The belt driven axial fan listed here carries 120 V, 380 V, 110 V, 220 V, power source Electric, documented exactly as the manufacturer publishes it. Made by Guangzhou Xinfeng Fan Co., Ltd. (13 years on the platform, typical reply ≤5h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Belt Driven Axial Fan
- Power Source: Electric
- Voltage: 120 V, 380 V, 110 V, 220 V
- Material: Stainless Steel
- Blade Material: Stainless Steel
- Speed: 2100 RPM, 2700 RPM, 4500 RPM, 1350RPM, 14000Rpm, 3 000 RPM, 2500 RPM
- Warranty: 3 Years
Technical Specifications
| Voltage | 120 V, 380 V, 110 V, 220 V |
|---|---|
| Speed | 2100 RPM, 2700 RPM, 4500 RPM, 1350RPM, 14000Rpm, 3 000 RPM, 2500 RPM |
| Type | High-Temperature Axial Fan |
| Material | Stainless Steel |
| Blade Material | Stainless Steel |
| Mounting Type | Free Standing |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 3 Years |
| After-Sales Service Provided | Field installation, commissioning and training |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Guangdong, China |
| Brand Name | SUIFENG |
| Size | 40x40x10mm |
| Application | Workshop |
| Usage | Cooling System |
| Product Name | AC Axial Fan |
| Color | Customers’ Requirements |
| Feature | Saving Energy .strong Wind Power.convenient.slient |
| Keyword | Exhaust Cooling Fan |
| Noise | 65db |
| Certification | CE/FCC/RoHs/UL/CCC/ISO9001 |
| Function | Exhaust Air |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Model | Revolution (r/min) | Volume (m³/h) | Full presure (Pa) | static pressure (Pa) | Power (Kw) | working voltage (v) |
BYT-280 | 1450 / 2900 | 662~3542 | 39~254 | 20~135 | 0.025 ~0.37 | 200V/380V |
BYT-315 | 1450 / 2900 | 1473~5957 | 56~316 | 32~181 | 0.04 ~0.55 | 200V/380V |
BYT-355 | 1450 / 2900 | 2128~6942 | 60~366 | 32~170 | 0.04 ~ 1.1 | 220V/380V |
BYT-400 | 960/ 1450/ 2900 | 1908~9312 | 32~496 | 32~279 | 0.12 ~ 2.2 | 220V/380V |
BYT-450 | 720 / 960 / 1450 / 2900 | 1991~14539 | 20~710 | 20~369 | 0.18 ~4 | 220V/380V |
BYT-500 | 720 / 960 / 1450 / 2900 | 2142~19679 | 31~710 | 18~416 | 0.18~ 5.5 | 220V/380V |
BYT-560 | 720 / 960 / 1450 / 2900 | 2734~24885 | 53~1040 | 45~703 | 0.18~11 | 220V/380V |
BYT-600 | 720 / 960 / 1450/ 2900 | 3664~33466 | 65~1211 | 48~755 | 0.18~15 | 220V/380V |
BYT-630 | 720 / 960 / 1450 / 2900 | 3895~40358 | 62~1175 | 21~836 | 0.18~18.5 | 220V/380V |
BYT-710 | 720 / 960 / 1450 | 4951~29798 | 82~471 | 47~340 | 0.25~5.5 | 220V/380V |
BYT-800 | 720/ 960 / 1450 | 6854~37807 | 96~532 | 73~397 | 0.37~7.5 | 220V/380V |
BYT-900 | 720/ 960/1450 | 10358~51387 | 118~795 | 102~552 | 0.75~15 | 220V/380V |
BYT-1000 | 720/ 960 / 1450 | 19127~69513 | 150~923 | 119~608 | 1.5~18.5 | 220V/380V |
BYT-1120 | 720/ 960 / 1450 | 23384~111435 | 188~1076 | 154~788 | 2.2~45 | 220V/380V |
BYT-1250 | 720/ 960 / 1450 | 29853~136982 | 240~1477 | 207~1038 | 3~75 | 220V/380V |
BYT-1400 | 720 / 960 | 47799~128075 | 325~845 | 256~583 | 5.5~37 | 220V/380V |
BYT-1600 | 720 / 960 | 23384~195148 | 202~1116 | 153~766 | 2.2~90 | 220V/380V |
BYT-1800 | 720/ 960 | 100562~277857 | 350~1413 | 251~993 | 22~160 | 220V/380V |
BYT-2000 | 720 / 960 | 109347~381147 | 645~1744 | 499~1159 | 37~250 | 220V/380V |
1.Do you have MOQ?
2.How long is the product's warranty?
3.Can you provide OEM or ODM?
4.Are you a manufacturer or a trader?
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $60 / set
- 10+ set: US $55 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this belt driven axial fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this belt driven axial fan carry?
It is supplied with CE/FCC/RoHs/UL/CCC/ISO9001 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the belt driven axial fan be supplied for my local voltage?
The standard configuration is 120 V, 380 V, 110 V, 220 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangzhou Xinfeng Fan Co., Ltd., based in China. The company 13 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Guangzhou Xinfeng Fan Co., Ltd. range on HVACR Nexus.
