Key specification for this air source heat pump: capacity 8L, power source Electric. Everything below is reproduced from the factory data sheet. Made by Foshan Blueway Electric Appliances Co., Ltd. (14 years on the platform, typical reply ≤2h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Source Heat Pump
- Model Number: EHP-17S
- Power Source: Electric
- Capacity: 8L
- Housing Material: Stainless Steel
- Material: Stainless steel
- Refrigerant: R410A
Technical Specifications
| Application | Outdoor, Hotel, Commercial, Household |
|---|---|
| Power Source | Electric |
| Type | Heat Pump Water Heaters |
| Storage / Tankless | Storage |
| Capacity | 8L |
| Installation | Freestanding |
| Housing Material | Stainless Steel |
| App-Controlled | Yes |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Private Mold | No |
| Logo/Graphic Design | Silk Screen Printing, Laser Printing, Hot Stamping, Inkjet Printing, UV printing, Heat-Transfer Printing, 3D Printing |
| Place Of Origin | China |
| Brand Name | Blueway |
| Model Number | EHP-17S |
| Color | Grey/White |
| COP | 4.0~4.5 |
| Fan Discharging | Side |
| Material | Stainless steel |
| Max Temperature | 60℃ |
| Products Type | EVI heat pump split water heater |
| Refrigerant | R410A |
| Usage | Home,Villa,SPA, School, Hotels, Hospital |
| Selling Units | Single item |
| Single Package Size | 145X145X145 cm |
| Single Gross Weight | 68.0 kg |
Product Details
EVI+DC Inverter Heat Pump Water Heater (R410A)
For Cold cliamte Ambient -15℃~43℃– Split
America hot selling low cost water heater swimming pool heat pump air source heat pump
Product details
| Brand name | Blueway |
| Color | Grey or White |
| COP | 4.0~4.5 |
| Fan discharging | Vertical or Horizontal |
| Material | Galvanized Steel Powder Coated/Plastic/Stainless steel |
| Max/Rated temperature | 28℃/40℃ |
| Place of origin | Guangdong China |
| Products type | Swim Pool heat pump |
| Refrigerant | R410A |
| Application | Home,Villa,SPA, School, Hotels, Hospital |
| Product Keywords | air source heat pump,air source heat pump water heater,swimming pool heat pump |
Blueway R32 Inverter swimming pool heat pump is a smart and reliable solution to heat the pool and spa. With most of the energy absorbed from the air, pool heat pumps can heat the pool and spa all year round with much less cost. Running at low cost and without CO2 discharging, people can enjoy swimming or spa at pleasant water temperature all over the year.
| Model | SPCH-I-2.0S | SPCH-I-3.0S | SPCH-I-4.0S | SPCH-I-5.0S | SPCH-I-6.0S | SPCH-I-5S | SPCH-I-6S | SPCH-I-7S | SPCH-I-10S | SPCH-I-15S | SPCH-I-25T | |||
| HP | 2 | 3 | 4 | 5 | 6 | 5 | 6 | 7 | 10 | 15 | 25 | |||
| Power Supply | V/Hz/Ph | 220-240/50/1, 208-230/60/1 | 380-415/50/3, 208-230/60/3, 380-415/60/3 | |||||||||||
| Heating performance | Heating (1): A26/19°C W26/28°C | Heating capacity | kW/h | 2.5~9 | 3.0~12 | 4.0~17 | 5.0~20 | 6.0~24 | 5.0~20 | 6.0~24 | 7~28 | 9~38.5 | 12~59 | 24~116 |
