Air Handling Unit, HVAC, HEPA, AHU

The air handling unit listed here carries power supply 220-240V, 50Hz, 1 Phase, airflow 450m³/h,700m³/h, documented exactly as the manufacturer publishes it. Made by Guangzhou Klc Cleantech Co., Ltd. (22 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Air Handling Unit

• Power Supply: 220-240V, 50Hz, 1 Phase
• Operating Voltage: 230 VAC
• Airflow: 450m³/h,700m³/h
• Noise Level: ≤65 dBA
• Warranty: 1 Year
• After Warranty Service: Online support

Technical Specifications

Product Details

Commercial HVAC System HEPA AHU Large Fresh Air Flow Air Handling Unit For Hospital

Specification

Specification

Item	Air Handling Unit
Model	FAC-450	FAC-700
Material	Cold rolled steel with powder coated
Dimension（WxHxL）	328x338x800mm	328x338x800mm
Air Flow Capacity	450 m³/h	700 m³/h
Coverage area	24 ~ 42 m²	33 ~ 60 m²
Fan	EC Centrifugal Fan	EC Centrifugal Fan
Efficiency	99.99%@0.3μm	99.99%@0.3μm
Colour	White	White
Noise (equipment edge)	≤65 dB	≤65 dB
Power supply	220~240V/50Hz 1Phase	220~240V/50Hz 1Phase

Products Description

The introduction of air handling unit

Designed to deliver the easiest and quick protection to users by effectively controlling & eliminating all types of particulate dust, microbial and chemical pollutants from air stream, making the ambient suitable for users with reduced risk of airborne infection & molecular pollutants. The air handling unit shall be self-sufficient for recirculation, positive or negative pressurization applicaitons with in-built low noise fan assembly and controls

As additional to indoor fresh air intake , can be easily fitted to existing fresh air system or mixed (fresh & recirculating ) air system.

Customized Product Display

Customized Product Display

OEM, OEM Production services.

Independent R&D team, one-stop solution for cleanroom projects.

Application

Application

Used in laboratory, operating room, biopharmaceutical, LED lights, circuit boards, microelectronics, medical industry, food processing and other clean fresh air demanding work enviornment; Also widely used in civil construction of the ventilation system, be applied to the housing building plus wind and equiblast of fire control system, purification air pressurizing and supplement and other occasion.

Related products

Company Information

Guangzhou KLC Cleantech Co., Ltd Guangzhou KLC Cleantech Co., Ltd was established in 1994, is a professional engaged in the research, development, sale and service of air filters, air purification equipment and cleanroom solutions. Located in Guangzhou China, enjoying convenient transportation and beautiful environment, KLC factory covers an area of 13500 square meters and has more than 160 employees.

Owning the advanced production processing and highly automotive machine lines for air purification equipment, equipped a dust-free production workshop for air filters, KLC is always capable of meeting production requirements of large projects.

Certifications

Dedicated to these strict quality control and thoughtful customer service, we welcome OEM and ODM orders, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. Adhering to the business principle of mutual benefits, KLC have had a reliable reputation among our customers all over the world because of our professional services, quality products and competitive prices. We warmly welcome customers from at home and abroad to cooperate with us for common success.

Contact Us

1. Q: Are you manufacturer or trader？Where are your factory located？

A: We are manufacturer with professional designers and engineers. Our factory is located in Guangzhou city.

2. Q: How long is your warranty? Can we extend?

A: 12 months after installation and commissioning. Warranty can be extended with extra charge.

3. Q: Do you have professional engineer team fordesign and installation?

A: Yes, we have engineer team for ODM and OEM services

4. Q: What documents will you provide?

A: Usually we will provide DQ, IQ, PQ, OQ, FAT, SAT, operation manual, maintenance instruction, layout drawing etc.

Ordering and Pricing

• Minimum order quantity: 1 unit
• Volume pricing:
  • 1–4 unit: US $700 / unit
  • 5–9 unit: US $670 / unit
  • 10+ unit: US $650 / unit
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air handling unit?

The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Which certifications does this air handling unit carry?

It is supplied with CE ISO9001 ISO14001 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.

Can the air handling unit be supplied for my local voltage?

The standard configuration is 230 VAC. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
