The door panel listed here carries 1000W, refrigerant R134a, documented exactly as the manufacturer publishes it. Made by Chengdu Hop Technology Co., Ltd. (13 years on the platform, typical reply ≤1h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Door Panel
- Cooling Capacity: 1000W
- Refrigerant: R134a
- Warranty: 1 Year
- Place Of Origin: Sichuan, China
- Application: Plant, Telecom
- Type: Cabinet Air Conditioner
Technical Specifications
| Type | Cabinet Air Conditioner |
|---|---|
| Refrigerant | R134a |
| Mounting Type | Door Mounted |
| Compressor Brand | Other |
| Fan Motors Type | AC |
| Application | Plant, Telecom |
| Key Selling Points | Long Service Life |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Pressure Vessel, Motor, Bearing, Gear, PLC, Pump, Engine, Gearbox |
| Place Of Origin | Sichuan, China |
| Weight (Kg) | 25 |
| Brand Name | HOP |
| Dimension(L*W*H) | 746*446*200 |
| Cooling Capacity | 1000W |
| Rated Frequency | 50Hz |
| Working Temperature Ranger | -40℃~+55℃ |
| Weight | 25KG |
| Noise | 62dB(A) |
| After-Sales Service | 1 year |
| After-Sales Service Provided | Online support |
| Selling Units | Single item |
| Single Package Size | 56X26X86 cm |
| Single Gross Weight | 27.000 kg |
Product Details
Model number | AC1000 Cabinet air conditioner |
Power supply | AC187V~253V，50Hz |
Cooling capacity(W) | 1000 |
Heating capacity(W)(Optional) | 1000 |
Power consumption(W) | 320 |
Range of working temperature(℃) | -40 ~+55 |
Running current (A) | Cooling : 2.2 Heating : 7.0 |
Starting current (A) | Soft start-up |
Dimension without flange(mm) | 746*446*200 |
Refrigerant type | R134a |
IP level | IP 55 |
Noise level (dB) | 62 |
Weight (Kg) | 25KG |
Installation | Door mounted (Embedding slightly) |
Certification | CE |
Ambient set temperature (℃) | 20~40 |
Temperature control mode | Digital display thermostat |
1. 2 years: The design of each model can be sold overseas only after a 2-year test period.
2. 0.2% failure rate: we can guarantee that the product failure rate does not exceed 0.2%.
3. 8 quality inspections: We have the largest and most cabinet air-conditioning quality inspection center in China. Warmly welcome you to visit our factory.
4. 5 product certificates: CE, RoHS, Intertek, IOS and IAF.
A: Yes, we can provide air conditioning accessories for later maintenance.
Q: How long is the warranty period？
A: Usually we guarantee the warranty 12-18 months accordingly，our product failure rate does not exceed 0.2% .
Q: Can you provide OEM service？
A: Yes, we can customize the product color, logo, outer packaging according to your requirements.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–10 set: US $259 / set
- 11–50 set: US $250 / set
- 51–100 set: US $245 / set
- 101+ set: US $240 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this door panel?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Chengdu Hop Technology Co., Ltd., based in China. The company 13 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Chengdu Hop Technology Co., Ltd. range on HVACR Nexus.
