Axial condenser — 120 V, 230V, 380V, power source Electric. The complete factory specification follows. Made by Shanghai Anneng Fan Co., Ltd. (17 years on the platform, typical reply ≤4h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Axial Condenser
- Model Number: A4D600S-5DM-AT00, A6E600S-5DM-AT00
- Power Source: Electric
- Voltage: 120 V, 230V, 380V
- Material: Carbon Steel
- Blade Material: Carbon Steel
- Warranty: 2 Years
Technical Specifications
| Blade Diameter | 24 in |
|---|---|
| Voltage | 120 V, 230V, 380V |
| Type | ac axial fan |
| Material | Carbon Steel |
| Blade Material | Carbon Steel |
| Mounting Type | Free Standing |
| Bearing Type | TWO BALL BEARING |
| Power Source | Electric |
| Warranty | 2 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Shanghai, China |
| Brand Name | ANENG |
| Model Number | A4D600S-5DM-AT00, A6E600S-5DM-AT00 |
| Motor | External Rotor Motor |
| Rotor | Cast aluminum |
| Type Of Protection | IP44 |
| Insulation Class | Class F |
| Bearing | NSK Ball Bearing |
| Life Time | 40000h+ |
| Weight | 18kg |
| Cable Lenght | 450 mm or terminal box |
| Certification | CE CCC RoHS |
| Selling Units | Single item |
| Single Package Size | 55X55X23 cm |
| Single Gross Weight | 18.0 kg |
Product Details
Type: 600MM AXIAL CONDENSER FAN
| 1. for Sample, packing individually by foam carton; 22*22*15cm 2. for Mass, pallet package 112x112x120CM. |
| Quality Guarantee We are professional manufacturer in ac,dc,ec centrifugal fans with brushless external rotor motor. All the fans are produced by ourselves independently, including the motor. So we have more confidence on the products' qulaity and performance. Price Guarantee The products are sold by our own factory directly. So the reason for low price is simple: no middlemen. Delivery Time Guarantee We will make production on time as order and send the goods according to mutual confirmed delivery time. We will try our best to avoid risk of any delay. Service Guarantee We adopt the mode of combining the sales team and engineers team. So we can provide the responsible suggestion and recommendation when we contact at first time.We will check all details before accepting the order, and keep quality before delivery.
Our Friends, Let's creat a beautiful future! |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–99 piece: US $85 / piece
- 100–199 piece: US $75 / piece
- 200–499 piece: US $73 / piece
- 500+ piece: US $72 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this axial condenser?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this axial condenser carry?
It is supplied with CE CCC RoHS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the axial condenser be supplied for my local voltage?
The standard configuration is 120 V, 230V, 380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
