This condensing unit is published with the manufacturer’s full specification — 220V/380V, 4.8KW. Made by Zhejiang Ruixue Refrigeration Equipment Technology Co., Ltd. (10 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Condensing Unit
- Power Of Fan: 1*145W
- Voltage: 220V/380V
- Cooling Capacity: 4.8KW
- Refrigerant: R404A
- Warranty: 1 Year
- Certification: ce, ISO9001
Technical Specifications
| Core Components | Engine, Motor |
|---|---|
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | Zhejiang, China |
| Weight (Kg) | 70 |
| Type | Cooler |
| Certification | ce, ISO9001 |
| Name | Box L Type Air Cooled Condensing Unit For Cold Room |
| Refrigerant | R404A |
| Quality Of Fan | 1 |
| Air Volume | 1*2700m3/h |
| Power Of Fan | 1*145W |
| Overall Dimension | 1110*500*790MM |
| Compressor | ZB15KQE(2HP) |
| Voltage | 220V/380V |
| Cooling Capacity | 4.8KW |
| Port Of Dispatch | Shanghai,Ningbo |
| Selling Units | Single item |
| Single Package Size | 100X100X50 cm |
| Single Gross Weight | 100.0 kg |
| Supply Ability | 100 pieces per Month compressor refrigeration r404a condensing unit |
Product Details
RUIXUE supply 2HP box type condensing unit with one motor fan r404a copeland compressor unit for ice storage freezer room
Pictures of Box Type R404a Copeland Condensing Unit:
The box is designed and made by ourselves, and the compressor power is from 1hp to 30hp.It is designed as thin-wall type , which is suitable for both wall hanging and floor standing installation;All the fans are axial fans ,which is easy for installation and maintenance ,with stable operation and low noise.
| Medium and High Temperature Air-Cooled Condensing Unit Scroll Series | |||||||
| Model of units | RX-FNL-02MH | RX-FNL-03MH | RX-FNL-04MH | RX-FNL-05MH | RX-FNL-06MH | ||
| Compressor model | ZB15KQ | ZB21KQ | ZB29KQ | ZB38KQ | ZB45KQ | ||
| Applicable Temperature(℃) | 0℃ ~ -15℃ | ||||||
| Refrigerant | R22 / R404A | ||||||
| Supply | 380V 50Hz | ||||||
| Condenser | Quantity of Fan(pcs) | 1 | 1 | 1 | 2 | 2 | |
| Air flow(m³/h) | 1*3800 | 1*3800 | 1*3800 | 2*3800 | 2*3800 | ||
| Power of Fan (w) | 1*190 | 1*190 | 1*190 | 2*190 | 2*190 | ||
| Ref.Capacity of condensing units | Evaporating Temperature -0℃ | Ref. Capacity (w) | 4830/4670 | 7020/6690 | 9430/9480 | 11700/11950 | 14150/14000 |
| Power(w) | 1540/1720 | 2270/2480 | 2890/3290 | 660/4150 | 4230/4700 | ||
| Evaporating Temperature -5℃ | Ref. Capacity (w) | 4000/3820 | 5820/5740 | 7810/7790 | 9710/9830 | 11750/11500 | |
| Power(w) | 1520/1760 | 2240/2500 | 2860/3310 | 3610/4180 | 4210/4730 | ||
| Evaporating Temperature -12℃ | Ref. Capacity (w) | 2990/2710 | 4350/4300 | 5840/5840 | 7260/7370 | 8840/8630 | |
| Power(w) | 1510/1840 | 2220/2510 | 2930/3330 | 3570/4200 | 4150/4760 | ||
| Coupling | Tube coupling | φ10 | φ10 | φ12 | φ12 | φ12 | |
| Suction coupling | φ16 | φ16 | φ19 | φ19 | φ19 | ||
| Overall dimension | Lenght (A) mm | 1110 | 1110 | 1110 | 1110 | 1110 | |
| Width(B) mm | 500 | 500 | 500 | 500 | 500 | ||
| Height (H) mm | 790 | 790 | 790 | 1240 | 1240 | ||
| Installation dimension | Lenght (D) mm | 590 | 590 | 590 | 590 | 590 | |
| Width(E) mm | 440 | 440 | 440 | 440 | 440 | ||
| Medium and High Temperature Air-Cooled Condensing Unit Scroll Series | |||||||
| Model of units | RX-FNL-07MH | RX-FNL-08MH | RX-FNL-10MH | RX-FNL-12MH | RX-FNL-15MH | ||
| Compressor model | ZB48KQ | ZB58KQ | ZB76KQ | ZB88KQ | ZB114KQ | ||
| Applicable Temperature(℃) | 0℃ ~ -15℃ | ||||||
| Refrigerant | R22 / R404A | ||||||
| Supply | 380V 50Hz | ||||||
| Condenser | Quantity of Fan(pcs) | 2 | 2 | 2 | 4 | 4 | |
| Air flow(m³/h) | 2*5000 | 2*5000 | 2*7000 | 4*3800 | 5*5000 | ||
| Power of Fan (w) | 2*230 | 2*230 | 2*420 | 4*190 | 4*250 | ||
