The floor ceiling air conditioner listed here carries power supply 220-240V~/50Hz/1P, capacity 30000, documented exactly as the manufacturer publishes it. Made by Foshan Weltec Electrical Appliance Co., Ltd. (1 year on the platform, typical reply ≤8h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Floor Ceiling Air Conditioner
- Model Number: R410A-4PZD-30K
- Power Type: AC
- Power Source: Electric
- Power (W): 8790KW
- Power Supply: 220-240V~/50Hz/1P
- Rated Cooling Power Input: 2800KW
Technical Specifications
| Application | Commercial |
|---|---|
| Capacity (Btu) | 30000 |
| Cooling/Heating | Cooling Only |
| Refrigerant | R410 |
| Fixed Frequency/Variable Frequency | Fixed Frequency |
| Recommended Room Size（Square Feet） | up to 298 sq. ft |
| Eer | 2-4 |
| Feature | Energy Saving |
| Warranty | 1 Year |
| After-Sales Service Provided | 1 Year (Unit), 2 Years (PCB), 5 Years (Compressor) |
| Power Type | AC |
| App-Controlled | Yes |
| Remote Control | Yes |
| Timer | Yes |
| Operating Language | English |
| Power Source | Electric |
| Packaging Types | Corrugated Box |
| Place Of Origin | Guangdong, China |
| Brand Name | AKAI |
| Power (W) | 8790KW |
| Model Number | R410A-4PZD-30K |
| Power Supply | 220-240V~/50Hz/1P |
| Rated Cooling Power Input | 2800KW |
| Rated Cooling Current | 14A |
| Indoor Air Flow(Hi/Mi/Lo) | 1600/1300/1100m³/h |
| Wired/Remote Controller | Remote control |
| Service | OEM/ODM |
| Function | Quiet operation, healthy filters, comfort cooling |
| Selling Units | Single item |
| Single Package Size | 135X74.8X30.5 cm |
| Single Gross Weight | 35.000 kg |
Product Details
Items | Ceiling&floor Indoor | ||||||||||||
Model | 24K | 30K | 36K | 48K | 60K | ||||||||
Power supply side | / | Outdoor | Outdoor | Indoor & Outdoor | Indoor & Outdoor | Indoor & Outdoor | |||||||
IDU Power Supply | V~,Hz,Ph | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | |||||||
Capacity | Cooling | Btu/h | 24000 | 30000 | 36000 | 48000 | 55000 | ||||||
KW | 7030 | 8790 | 10548 | 14064 | 16115 | ||||||||
Electric Data（T1） | Rated Cooling Power Input | KW | 2000 | 2800 | 3600 | 4200 | 5500 | ||||||
Rated Cooling Current | A | 8.8 | 14 | 7 | 7.7 | 10 | |||||||
Performance（T1） | EER | W/W | 3.52 | 3.14 | 2.93 | 3.35 | 2.93 | ||||||
Indoor Unit | Indoor Air Flow(Hi/Mi/Lo) | m³/h | 1200/1100/1000 | 1600/1300/1100 | 1600/1300/1100 | 1950/1700/1450 | 1950/1700/1450 | ||||||
Indoor sound power(S/H/M/L/Mute) | dB(A) | / | / | / | / | / | |||||||
Net Dimension(W*D*H) | mm | 1055×675×235 | 1275×675×235 | 1275×675×235 | 1635×675×235 | 1635×675×235 | |||||||
Packing Dimension(W*D*H) | mm | 1130×748×305 | 1350×748×305 | 1350×748×305 | 1710×748×305 | 1710×748×305 | |||||||
Net Weight | Kg | 25 | 29 | 29 | 38 | 38 | |||||||
Gross Weight | Kg | 30 | 35 | 35 | 44 | 44 | |||||||
Refrigerant Pipe | Gas Side | mm | 9.52 (3/8) | 9.52 (3/8) | 9.52 (3/8) | 9.52 (3/8) | 9.52 (3/8) | ||||||
Liquid Side | mm | 15.88 (5/8) | 15.88 (5/8) | 15.88 (5/8) | 19.05 (3/4) | 19.05 (3/4) | |||||||
Operation Temperature Range | ℃ | 16～31 | 16～31 | 16～31 | 16～31 | 16～31 | |||||||
Wired/Remote Controller | / | Remote controller | Remote controller | Remote controller | Remote controller | Remote controller | |||||||
IDU Qty’per 40HQ (Only For Reference) | Set | 248 | 200 | 200 | 160 | 160 | |||||||
IDU+ODU Qty’per 40HQ (Only For Reference) | Set | 114 | 87 | 82 | 57 | 57 | |||||||
Ordering and Pricing
- Minimum order quantity: 20 set
- Volume pricing:
- 20–49 set: US $592.55 / set
- 50–99 set: US $562.55 / set
- 100–499 set: US $532.55 / set
- 500+ set: US $502.55 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this floor ceiling air conditioner?
The standard minimum order quantity is 20 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the floor ceiling air conditioner be supplied for my local voltage?
The standard configuration is 220-240V~/50Hz/1P. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
