Axial fan — 230V, 400Y, power source Electric. The complete factory specification follows. Made by Ningbo Lionball Ventilator Co., Ltd. (22 years on the platform, typical reply ≤7h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Axial Fan
- Model Number: YWF300
- Power Source: Electric
- Voltage: 230V, 400Y
- Blade Material: Stainless Steel
- Speed: 950RPM-2700RPM
- Warranty: 1 Year
Technical Specifications
| Voltage | 230V, 400Y |
|---|---|
| Speed | 950RPM-2700RPM |
| Type | ac axial fan |
| Blade Material | Stainless Steel |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Field Maintenance and Repair Service |
| Customized Support | OEM, ODM |
| Place Of Origin | Zhejiang, China |
| Brand Name | LIONBALL |
| Model Number | YWF300 |
| Product Name | AC Axial Fan |
| Application | Cooling |
| Motor | AC External Motor |
| Ambient Temperature | -20°C to +45°C (Customizable to -40°C to +70°C) |
| Average Service Life | Over 20008 Hours |
| Selling Units | Single item |
| Single Package Size | 44X44X17.5 cm |
| Single Gross Weight | 6.600 kg |
Product Details
Types | AC Axial Fan |
Voltage Ranges | 220V, 230V, 380V, 400V |
Frequency | 50/60 Hz |
Diamter | 300mm ( impeller diameters ) |
Motor Types | External Rotor Motor |
Speed Control | 0-10V Signal / PWM / RS485(Optional) |
Max.ambient Temp | -20℃～ +70℃ |
Certificating | All necessary certifications suitable for USA & Europe, UL, CE, RoHS, Atex, CB, CQC, ISO 9001, ISO 14001, ISO 45001 |
Protection Level | IP44, IP54, IP55 |
Electronic Protection | Current limiting protection ,Over-temperature protection,Over-current protection,Locked-rotor protection,Soft start |
Working & Storage | Operating temperature：-25~45℃ (Customizable to -40℃-+70℃） |
Product Standards | LVD EN60335-1; EMC EN61000-3-2, EN61000-3-3 |
Mainly Applications | AUH/ AIR PURIFIER / Server Cooling & Ventilation / Grow Tent /Ventilation SYSTEM/ Equipments Cooling /Refrigerator, etc; ventilation fan cooling; ventilation exhaust fans |
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–299 piece: US $32 / piece
- 300–499 piece: US $28 / piece
- 500+ piece: US $27 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this axial fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the axial fan be supplied for my local voltage?
The standard configuration is 230V, 400Y. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Ningbo Lionball Ventilator Co., Ltd., based in China. The company 22 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Ningbo Lionball Ventilator Co., Ltd. range on HVACR Nexus.
