Centrifugal Fan, 100MM, 230V, Plastic, 85W

Centrifugal fan — 230 V, power source type Corded Electric. The complete factory specification follows. Made by Suzhou Blauberg Motoren Technology Co., Ltd. (7 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Centrifugal Fan

• Model Number: IL-B100P-EC-00
• Power Source Type: Corded Electric
• Voltage: 230 V
• Material: Metal
• Blade Material: Plastic
• Noise Level: 40 dB and above

Technical Specifications

Product Details

BLAUBERG MOTOREN

Blauberg Motoren , established in 2014 as part of Blauberg Group Germany, focuses on EC motor and fan technology with localized manufacturing in China.

By 2025, the company operates a modern production facility of over 10,000㎡ with 120+ employees and holds 29 patents, driving continuous innovation in ventilation solutions for global markets.

Product Information

Type	IL-B100P-EC-00	Nominal Speed	3300±5%RPM
Motor	EC072AC230V085W	Max. Input Power	85W
Phase	1~	Max. Input Current	0.65A
Nominal Voltage	230VAC	Sound level	72dB(A)
Nominal Voltage Range	184~276VAC	Min.Ambient Temperature	-25℃
Frequency	50/60 Hz	Max.Ambient Temperature	60℃
Method of Obtaining Data	FA	ML=Max. load ME=Max, effciency FA=Free Air

Related products

EC SERIES

Model	Voltage  Range[V]	Frequency [Hz]	Rated Speed[RPM]	Rated Power[W]	Rated Current[A]	Noise Level[dB(A)]
IC-B100P-EC-00	92~138	50/60	3300	85	1.3	72
IC-B125P-EC-00	92~138	50/60	3300	85	1.3	72
IC-B150P-EC-00	92~138	50/60	2600	85	1.2	72
IC-B160P-EC-00	92~138	50/60	2700	85	1.3	73
IC-B200P-EC-01	92~138	50/60	3400	170	2.6	80
IC-B250P-EC-01	92~138	50/60	2800	170	2.4	78
IC-B315D-EC-07	92~138	50/60	2600	220	3.2	82

DC SERIES

Model	Voltage  Range[V]	Rated Speed[RPM]	Rated Power[W]	Rated Current[A]	Noise Level[dB(A)]
ID-B100P-EC-00	19~29	3300	85	3.6	72
ID-B125P-EC-00	19~29	3300	85	3.6	72
ID-B150P-EC-00	19~29	2600	85	3.5	72
ID-B160P-EC-00	19~29	2700	85	3.5	73
ID-B200P-EC-N07	19~29	2800	180	7.6	76
ID-B250P-EC-N07	19~29	2850	180	7.5	79
ID-B315D-EC-N07	19~29	2500	220	8.4	80

AC SERIES

Model	Voltage  Range[V]	Frequency [Hz]	Rated Speed[RPM]	Rated Power[W]	Rated Current[A]	Noise Level[dB(A)]
IL-B100M-AC-00	184~276	50/60	2450/2500	62/81	0.28/0.36	58/60
IL-B125P-AC-00	184~276	50/60	2750/3108	83/97	0.38/0.44	64/67
IL-B150P-AC-01	184~276	50/60	2520/2680	10/128	0.45/0.57	66/68
IL-B160P-AC-01	184~276	50/60	2500/2670	104/132	0.45/0.59	67/69
IL-B200M-AC-02	184~276	50/60	2550/2700	175/242	0.75/1.08	68/70
IL-B250M-AC-02	184~276	50/60	2610/2770	166/235	0.74/1.05	67/75
IL-B350M-AC-03	184~276	50/60	2530/2620	220/310	0.94/1.38	73/76

Application

Home Applications

-Fresh Air Systems -HVAC Systems -High-end Residential Air Purifiers

Industrial Applications

-Industrial Dust -Cleaning Equipment -Data Centers

Medical Applications

-Operating Rooms -Medical Equipment -Sterile Wards

Transportation

-Automotive AC Systems -Rail Transit Feedback Control -For Diverse Field Requirements

New Energy Equipment

-Charging Piles and Stations -Energy Storage System Cooling

Why Choose Us

Certificate

Product Certification

Blauberg Group has achieved more than 30 global mainstream safety and energy efficiency certifications such as CCC, UL, ETL, ROHS, CE, TUV with strict standards.

The product meets the strict global market access requirements, and is a strong proof of product reliability and excellent performance.

Company Profile

THE BIRTH OF THE BLABUERG BRAND

In 1900, Karl August Blauberg founded Blauberg in the Bavarian region of Munich, Germany. The company was born in the bavarian state at the foot of the majestic carpathian mountains. At the same time, BLAUBERG also means blue mountains.

Company Profile

Blauberg Motoren , established in 2014 as part of Blauberg Group Germany, focuses on EC motor and fan technology with localized manufacturing in China.
By 2025, the company operates a modern production facility of over 10,000㎡ with 120+ employees and holds 29 patents, driving continuous innovation in ventilation solutions for global markets.

Exhibition

ISH IN BEIJING

CRH IN SHANGHAI

CRH IN BEIJING

HARFQ IN KOREA

HVACR IN VIETNAM

MARVEX HVAC IN MALAYSIA

CANTON FAIR IN GUANGZHOU

RHVAC IN INDONESIA

FAQ

Q: Who are we?

A: Blauberg Motoren, part of Germany's Blauberg Group, manufactures fans and motors. The Group offers a wide range
of ventilation products—from domestic to industrial—and specializes in providing customized solutions and parts to meet diverse client needs with an optimal balance of price and quality.

Q: Why choose us？

A: Large-scale producer of fans with modern facilities, high annual capacity, and a strong focus on customized solutions and customer support.

Q: Wonder if you accept small orders?

A: Do not worry. Feel free to contact us .In order to get more orders and give our clients more convener ,we accept small
order.

Q: Can you do OEM for me?
A: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you.

Q: What's your payment terms ?
A: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.

Ordering and Pricing

• Minimum order quantity: 1 piece
• Volume pricing:
  • 1–99 piece: US $50.59 / piece
  • 100–999 piece: US $46.18 / piece
  • 1000+ piece: US $41.05 / piece
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this centrifugal fan?

The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.

Which certifications does this centrifugal fan carry?

It is supplied with ce,ccc,RoHS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.

Can the centrifugal fan be supplied for my local voltage?

The standard configuration is 230 V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Suzhou Blauberg Motoren Technology Co., Ltd., based in China. The company 7 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Suzhou Blauberg Motoren Technology Co., Ltd. range on HVACR Nexus.
