high quality components.Using high efficient scroll compressor, plate heat exchanger,
high efficient shell and tube heat exchanger, high efficient spiral casing heat exchanger, built-in WEILO water pump
♣Parameter
| Model | MWCHRA | 020ZC | 030ZC | 040ZC | 050ZC |
| Cooling capacity | KW | 5.6 | 8.4 | 11.2 | 14 |
| Rated input power | KW | 1.15 | 1.73 | 2.31 | 2.89 |
| Rated input current | A | 5.2 | 7.9 | 10.5 | 13.1 |
| Heating capacity | KW | 6 | 9 | 12 | 15 |
| Rated input power | KW | 1.41 | 2.12 | 2.85 | 3.53 |
| Rated input current | A | 6.4 | 9.6 | 12.8 | 14 |
| Power supply | 220V/1PH/60Hz | ||||
| Compressor | Rotary | Rotary | Scroll | Scroll | |
| Noise | dB(A) | 50 | 52 | 54 | 56 |
| Refrigerant | R410A | R410A | R410A | R410A | |
About MACON
Ordering and Pricing
- Minimum order quantity: 2 unit
- Volume pricing:
- 2–49 unit: US $1750 / unit
- 50+ unit: US $1600 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