| Ref.Capacity of condensing units | Evaporating Temperature -0℃ | Ref. Capacity (w) | 15600/15750 | 18550/18600 | 24900/24700 | 28500 | 36200/36300 |
| Power(w) | 4650/5570 | 5470/6390 | 7180/8360 | 8130 | 10900/12700 | ||
| Evaporating Temperature -5℃ | Ref. Capacity (w) | 12950/13000 | 15100/15300 | 20600/20400 | 23500 | 29500/29700 | |
| Power(w) | 4630/5410 | 5460/6360 | 7130/8290 | 8070 | 10800/12650 | ||
| Evaporating Temperature -12℃ | Ref. Capacity (w) | 9730/9800 | 10900/11350 | 15450/15250 | 17550 | 21100/21900 | |
| Power(w) | 4570/5150 | 5470/6320 | 7040/8190 | 7970 | 10750/12650 | ||
| Coupling | Tube coupling | φ16 | φ16 | φ16 | φ16 | φ16 | |
| Suction coupling | φ22 | φ28 | φ35 | φ35 | φ35 | ||
| Overall dimension | Lenght (A) mm | 1230 | 1230 | 1430 | 1630 | 1730 | |
| Width(B) mm | 560 | 560 | 560 | 630 | 630 | ||
| Height (H) mm | 1240 | 1390 | 1390 | 1390 | 1490 | ||
| Installation dimension | Lenght (D) mm | 840 | 900 | 1040 | 1110 | 1210 | |
| Width(E) mm | 500 | 500 | 500 | 570 | 570 | ||
We are a manufacturer, we can customize products for you according to your requirements.If you don't know which model is suitable for you, you could send message to us.We have professional engineers to make a customized solution for you.
Send Message To RUIXUE Refrigeration!
Our products in the course of processing and are subject to stringent quality inspection before delivery, if there is a need, we photographed in the process every step of the process and quality control can be sent to customers.
Visit Our Home To Know More Information About Us!
All of our products can accept customization, accessories are CE ISO certified.
Contact us and we will show you Complete certificate.
Delivery time:Generally it is 5-10days if the goods are in stock,or it is 30-45 days if the goods are not in stock, it is according to quantity.
Trade Assurance: We recommend customers to use. We have large amount of credit.
Let's start a wonderful business!
We have professional shipping company like MSK, CMA, MSC, CSCL, COSCO, MOL to support us on shipment, ship our products to your hand easily.
All the big products are packed in wooden case for exporting specially, fumigation is not needed.
Pre-Sales Service
* Inquiry and consulting support. * Sample testing support. * View our Factory.
After-Sales Service
*Advicing how to install the machine, Advicing how to use the machine. * Perfect service for the first time
The plant covers an area of 60 acres totally. It covers an area of 20 acres, 15000M2 construction area. The main plant area is more than 11000M2. The plant Is expected to reach an annual output of 10,000 units
Every year we will attend many professional refrigeration Fair,like China refrigeration Fair,Germany Refrigeration Fair,Thailand refrigeration Fair and so on,during the Fair,we already got many customer's support,like our russia customer,kazakhstan customers,we all bulit long business relationship with them.
If you want to know more about our exhibition information, please contact us or visit our website: www.rxzl.com.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $761 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this condensing unit?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this condensing unit carry?
It is supplied with ce, ISO9001 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the condensing unit be supplied for my local voltage?
The standard configuration is 220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Zhejiang Ruixue Refrigeration Equipment Technology Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Zhejiang Ruixue Refrigeration Equipment Technology Co., Ltd. range on HVACR Nexus.
