Key specification for this high-quality pvc duct fan: 120V/60Hz, power input AC 110/230V. Everything below is reproduced from the factory data sheet. Made by Ningbo Longwell Electric Technology Co., Ltd. (9 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This High-Quality Pvc Duct Fan
- Model Number: LWID 4” ~ 12”
- Power Input: AC 110/230V
- Voltage: 120V/60Hz
- Blade Material: Plastic
- Pasing Material: plastic
- Impeller Material: Propylene with glass fiber reinforced
Technical Specifications
| Voltage | 120V/60Hz |
|---|---|
| Blade Material | Plastic |
| Mounting | Duct Fan |
| Electric Current Type | AC |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Zhejiang, China |
| Brand Name | LONGWELL |
| Model Number | LWID 4” ~ 12” |
| Type | grow tent fan |
| Power Input | AC 110/230V |
| Pasing Material | plastic |
| Impeller Material | Propylene with glass fiber reinforced |
| Direction | Clockwise |
| Bearing | Ball Bearing |
| Amb,Temp | -30 to +60℃ |
| Insulation | B/F |
| Application | Grow tent,greenhouse,exhaustor |
| Selling Units | Single item |
| Single Package Size | 18X18X21 cm |
| Single Gross Weight | 4.0 kg |
Product Details
Types : | High-Quality PVC Duct Fan with Ball Bearing Motor and Safety Design Suitable for duct mount in suspended ceiling |
Voltage Ranges : | 220V |
Frequency : | 50/60 Hz |
Diamter : | 100-150mm ( impeller diameters ) |
Motor Types : | BLEC External Rotor Motor |
Speed Control : | 0-10V Signal / PWM / RS485(Optional) |
Max.ambient Temp: | -25℃～ +60℃ |
Certificating : | All necessary certifications suitable for USA & Europe , ETL,UL ,CE ,RoHS, ISO19001,ISO 14001,BSCI |
Protection Level: | IP44 ,IP54,IP55 |
Electronic Protection: | Current limiting protection ,Over-temperature protection,Over-current protection,Locked-rotor protection,Soft start |
Working & Storage | Operating temperature：-25~60℃；Operating humidity：0 ~ 85 % RH Storing temperature：-25 ~ 70℃；Storing humidity：0 ~ 95 % RH Applicable altitude range：＜1000m |
Balancing | According to JB/T 9101-1999 requirements G6.3 |
Product Standards : | LVD EN60950-1 EMC EN61000-6-3,EN61000-4-2, EN61000-4-3 |
Mainly Applications | AUH/ AIR PURIFIER / Server Cooling & Ventilation / Grow Tent /Ventilation SYSTEM/ Equipments Cooling /Refrigerator ,etc;ventilation fan cooling;ventilation exhaust fans |
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–299 piece: US $40 / piece
- 300+ piece: US $35 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this high-quality pvc duct fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the high-quality pvc duct fan be supplied for my local voltage?
The standard configuration is 120V/60Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Ningbo Longwell Electric Technology Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Ningbo Longwell Electric Technology Co., Ltd. range on HVACR Nexus.
