Key specification for this hl-2000 laser water chiller: 220 V, 2000 W. Everything below is reproduced from the factory data sheet. Made by Tang Cheng International Trade Co., Ltd. (9 years on the platform, typical reply ≤4h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Hl-2000 Laser Water Chiller
- Power: 2000 W
- Voltage: 220 V
- Refrigerant: R-410A
- Warranty: 1 Year
- Place Of Origin: Jiangsu, China
- Pump Type: Gear Pump
Technical Specifications
| Voltage | 220 V |
|---|---|
| Power | 2000 W |
| Refrigerant | R-410A |
| Pump Type | Gear Pump |
| Warranty | 1 Year |
| Machinery Test Report | Not Available |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Easy To Operate |
| Core Components | Engine |
| Container Volume | 13L |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 70 |
| Brand Name | HANLI |
| Dimension(L*W*H) | 530x480x760 |
| Working Temperature Range | 0-40℃ |
| Selling Units | Single item |
| Single Package Size | 100X100X100 cm |
| Single Gross Weight | 75.0 kg |
Product Details
should be installed in the place where are better air venting and better heat radiation effect, shown as the picture, need keep 1m
space around the machine set, can't have baffle object and the heat radiation port should keep 1m space. The height on the machine need above 3m.
The equipment use environment 0℃~40℃, used water temperature 21℃~30℃. Please contact us if have special requirements.
NO. | Model | Unit | Parameter | |
1 | Type | HL-2000-QG2/2 | ||
2 | Power system | 220V/AC±10% 50Hz | ||
3 | Power rating | kW | 2.8 | |
4 | Maximum current | A | 12.7 | |
5 | Nominal horse-power | HP | 2 | |
6 | Compressor power | kW | 1.32 | |
7 | Electric heating power | kW | 0.9 | |
8 | Pumping power | kW | 0.48 | |
9 | Fan power | kW | 0.1 | |
10 | The maximum air volume of the fan | m3/h | 1920 | |
11 | Rated flow rate at the low-temperature end | L/min | 22-24 | |
12 | Rated pressure at the low-temperature end | bar | 3 | |
13 | Maximum pressure at the low-temperature end | bar | 4.2 | |
14 | Low-temperature end interface size | G1/2-16mm quick connector | ||
15 | The water temperature range at the low-temperature end | ℃ | 21~32 | |
16 | Rated flow rate at the high-temperature end | L/min | 1.3 | |
17 | Rated pressure at the high-temperature end | bar | 3 | |
18 | High-temperature end interface size | G1/2-10mm quick connector | ||
19 | The water temperature range at the high-temperature end | ℃ | 26-35 | |
20 | Water temperature control accuracy | ℃ | 1 | |
21 | Water tank volume | L | 13 | |
22 | Ambient temperature | ℃ | 5-40 | |
23 | Refrigerant | R32 | ||
24 | Equipment appearance color | Orange grain white | ||
25 | Equipment operation noise | dB(A) | =65 | |
26 | Net weight | kg | 41 | |
27 | Machine size | mm | 530x480x760 | |
28 | Rough weight | kg | 50 | |
29 | Packing measurement | mm | 675x525x800 | |
30 | Suitable cooling medium | Purified water; ethylene glycol solution with a concentration of ≤30% | ||
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $547.2 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this hl-2000 laser water chiller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the hl-2000 laser water chiller be supplied for my local voltage?
The standard configuration is 220 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
