Key specification for this air handling unit: type Air Handling Unit. Everything below is reproduced from the factory data sheet. Made by Ningbo Longwell Electric Technology Co., Ltd. (8 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Handling Unit
- Warranty: More Than 5 Years
- Place Of Origin: Zhejiang, China
- Application: sports arenas/exhibition centers/theaters/conference rooms/malls
- Type: Air Handling Unit
- Mounting Type: Other
- Size: customizable
Technical Specifications
| Type | Air Handling Unit |
|---|---|
| Mounting Type | Other |
| Key Selling Points | High-accuracy low price cooling fast |
| Warranty | More Than 5 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Pressure Vessel, Motor, Other, Bearing, Gear, PLC, Engine, Gearbox, customizable, cooling fast, Resistant to 3000pa high pressure |
| Place Of Origin | Zhejiang, China |
| Weight (Kg) | 58 KG |
| Brand Name | LongWell |
| Dimension(L*W*H) | customizable |
| Product Name | 380v 220v 110v 50HZ 60HZ Air Handling Unit Horizontal Vertical Series |
| Application | sports arenas/exhibition centers/theaters/conference rooms/malls |
| Keyword | Air Handling Unit-Horizontal/Vertical Series |
| Cooling Temperature/Heating Temperature | Cool down to7°C/Warm up to 60°C |
| Fire-Proof Level | B1 |
| Air Volume (M³/H) | 70000m³/h |
| Rated Cooling Capacit(KW) | 10-1000KW |
| Size | customizable |
| Electric Current | AC/DC/EC |
| Function | Thermal insulation and vibration and noise reduction |
| Selling Units | Single item |
| Single Package Size | XX cm |
| Single Gross Weight | 0.0 kg |
Product Details
Products Description
Product Name | Air Handling Unit horizontal / Vertical Series | ||||||
Air Volume(m³/h) | 3000m³/h-100000m³/h | ||||||
Dimension(L*W*H) | Air Handling Unit horizontal / Vertical Series (Customizable) | ||||||
Core Components | Pressure vessel/ Motor/PLC/Pump | ||||||
Cooling capacity | 5.5kw-178.8kw | ||||||
Heating capacity | 7.5KW-126kw | ||||||
Condensate Pipe Diameter(DN) | 10mm / 12mm / 15mm / 18mm etc (Customizable) | ||||||
Condenser tube length | 200mm / 250mm / 300mm / 400mm (Customizable) | ||||||
Condenser tube wall thickness | 1mm – 2mm (Customizable) | ||||||
Air leakage rate | Air leakage rate less than 2% (rubber sealing strip reduces air leakage rate) | ||||||
Primary filter | G4/G3/G2/G1 | ||||||
Medium efficiency filter | F8/F7/F6/F5 | ||||||
High-efficiency filter | million-level filtration / 300,000-level filtration / 100,000-level filtration | ||||||
degree of filtration | degree of filtration (According to selected filter) | ||||||
Keyword | Ceiling Type Chilled Water Air Handling Unit | ||||||
Refrigerant | R410a/R22/R32/R290 | ||||||
Power Supply | 380v/3N/50HZ | ||||||
Application | Restaurant/Hotels/sports arenas/exhibition centers/malls/machinery | ||||||
Features | Easy installation, low noise and high efficiency | ||||||
Air volume working conditions | Fresh air and return air | ||||||
Technical analysis | ||||||||
working principle: | Treats the air entering a building interior to condition and optimize air quality through filtration, heating, cooling, humidification or dehumidification | |||||||
Key technical components: | Filtration systems, heat exchangers, humidity controllers | |||||||
Performance data report | ||||||||
processing power: | From 1000 m³/h to160000 m³/h | |||||||
Conditions of Use： | Configurable to meet various indoor environment needs | |||||||
Energy saving performance: | High efficiency heat recovery system | |||||||
Market positioning analysis | ||||||||
Market positioning analysis | Suitable for environments that require strict air quality control, such as hospitals, laboratories, clean rooms | |||||||
Main application scenarios： | Ensure indoor air quality, support health and productivity | |||||||
Return Air Condition(direct drive/belt drive) | Model | LWHFD-20 | LWHFD-25 | LWHFD-30 | LWHFD-100 | LWHFD-150 | |||||
Standard Cooling | Air Volume(m³/h) | 2000 | 2500 | 3000 | 10000 | 15000 | |||||
