This air source heat pump is published with the manufacturer’s full specification — 40.6kw, power source Electric. Made by Foshan Folansi Heat Pump Co., Ltd. (1 year on the platform, typical reply ≤4h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Source Heat Pump
- Model Number: FA-10EVI
- Power Source: Electric
- Heating Capacity: 40.6kw
- Housing Material: powder coating metal or stainless steel metal
- Refrigerant: R32
- Warranty: 3 Years
Technical Specifications
| Type | Air Source Heat Pump |
|---|---|
| Heating Capacity | 40.6kw |
| Application | Outdoor, Hotel, Commercial, Household |
| Refrigerant | R32 |
| Storage / Tankless | Instant / Tankless |
| Compressor | Scroll Compressor |
| Installation | Freestanding |
| App-Controlled | No |
| Housing Material | powder coating metal or stainless steel metal |
| Feature | High Efficiency, Safe, Energy-Saving, Easy Operation, Eco-Friendly, Easy Installation |
| Power Source | Electric |
| Warranty | 3 Years |
| After-Sales Service Provided | Free Spare Parts |
| Operating Language | English |
| Private Mold | No |
| Packaging Types | Corrugated Box |
| Place Of Origin | Guangdong, China |
| Brand | Folansi |
| Model Number | FA-10EVI |
| Function | House Heating Cooling Hot Water |
| Use | Outdoor |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
| Model | heat pump | FA-10EVI | ||
| Unit function | Standard condition | Heating capacity | kw | 40.60 |
| kcal/h | 34910.00 | |||
| Hot water supply | T/h | 0.87 | ||
| Input power | kw | 9.60 | ||
| Low temperature conditions | Heating capacity | kw | 33.20 | |
| kcal/h | 28547.00 | |||
| Hot water supply | T/h | 0.63 | ||
| Input power | kw | 9.38 | ||
| Ultra-low temperature conditions | Heating capacity | kw | 19.40 | |
| kcal/h | 16681.00 | |||
| Hot water supply | T/h | 0.37 | ||
| Input power | kw | 9.30 | ||
| Standard condition heating input current | A | 16.80 | ||
| Max running current | A | 21.00 | ||
| Power | V/Ph/Hz | 380~400V/3N/50Hz | ||
| Unit Noise comprehensive index | Db(A) | 58.00 | ||
| Dimension | W | mm | 1450.00 | |
| D | mm | 780.00 | ||
| H | mm | 1050.00 | ||
| Unit weight | kg | 330.00 | ||
| Running control | Water temperature control precision | ℃ | ±2℃ | |
| Ambient temperature range | ℃ | –30℃ – 43℃ | ||
| Refrigerants circulation structure | Throttle type | thermostatic expansion valve/electric expansion valve | ||
| Refrigerant | Type | R407C,R410A | ||
| Refrigerant charge | kg | 3.5*2 | ||
| Max working pressure | bar | 28.00 | ||
| Compressor | Type | Efficient fully enclosed type vortex. Copeland,panasonic EVI | ||
| Stall Current | A | 60.00 | ||
| Air-source side heat exchanger | Type | Finned heat exchanger | ||
| Qty | pc | 2.00 | ||
| Motor power | kw | 0.4*2 | ||
| Hhot water side heat exchanger | Type | tube in shell heat exchange/plate heat exchange | ||
| Water flow | m3/h | 6.98 | ||
| Water pressure down | kPa | 36.00 | ||
| Connecting pipe size | DN | 32.00 | ||
| Water side max working pressure | kPa | 1000.00 | ||
1,standard condition heating condiiton: air source side heat exchanger inlet air 20/15℃,hot water source intial temp 15℃,end heating temp 55℃.
2,Low temp heating condition: air source side heat exchanger inlet air 7/6℃,hot water side intial temp 10℃,end heating temp 55℃.
3,Ultra-low temperature heating conditions:air-source side heat exchanger inlet air -15/-17℃,hot water side intial temp 10℃,end heating temp 55℃.
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1–1 unit: US $2910.17 / unit
- 2–9 unit: US $2894.2 / unit
- 10+ unit: US $2874.24 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air source heat pump?
The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Folansi Heat Pump Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Foshan Folansi Heat Pump Co., Ltd. range on HVACR Nexus.
