Duct inline garden extractor — 110v 220v, blade material Plastic. The complete factory specification follows. Made by Taizhou Defeng Mechanical And Electrical Co., Ltd. (12 years on the platform, typical reply ≤7h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Duct Inline Garden Extractor
- Voltage: 110v 220v
- Blade Material: Plastic
- Warranty: 2 Years
- Certification: CE ETL
- Place Of Origin: Zhejiang, China
- Application: Exhaust Ventilation
Technical Specifications
| Mounting | Duct Fan |
|---|---|
| Voltage | 110v 220v |
| Blade Material | Plastic |
| Warranty | 2 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM |
| Place Of Origin | Zhejiang, China |
| Brand Name | FENGDA |
| Color | Black/white |
| Plug | American Plug,European Plug |
| Operation | distant control |
| Application | Exhaust Ventilation |
| Motor | 100% Copper Wire |
| Certification | CE ETL |
| Selling Units | Single item |
| Single Package Size | 33.5X26.3X27 cm |
| Single Gross Weight | 5.0 kg |
Product Details
Low noise mixed flow inline bathroom trade assruance corvered Extractor Fan Round Duct Fan
1, Fan diameter : 100mm to 200mm.
2, The voltage :110-120V/60Hz ,220-240V/50Hz according to customer's requirements.
3,Color:Black and White
4,Operating temperture rage:-20℃~60℃
5,Long life with low energy consumption
| Model | Voltage (V) | Frequency (Hz) | Current (A) | Power (W) | Speed (RPM) | Air Flow (m³/h) | Pressure (Pa) | Noise (dB) |
| GDFP100 | 220-240 | 50 | 0.12 | 26 | 2200 | 198 | 156 | 31 |
| 110-120 | 60 | 0.26 | 30 | 2500 | 220 | 160 | 31 | |
| GDFP125 | 220-240 | 50 | 0.14 | 33 | 2250 | 284 | 159 | 32 |
| 110-120 | 60 | 0.30 | 40 | 2500 | 310 | 165 | 32 | |
| GDFP150 | 220-240 | 50 | 0.26 | 60 | 2300 | 530 | 300 | 33 |
| 110-120 | 60 | 0.61 | 70 | 2500 | 580 | 350 | 33 | |
| GDFP200 | 220-240 | 50 | 0.40 | 130 | 2250 | 900 | 380 | 43 |
| 110-120 | 60 | 0.85 | 150 | 2500 | 1000 | 430 | 43 |
| Model | A | B | C | ΦD | E | F | G | H |
| GDFP100 | 295 | 170 | 80 | 96 | 204 | 111 | 103 | 60 |
| GDFP125 | 295 | 170 | 80 | 122 | 204 | 111 | 103 | 60 |
| GDFP150 | 295 | 194 | 80 | 148 | 230 | 126 | 122 | 60 |
| GDFP200 | 307 | 203 | 100 | 197 | 240 | 138 | 138 | 75 |
FENGDA was establish in 1990,covering an area of 17,000 square meters,more than 200 employes.We professionally manufacture various fans and motors,which widely used in Ventilation,air condittion,air condition,cooling and heating industry.
We have gotten CE,UL,CCC certificates and ISO9001 Quality Management System Certification.nd our products are exporting to Europe and America,Middle East,Russia etc.
1.Warranty:1 year warranty for all products.
2.Products Quality:100% products inspection before delivery.
3.Just in time delivery: Normally,lead time is 30 days.
4.Customized Service: As we have our own molding department,customized service can be provided.
5.Prompt customers services:E-mail will be replied in 24 hours.
1. Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
2. Q: Could FENGDA provide technology support?
A: We're in this field many years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does FENGDA keep goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
4. Q: Could you fill the invoice for customs as our requirement?
A: Yes, if there's any requirement for it, please tell us. We'll do it.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $45.9 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this duct inline garden extractor?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this duct inline garden extractor carry?
It is supplied with CE ETL documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the duct inline garden extractor be supplied for my local voltage?
The standard configuration is 110v 220v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
