Key specification for this ec motors: 72V, 72V PMSM motor&MCU&VCU. Everything below is reproduced from the factory data sheet. Made by Shanghai Goldgun M&E Hi-Tech Co., Ltd. (4 years on the platform, typical reply ≤6h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of These Ec Motors
- Rated Power: 10kw
- Peak Power: 20kw
- Voltage: 72V
- Voltage Range: 50v-90v
- Speed(RPM): 2730-7000rpm
- Rated Speed: 2730rpm
Technical Specifications
| Voltage | 72V |
|---|---|
| Speed(RPM) | 2730-7000rpm |
| Type | 72V PMSM motor&MCU&VCU |
| Condition | New |
| Purpose | Sightseeing and special vehicles |
| Place Of Origin | Shanghai, China |
| Weight | 24kg |
| Overall Dimentions | 143/205/110mm |
| Voltage Range | 50v-90v |
| Rated Speed | 2730rpm |
| Torque | 100Nm |
| Protection Grade | IP67 |
| Motor Cooling Method | wind cooling |
| Rated Power | 10kw |
| Peak Power | 20kw |
| Selling Units | Single item |
| Single Package Size | 55X45X45 cm |
| Single Gross Weight | 30.000 kg |
Product Details
Product model | TZ180XS015-1 | ||
Rated voltage (VDC) | 292 | Cooling method | Water cooling |
Rated power (kW) | 22 | Back EMF (Vpeak) | 503v@9700rpm |
Rated torque(Nm) | 70 | Peak power(KW) | 57 |
Rated speed (rpm) | 3000 | Peak torque (Nm) | 150 |
Insulation class | H | Maximum speed (rpm) | 9700 |
Dimensions (mm) | φ221*L277 | Protection level | IP67 |
Weight (kg) | 34kg | Peak current (Arms) | 230 |
Product model | TZ180XS015-2 | ||
Rated voltage (VDC) | 336 | Cooling method | Water cooling |
Rated power (kW) | 18 | Back EMF (Vpeak) | 540@1000rpm |
Rated torque (Nm) | 60 | Peak power (kW) | 60 |
Rated speed (rpm) | 2850 | Peak torque (Nm) | 145 |
Insulation class | H | Maximum speed (rpm) | 9000 |
Dimensions (mm) | φ210*L293 | Protection level | IP67 |
Weight (kg) | 34kg | Peak current (Arms) | 200 |
A1: A company integrated with factory and trade.
A2: For urgent order and light weight, you can choose the following express: UPS, FedEx, TNT,DHL, EMS. For heavy weight, you can choose to deliver the goods by air or by sea to save cost.
A3: We accept T/T, L/C for big amount, and for small amount, you can pay us by PayPal, Western Union, and etc.
A4: It depends on seasons. Fee is different in different seasons. You can consult us at all times.
A5: Usually we produce within 25-60days after the payment confirmed. If you are urgent, we will urge the production department for you.
Ordering and Pricing
- Minimum order quantity: 2 piece
- Volume pricing:
- 2–99 piece: US $1590 / piece
- 100+ piece: US $1400 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this ec motors?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the ec motors be supplied for my local voltage?
The standard configuration is 72V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shanghai Goldgun M&E Hi-Tech Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, Trading Company. Browse the full Shanghai Goldgun M&E Hi-Tech Co., Ltd. range on HVACR Nexus.
