Leading (Shandong) CNC Equipment lists this cnc fiber laser tube with its own published specification, unedited. Supplier profile: 4 years on the platform, factory-assessed. Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Cnc Fiber Laser Tube
- Laser Power: 1500W /2000W/ 3000W / 6000W
- Applicable Material: Metal
- Cutting Materials: Stainless Steel Carbon Steel
- Cutting Speed: 0-120m/min
- Warranty: 3 Years
- Place Of Origin: Shandong, China
Technical Specifications
| Laser Type | Fiber Laser |
|---|---|
| Applicable Material | Metal |
| Cutting Thickness | 1-30mm |
| Products Handled | Sheet Metal And Tube |
| Cutting Speed | 0-120m/min |
| Configuration | 3-Axis |
| Feature | Water-Cooled |
| Mode Of Operation | Continuous Wave |
| Cooling Mode | WATER COOLING |
| Control System Brand | Cypcut |
| Servo Motor Brand | Yaskawa |
| Guiderail Brand | PEK |
| Laser Head Brand | Raytools |
| Graphic Format Supported | AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT |
| Warranty | 3 Years |
| Condition | New |
| Key Selling Points | High-Accuracy |
| Cnc Or Not | Yes |
| Control Software | Cypcut |
| Place Of Origin | Shandong, China |
| Brand Name | Leading |
| Weight | 3500 |
| Type | Metal Plate & Pipe CNC Fiber Laser Cutting Machine |
| Laser Power | 1500W /2000W/ 3000W / 6000W |
| Cutting Materials | Stainless Steel Carbon Steel |
| Laser Head | Raytools/Precitec |
| Cooling System | Industrial Water Chiller |
| Working Area | 4000mmX2000mm |
| Fiber Laser Source | IPG Max Raycus |
| Control System | Cpycut Control |
| Color | Customer Requirement |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Fiber laser cutting machine is usually used to cutting metal materials, like steel sheet, steel pipe, aluminum, copper, stainless steel, carbon steel, etc.
| Model | LEA-DTP-2260 |
| Machine bed | Sauare tube weldin |
| Gantry struture | Aluminum |
| Machine overall dimensions | 11000 * 1200 * 2260mm |
| Overall weightGuiderail | 3000ka |
| Laser head | THK / PEK / HIWIN |
| Laser source | Raytools / PrecitecIPG / Raycus / MAX |
| Servo motor and drive | YASKAWA / FUJ |
| Control system | Sypcut / WEIHONG |
| Chuck | Dysonbot |
| Clamping Range | 20-220mm(240/320/350) mm |
| Max linkage speed | 100m / min |
| Max acceleration | 1 . 5G |
| Positioning accuracy | 0 . 03mm |
| Pepositioning accuracy | 0 . 02mm |
| laser power | 3KW-6KW |
| Power supply | 380V 50HZ / 60HZ / 60A |
| cutting material | lron/CS/SS/Aluminum/Copper and all kinds metal |
Clamping round tube 10-160 mm. Servo Motor and reducer are driven synchronously to enssure processing accurcay Both front and rear chucks are pneumatically tightened.
follow-up function Follow the change of theheight of the board , dont worry about the unevenness ofthe board affecting the cutting effect.
Customer can chose suitable laser source according to actual needs.
Brand:IPG,Raycus,MAX,Reci
Power:1500w,2000w,3000w,6000w.
1. The excellent performance of acceleration and deceleration: acceleration from -3000r/min to 3000r/min takes time 6-7ms.Long Service LifeCompact construction and low weight.
2. FUJI/Yaskawa for choose.
1. The installation accuracy of the guide rail and the rack is controlled at 0.03mm to ensure the smooth operation of the gantry, thereby ensuring the cutting accuracy.
2. APEX/YYC/J&T for choose.
The integrated bed frame ensures the agility of the chuck and the stability during high-speed driving. Pneumatic roller support avoids sagging and deformation of the pipe, improves cutting accuracy and extends the service life of the chuck.
Leading (Shandong) CNC Equipment Co., Ltd. is an intelligent manufacturing equipment manufacturer committed to intelligent equipment R&D, production, sales and international trade.Located in JiNan, Shandong, our company has independent bed riveting and welding workshop, machining workshop, sheet metal production workshop, spraying workshop and assembly and debugging workshop,covering an area of 20,000 square meters .
As a leading intelligent equipment manufacturer, we have established and maintained close cooperation with first-line accessory manufacturers such as IPG, Precede, Raycus, and Max for many years. Currently, Leading CNC Equipment Co., Ltd. has established long-term and stable relationships with intelligent equipment distributors in more than 20 countries around the world, such as Russia, Saudi Arabia, South Korean, Europe, Australia, South east Asia, Africa etc. with an annual export volume of more than 1,000 units.
Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world, We need your machines running in order to keep your business running.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–4 piece: US $15000 / piece
- 5+ piece: US $12000 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cnc fiber laser tube?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Leading (Shandong) CNC Equipment Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Leading (Shandong) CNC Equipment Co., Ltd. range on HVACR Nexus.
