Blast freezer condensing unit — voltage 110-380V, cooling capacity -45~25℃ or customization. The complete factory specification follows. Send your target quantity and destination for a firm quotation with current lead times.
This blast freezer condensing unit spans -45C to 25C, which is a genuinely wide envelope — the same platform handles deep blast freezing at one end and chilled storage at the other. Compressor choice is left open across Bitzer, Copeland, Danfoss, Frascold and Gree in scroll, reciprocating or screw form, so the unit can be matched to what your service network already stocks parts for. Voltage from 110V to 380V with R22, R404 or R507 refrigerant.
Key Features of This Blast Freezer Condensing Unit
- Voltage: 110-380V
- Cooling Capacity: -45~25℃ or customization
- Refrigerant: R22/404/507 or others
- Warranty: 1 Year
- Place Of Origin: Jiangsu, China
- Compressor Type: Scroll/Reciprocating/Screw
Technical Specifications
| Cooling Capacity | -45~25℃ or customization |
|---|---|
| Temperature | -45~25℃ or customization |
| Compressor Brand | Bitzer/Copeland/Danfoss/Frascold/Blait/Gree |
| Compressor Type | Scroll/Reciprocating/Screw |
| Key Selling Points | Automatic, High-Accuracy, High Productivity, Long Service Life, Low Maintenance Cost, Famous brand PLC |
| Voltage | 110-380V |
| Warranty | 1 Year |
| Core Components | Pressure Vessel, Motor, Bearing, Gear, Gearbox, PLC, Pump, Engine |
| Video Outgoing-Inspection | Provided |
| Refrigerant | R22/404/507 or others |
| Place Of Origin | Jiangsu, China |
| Weight (KG) | 150 |
| Selling Units | Single item |
| Single Package Size | 200X200X200 cm |
| Single Gross Weight | 160.000 kg |
|
Product name
|
Refrigeration unit (compressor, air cooler, expansion valve, electric controller)
|
|
Color
|
Silver gray
|
|
Safety protection device
|
System high and low pressure protection, exhaust high temperature protection, etc.
|
|
Condensing fan type
|
Brushless DC Motor
|
|
Throttling device
|
Electronic expansion valve
|
|
Heat Exchanger
|
Finned tube heat exchanger
|
|
Voltage
|
200v-380v 50Hz
|
|
Applicable Industries
|
Hotels, Food & Beverage Factory, Farms, Restaurant, Home use
|
|
High temperature compressor unit
|
||||||||||||||
|
Evaporation temperature(°C)
|
-15 〜10 °C
|
|||||||||||||
|
Type of refrigeration oil
|
Ester oil
|
|||||||||||||
|
Refrigerant
|
R410A
|
|||||||||||||
|
Type
|
GNJ-QFT3C G/NaD
|
GNJ-QFT5C G/NaD
|
GNJ-QFT6C G/NaD
|
GNJ-QFT8C G/NaD
|
GNJ-QFT10C G/NaD
|
GNJ-QFT12C G/NaD
|
||||||||
|
Cooling capacity(Kw)
|
8.1
|
13.3
|
16.5
|
19.5
|
33.1
|
35
|
||||||||
|
Input power(kW)
|
2.4
|
3.8
|
5
|
5.4
|
9.6
|
10.1
|
||||||||
|
Distribution power(Kw)
|
4.2
|
7.0
|
8
|
9
|
14
|
15.4
|
||||||||
|
Refrigerant oil volume(L)
|
1.05
|
1.7
|
1.7
|
1.77
|
2.5
|
2.75
|
||||||||
|
Noise dB (A)
|
54
|
60
|
60
|
60
|
67
|
66
|
||||||||
|
Power supply
|
220V 〜 50Hz
|
380V 3N 〜50Hz
|
||||||||||||
|
Refrigerant charge (Kg)
|
3
|
5.3
|
6
|
9.5
|
8
|
9.4
|
||||||||
|
Compressor
|
TYPE
|
Hermetic Rotary Compressor
|
Hermetic scroll compressor
|
|||||||||||
|
HP
|
3
|
5
|
6
|
8
|
10
|
12
|
||||||||
|
Connecting pipe (mm)
|
gas tube
|
16
|
19
|
19
|
22
|
28
|
28
|
|||||||
|
liquid tube
|
9.52
|
12
|
12
|
12
|
16
|
16
|
||||||||
|
Condensing fan power (w)
|
120
|
150
|
250
|
200X2
|
200X2
|
200X2
|
||||||||
|
Size(mm)
|
412*1040*700
|
530*944*823
|
530*944*823
|
427*1098*1584
|
