Copper Wire Motor, 100mm, 50Hz, Ceiling, Wall

Key specification for this copper wire motor: 220 V, material Metal. Everything below is reproduced from the factory data sheet. Made by Foshan City Nanhai Popula Fan Co., Ltd. (18 years on the platform, typical reply ≤7h). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Copper Wire Motor

• Model Number: FP 500
• Voltage: 220 V
• Material: Metal
• Blade Material: Metal
• Noise Level: 35–39 dB
• Warranty: 1 Year

Technical Specifications

Product Details

Products Description

Features:

The use of electrostatic removal of grease and
smoke makes it more efficient in purification and also eliminates odour functions. The rational structural design, based on the
principle of fluid mechanics, optimises the design of the main body of the purifier and reduces the wind resistance and noise of
the product.

PF-JD series electrostatic smoke purifier is an environmentally friendly product developed by our company in accordance with the relevant regulations and requirements of the National Environmental Protection Administration, which can effectively remove oil fumes, eliminate odours and thus purify the working environment and completely solve the problem of pollution transfer.

Model	Vol./Freq.	Power	Air volume	Noise	Static pressure	Filteration Efficiency	Duct size	Demesion L*W*H (mm)	NET.Gross
		(V/Hz)	(W)	(m3/h)	(dB)	(Pa)	%	(Φmm)	mm	(kg)
FP150	220/50	40	150/120	24	150	＞95	100	375*326*120	6.8
FP250			50	250/200	32	180	＞95	150	375*326*185	7.5
FP350			70	350/300	34	200	＞95	150	375*326*185	8.5
FP500			150	500/450	35	240	＞95	200	375*326*235	9.8
FP650			160	650/550	36	240	＞95	200	375*326*235	9.8
FP800			180	800/700	39	260	＞95	200	433*419*280	11.5
FP1000			300	1000/900	41	320	＞95	200	505*419*300	17
FP1200			330	1200/1050	42	350	＞95	250	505*419*300	17.5
FP1500			360	1500/1300	45	380	＞95	250	560*502*340	24
FP2000			480	2000/1700	48	390	＞95	250	560*502*340	24.5

Usage Area
:This series of fans are specially used for oil fume purification in the kitchen of hotels, restaurants or canteens. However, it
is strictly prohibited to be used for purifying the air that is inflammable, explosive, volatile and corrosive, or black smoke produced by diesel while burning.

Ordering and Pricing

• Minimum order quantity: 10 unit
• Volume pricing:
  • 10+ unit: US $251 / unit
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this copper wire motor?

The standard minimum order quantity is 10 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Which certifications does this copper wire motor carry?

It is supplied with ce/GCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.

Can the copper wire motor be supplied for my local voltage?

The standard configuration is 220 V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Foshan City Nanhai Popula Fan Co., Ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Foshan City Nanhai Popula Fan Co., Ltd. range on HVACR Nexus.

See more in Metal Duct Fans on HVACR Nexus.
