This custom chilled water coil is published with the manufacturer’s full specification — material Stainless Steel, Aluminum Alloy, Copper, heat exchanger type finned tube heat exchanger. Made by Shenzhen Hylita Heat Exchanger Co., Ltd. (4 years on the platform, typical reply ≤3h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Custom Chilled Water Coil
- Material: Stainless Steel, Aluminum Alloy, Copper
- Tube Material: Copper, CuNi, Stainless steel, Aluminium, Hot dip steel, Titanium
- Fin Material: Copper, CuNi, Stainless steel, Aluminium, Hot dip steel, Titanium
- Frame Material: Stainless Steel, GI plate, Aluminum plate
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
Technical Specifications
| Heat Exchanger Type | finned tube heat exchanger |
|---|---|
| Fluid Compatibility | Oil, Water, Steam, Refrigerant |
| Material | Stainless Steel, Aluminum Alloy, Copper |
| Core Components | Fin, Tube |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 200 |
| Brand Name | Hylita |
| Liquid Flow Rate | 0.1~10 M/s |
| Maximum Pressure Rating | 40bar |
| Dimension(L*W*H) | Customize |
| Type | Fin Tube Condenser Evaporator Coils |
| Application | Heating and Cooling |
| Product Name | Stainless Cooling Coil Air Evaporator |
| Tube Material | Copper, CuNi, Stainless steel, Aluminium, Hot dip steel, Titanium |
| Fin Material | Copper, CuNi, Stainless steel, Aluminium, Hot dip steel, Titanium |
| Tube Type | Smooth, Grooved |
| Fin Type | flat, corrugated, louvered |
| Frame Material | Stainless Steel, GI plate, Aluminum plate |
| Fin Surface | Epoxy (gold), Blue (hydrophilic), Powder paint, Bare |
| Usage | Refrigeration Equipment |
| Selling Units | Single item |
| Single Package Size | 140X45X80 cm |
| Single Gross Weight | 220.0 kg |