127*1098*1584
|
427*1098*1584
|
||||||||
|
Net weight (kg)
|
72
|
105
|
118
|
159
|
195
|
176
|
||||||||
|
LOW temperature compressor unit
|
||||||||||||
|
Evaporation temperature
|
-30℃〜0℃
|
|||||||||||
|
Type
|
GNJ-QF3C D/NfD
|
GNJ-QF4C D/NfD
|
GNJ-QF5C D/NfD
|
GNJ-QF7C D/NfD
|
GNJ-QF12C D/NfD
|
|||||||
|
Type of refrigeration oil
|
FVC32D
|
RB68EP
|
POE
|
|||||||||
|
Refrigerant
|
R404A
|
R410A
|
||||||||||
|
Cooling capacity(Kw)
|
4.6
|
5.5
|
8.5
|
10.8
|
19.5
|
|||||||
|
Input power(Kw)
|
2.1
|
2.4
|
3.6
|
4.9
|
8.3
|
|||||||
|
Distribution power(Kw)
|
4
|
4
|
6.1
|
11.1
|
14.7
|
|||||||
|
Refrigerant oil volume(L)
|
1.25
|
1
|
1.7
|
1.7
|
2.51
|
|||||||
|
Noise dB (A)
|
56
|
56
|
56
|
56
|
65
|
|||||||
|
Power supply
|
220V 〜 50Hz
|
380V 3N 〜50Hz
|
||||||||||
|
Refrigerant charge (Kg)
|
3.8
|
4
|
5
|
5.5
|
10.5
|
|||||||
|
compressor
|
TYPE
|
Hermetic Rotary Compressor
|
Hermetic scroll compressor
|
|||||||||
|
HP
|
3
|
4
|
5
|
7
|
12
|
|||||||
|
Connecting pipe (mm)
|
gas tube
|
16
|
19
|
19
|
19
|
22
|
||||||
|
liquid tube
|
9.52
|
12
|
12
|
12
|
12
|
|||||||
|
Condensing fan power (w)
|
120
|
120
|
120X2
|
120X2
|
200X2
|
|||||||
|
Size(mm)
|
1040*412*700
|
950*412*800
|
995*412*1350
|
995*412*1350
|
1098*427*1584
|
|||||||
|
Net weight (Kg)
|
75
|
77
|
124
|
125
|
187
|
|||||||
We are based in Chongqing, China, start from 2017,Production cold storage, cold room and fresh-keeping storage, freezing and quick-freezing storage and etc,.There are total about 51-100 people in our office.Please do not hesitate to contact us for further information,we are waiting for you for 24 hours.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Gree Refrigeration Unit/Emerson Valley Wheel Compressor,Polyurethane Cold Storage Board,Air Cooler
4. Why should you buy from us not from other suppliers?
Xueyun Refrigeration Equipment Co., Ltd., a CCTV broadcast brand, is the leader of China’s digital innovation cold chain. It is a modern group company integrating R&D, production, sales, warehouse design and installation of refrigeration equipment such as
5. What services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency :USD,CNY;
Accepted Payment Type: T/T;L/C/ Western Union
Language Spoken:English,Chinese,Spanish
Frequently Asked Questions
What is the minimum order quantity for this blast freezer condensing unit?
Minimum order quantity is set per configuration and trial quantities can usually be arranged. Send your target volume with an enquiry and a quotation will follow with current lead times.
What warranty covers this blast freezer condensing unit?
A 1 Year warranty is supplied as standard. Spare parts and technical support remain available beyond the warranty period.
Can it be built for my local voltage?
The standard specification is 110-380V. Alternative voltage and frequency builds are available when confirmed at order stage.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying volumes. Supply your artwork and technical requirements with the enquiry.
How long is production and delivery?
Stocked configurations normally ship in 7-15 days. Customised or high-volume orders are typically produced in 25-35 days, confirmed at order.
About the Manufacturer
This blast freezer condensing unit is produced by Chongqing Xueyun Refrigeration Equipment Co., Ltd.. Browse the full Chongqing Xueyun Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
