Centrifugal blower — 24V, blade material Impeller made of galvanized sheet steel. The complete factory specification follows. Made by Guangzhou Kingan Auto Parts Co., Limited (13 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Centrifugal Blower
- Model Number: K3A160-DCN-92
- Voltage: 24V
- Blade Material: Impeller made of galvanized sheet steel
- Warranty: 1 Year
- Certification: ce
- Place Of Origin: Guangdong, China
Technical Specifications
| Voltage | 24V |
|---|---|
| Blade Material | Impeller made of galvanized sheet steel |
| Electric Current Type | DC |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Place Of Origin | Guangdong, China |
| Brand Name | KINGAN |
| Model Number | K3A160-DCN-92 |
| Certification | ce |
| Feature | Low Noise Power Saving |
| Direction Of Rotation | Anticlockwise, seen on leads |
| Type Of Protection | IP42 |
| Bearing | Ball bearing |
| Insulation Class | B |
| Approval | CCC,CE |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
DC 24V 48V forward curved centrifugal blower fan brushless impeller fan for air filtration system
Model | Voltage (VAC) | Air Flow (m3/h) | Speed (rpm) | Power Input (W) | Current (A) | Static Pressure (Pa) |
K3A160-DAN-92 | 12 | 490 | 1600 | 70 | 5.20 | 500 |
K3A160-DCN-92 | 24 | 550 | 1750 | 105 | 4.40 | 600 |
K3A160-DFN-92 | 48 | 550 | 1750 | 105 | 2.90 | 600 |
Answer: You can send us the picture or item code number, our profession will help to make sure the item for you.
Q: What is your minimum order quantity?
A: Normally we require 100 PCS as MOQ. But for a starting, we also accept few samples order for trying.
Q: What about your production time.
A: Average it takes about 5 days to prepare the standard items. If you need customize the motor speed, the production might take 2 more days to finish.
Q: Can i visit your company?
A: Welcome to our company at any time. We are located in Guangzhou, a international city in south of China. Guangzhou airport.
Ordering and Pricing
- Minimum order quantity: 2 piece
- Volume pricing:
- 2–9 piece: US $54 / piece
- 10–499 piece: US $52 / piece
- 500+ piece: US $49.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal blower?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this centrifugal blower carry?
It is supplied with ce documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the centrifugal blower be supplied for my local voltage?
The standard configuration is 24V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