Rated Cooling Capacity(KW) | 11.4 | 14.2 | 17.3 | 59.5 | 85.1 | ||||||
Rated Heating Capacity(KW) | 21.0 | 25.7 | 31.2 | 107.3 | 161.4 | ||||||
Water Flow Rate(l/s) | 0.54 | 0.68 | 0.83 | 2.84 | 4.07 | ||||||
Water Resistance(KPa) | 61.8 | 59.4 | 53.2 | 77.1 | 89.8 | ||||||
Chilled Water Pipe Diameter(DN) | 25 | 25 | 25 | 40 | 50 | ||||||
High Cold | Rated Cooling Capacity(KW) | 14.6 | 18.1 | 22.0 | 74.6 | 107.2 | |||||
Rated Heating Capacity(KW) | 25 | 30.6 | 38.3 | 133.6 | 188.3 | ||||||
Water Flow Rate(l/s) | 0.7 | 0.86 | 1.05 | 4.08 | 5.12 | ||||||
Water Resistance(KPa) | 66.4 | 68.1 | 70.1 | 55.8 | 77.5 | ||||||
Chilled Water Pipe Diameter(DN) | 25 | 25 | 25 | 50 | 65 | ||||||
Condensate Pipe Diameter(DN) | 25 | 25 | 25 | 25 | 25 | ||||||
Power Supply | 380V/3N/50Hz | ||||||||||
Drive Type | Direct drive | Belt drive | |||||||||
Remarks: | 1. Cooling: Inlet air dry bulb temperature 27°C, wet bulb temperature 19.5°C, inlet/outlet water temperature 7°C/12°C. 2. Heating: Inlet air dry bulb temperature 15°C, hot water inlet/outlet water temperaturen 60°C/50°C. 3. Specifications are subject to change without prior notice due to product improvements. 4. The water flow rate in the table is for cooling water flow rate. The heating water flow rate is smaller than the cooling water flow rate. Pump selection should be based on the cooling water flow rate. | ||||||||||
Advantages and features of Air Handling Unit horizontal / Vertical Series
Chassis structure design
1.High strength, low air leakage rate
2.Thermal conductive PE double-layer sealing
3.Integrated aluminum plastic profile
4.The overall air leakage rate is <0.1%, far better than the national standard, and the technology leads the industry
High strength panel structure
1.Evaporator coil uses seamless copper tubing and aluminum fins
Through expansion, the two are closely combined to ensure maximum heat transfer efficiency.
Can be customized to suit individual needs
1.23 standard designs, air volume from 2000 to 60000m'h
2.9 standard configurations with multiple external static pressure options
3.Two standard thicknesses: 25mm and 50mm
4.Provides cooling, heating, filtration, humidification and other functions
No cold bridge, stronger rust resistance
1.Designed with polyurethane foam
2.The double-layer board uses a high-pressure polyurethane foam insulation layer in the middle, which has both insulation and sealing functions.
3.The edges of the sheet metal parts are fully sealed with Styrofoam,avoid condensation
4.The thermal conductivity is less than 0.0237Wm-C.
High pressure monolithic foam
1.Environmentally friendly fluorine-free foam material
2.Density>50KGim
3.Good thermal insulation and cooling performance
4.25/50mm polyurethane flood board B1 fire protection grade
5.Good flame retardancy
Intelligent integrated control
1.Integrated control of motor and water valve
2.The control system consists of internationally renowned brand Renvolt electrical appliances and thermostats.
1.23 standard designs, air volume from 2000 to 60000m'h
2.9 standard configurations with multiple external static pressure options
3.Two standard thicknesses: 25mm and 50mm
4.Provides cooling, heating, filtration, humidification and other functions
No cold bridge, stronger rust resistance
1.Designed with polyurethane foam
2.The double-layer board uses a high-pressure polyurethane foam insulation layer in the middle, which has both insulation and sealing functions.
3.The edges of the sheet metal parts are fully sealed with Styrofoam,avoid condensation
4.The thermal conductivity is less than 0.0237Wm-C.
High pressure monolithic foam
1.Environmentally friendly fluorine-free foam material
2.Density>50KGim
3.Good thermal insulation and cooling performance
4.25/50mm polyurethane flood board B1 fire protection grade
5.Good flame retardancy
Intelligent integrated control
1.Integrated control of motor and water valve
2.The control system consists of internationally renowned brand Renvolt electrical appliances and thermostats.
