Key specification for this belt ventilation fan: 380v, power source Electric. Everything below is reproduced from the factory data sheet. Made by Jiangyin Glitter Air Treatment Equipment Co., Ltd. (19 years on the platform, typical reply ≤4h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Belt Ventilation Fan
- Model Number: 50”
- Power Source: Electric
- Power: 1.1kw
- Voltage: 380v
- Blade Material: Stainless Steel
- Warranty: 1 Year
Technical Specifications
| Voltage | 380v |
|---|---|
| Type | Wall-Mounted Axial Fan |
| Blade Material | Stainless Steel |
| Mounting Type | Wall Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM |
| Place Of Origin | Jiangsu, China |
| Brand Name | XINJU |
| Model Number | 50” |
| Size | 1380*1380*450mm |
| Motor Brand | China |
| Power | 1.1kw |
| Blade Diameter | 1270mm |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
2.Features:
1. Blade:Mirror stainless steel blade, imported from Germany, 6pcs.
Blade angle, patent design. Complete fan, through dynamic balance test, keep consistent air flow.
2. Framework:Aluminized ZINC plate. One-time molding process with water outlet at bottom.
3. Shutter:Hot galvanized sheet, high strength, keep 90° opening.
0.8mm and 1.5mm hot galvanized sheet, enhance the shutter strength and service life, increase weight and stability.
4. Centrifugal open institutions:High quality nylon material, enhance the service life. Through push-pull style, shutters open and close automatically, smoothly and silently.
5. V Belt:Mitsuboshi belt, from Japan, no deformation, free-maintenance.
6. Motor:High efficiency and energy saving, CCC certified, protection grade IP55, insulation grade F
7. Aluminum Alloy Components:V belt pulley, hot injection moulding, light material and high strength.
3.Specification:
| Model | 50’’ | 36’’ |
| Power | 1.1kw | 0.4kw |
| Blade Dia.(mm) | 1270 | 910 |
| Dimension(mm) | 1380*1380*450 | 1000*1000*450 |
| Type | Push-pull | Push-pull |
| Blade Material | 430BA Krupp S S | 430BA Krupp S S |
| Fan RPM(r/min) | 444 | 438 |
| Voltage | 380v/50Hz/3P | 380v/50Hz/3P |
| Motor RPM(r/min) | 1400 | 1400 |
| Air Flow(m3/h) | 40800 | 20800 |
| Noise(dB) | ≤65 | ≤64 |
| Frame Material | Aluminized ZINC plate | Aluminized ZINC plate |
| Shutters Material | hot galvanized sheet | hot galvanized sheet |
| V Belt | Mitsuboshi | Mitsuboshi |
| Weight(kg) | 88 | 55 |
1. Are you factory or trade company?
–We are professional ventilation fan products factory!
2. How can i get your pricelist?
—Send an enquiry to us and tell us u need our pricelist,our sales will reply u within 24 hours with pricelist.
3. Can i get an sample to check quality before mass order?
–Yes,you can.Welcome to place sample order to check our quality. I do believe our high quality products will bring more orders for you from your clients!
4. Any guarantee for your products?
–Our company’s culture is "Quality is our culture!” All of our products with
12 months FREE GUARANTEE,never need to worry about the after-sale service,we will always be here to support your business!
5. Any certifications for your products?
–Our exhaust fan products can pass CE certification,so they can be sold to worldwide safely!
6. How about the delivery time?
–Usually for sample order 5-7days,for mass order 7-15 days.
7. At last,about the payment terms,any convenient and safe way for our buyers?
—We have pay Alibaba pay,T/T payment terms options,do business with us,your money will be in safe,your business will be in safe!
Ordering and Pricing
- Minimum order quantity: 5 set
- Volume pricing:
- 5–49 set: US $268 / set
- 50–99 set: US $253 / set
- 100+ set: US $249 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this belt ventilation fan?
The standard minimum order quantity is 5 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the belt ventilation fan be supplied for my local voltage?
The standard configuration is 380v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Jiangyin Glitter Air Treatment Equipment Co., Ltd., based in China. The company 19 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Jiangyin Glitter Air Treatment Equipment Co., Ltd. range on HVACR Nexus.