| Power consumption | kW | 0.2~1.65 | 0.24~2.22 | 0.33~3.2 | 0.42~4.15 | 0.51~5 | 0.42~4.1 | 0.5~4.95 | 0.58~5.5 | 0.75~8 | 1~12 | 2~23 | ||
| COP | w/w | 12.5~5.45 | 12.5~5.4 | 12.1~5.31 | 11.9~4.82 | 11.76~4.8 | 12~4.9 | 11.9~4.86 | 12.1~5.1 | 12~4.81 | 12~4.92 | 12~5.04 | ||
| Heating (2): A15/12°C W26/28°C | Heating capacity | kW/h | 1.8~7.5 | 2.2~9.5 | 3~12.5 | 4~15.5 | 5~20 | 4~15.5 | 5~20 | 6~23.5 | 8~31 | 10~48 | 20~93.5 | |
| Power consumption | kW | 0.27~1.7 | 0.33~2.1 | 0.48~3 | 0.66~4 | 0.81~4.94 | 0.65~3.92 | 0.81~5 | 0.95~5.75 | 1.31~7.9 | 1.65~12.5 | 3.4~24 | ||
| COP | w/w | 6.7~4.4 | 6.67~4.52 | 6.25~4.17 | 6.06~3.88 | 6.17~4.05 | 6.15~3.95 | 6.2~4 | 6.32~4.1 | 6.11~3.92 | 6.06~3.84 | 5.88~3.9 | ||
| Cooling performance | Cooling: A35/24°C W30/28°C | Cooling capacity | kW/h | 2~5.5 | 3~7.5 | 5~10.5 | 7~12.5 | 7.5~14 | 7~12.5 | 7.5~14 | 8~17 | 15~25 | 18~38 | 36~72 |
| Power consumption | kW | 0.42~1.7 | 0.61~2.25 | 1~3.2 | 1.37~3.85 | 1.4~4.23 | 1.35~3.9 | 1.37~4.3 | 1.4~5 | 2.7~7.35 | 3.2~11.2 | 6.55~21.5 | ||
| EER | w/w | 4.76~3.24 | 4.92~3.33 | 5~3.28 | 5.1~3.25 | 5.36~3.31 | 5.19~3.2 | 5.47~3.25 | 5.7~3.4 | 5.56~3.5 | 5.63~3.39 | 5.5~3.35 | ||
| Ambient temp. range | °C | -7~46 | ||||||||||||
| Rated/Max.outlet water temp. | °C | 28/40 | ||||||||||||
| Rated water flow rate | m³/h | 3.8 | 5.2 | 7.3 | 8.6 | 10.3 | 8.6 | 10.3 | 12 | 16.6 | 25.4 | 50 | ||
| Rated pressure drop | kPa | 4 | 5 | 5 | 7 | 13 | 7 | 13 | 15 | 15 | 17 | 23 | ||
| Controller | – | Microprocessor based digital wire controller with LCD display | ||||||||||||
| External cabinet | – | Galvanized steel with powder coating | ||||||||||||
| Compressor | Type | – | Rotaty | Scroll | ||||||||||
| Qty. | Nos. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | ||
| Refrigerant | – | R32/R410a | ||||||||||||
| Water heat exchanger | – | Titanium tube in PVC shell | ||||||||||||
| Water connection | Inlet&Outlet | inch | DN40 | DN40 | DN40 | DN40 | DN50 | DN40 | DN50 | DN50 | DN65 | DN65 | DN80 | |
| Sound pressure at 1m | dB(A) | 40~51 | 42~52 | 44~53 | 45~56 | 46~58 | 45~56 | 46~58 | 45~59 | 48~62 | 49~63 | 62~72 | ||
| Air discharge | – | Side discharge | Top discharge | |||||||||||
| Net dimension | W*D*H | mm | 950*380*610 | 950*380*610 | 1110*430*700 | 1100*430*800 | 1100*430*960 | 1100*430*800 | 1100*430*960 | 1050*400*1260 | 1100*480*1480 | 1400*525*1630 | 2000*950*2100 | |
| Net weight | kg | 43 | 45 | 54 | 70 | 90 | 70 | 90 | 105 | 210 | 235 | 600 | ||
Ordering and Pricing
- Minimum order quantity: 5 set
- Volume pricing:
- 5–19 set: US $1980 / set
- 20–99 set: US $1890 / set
- 100+ set: US $1800 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air source heat pump?
The standard minimum order quantity is 5 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Blueway Electric Appliances Co., Ltd., based in China. The company 14 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Foshan Blueway Electric Appliances Co., Ltd. range on HVACR Nexus.
