Hybrid solar air conditioner — power supply 20~50V DC/200-240V/50Hz 60Hz, 4000BTU-24000BTU. The complete factory specification follows. Made by Guangdong Tunto Green Power Technology Co., Limited (14 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Hybrid Solar Air Conditioner
- Model Number: T2(R)-11Y/DC
- Solar Power (W): 500W-1500W
- Power Source: Solar+electricity
- Power Supply: 20~50V DC/200-240V/50Hz 60Hz
- Capacity (BTU): 4000BTU-24000BTU
- Cooling Capacity: 4000-24000 Btu
Technical Specifications
| Cooling/Heating | Cool/Cool&Heat |
|---|---|
| Application | Household |
| Capacity (BTU) | 4000BTU-24000BTU |
| Place Of Origin | Guangdong, China |
| Brand Name | TUNTO Solar power |
| Model Number | T2(R)-11Y/DC |
| Solar Power (W) | 500W-1500W |
| EER | 5 |
| COP | 3.8 |
| Product Name | Solar Powered Window type Air Conditioner |
| Power Source | Solar+electricity |
| Type | Window type Air Conditioner |
| Solar Panel | 1~8Pcs 300-550W Solar Panel |
| Power Supply | 20~50V DC/200-240V/50Hz 60Hz |
| Cooling Capacity | 4000-24000 Btu |
| Compressor | Famous Brand Rotary Compressor |
| Warranty | 5 Years |
| Refrigerant | R134A |
| Selling Units | Single item |
| Single Package Size | 55X65X45 cm |
| Single Gross Weight | 30.0 kg |
Product Details
Product Introduction: TUNTO SOLAR POWER 24/48V DC Off-Grid Window-Type Air Conditioners & AC/DC Hybrid Window-Type Air Conditioners (4,000 BTU – 24,000 BTU)
Overview: Introducing our state-of-the-art 24/48V VDC off-grid window-type air conditioners and AC/DC hybrid window-type air conditioners, designed to provide efficient and sustainable cooling solutions for various applications. Available in capacities ranging from 4,000 BTU to 24,000 BTU, these units are perfect for homes, offices, and remote locations.
Key Features:
Energy Efficient: Our air conditioners utilize advanced technology to maximize cooling efficiency while minimizing energy consumption. The 24/48V VDC models are designed specifically for off-grid applications, harnessing solar energy for sustainable operation.
Versatile Hybrid Functionality: The AC/DC hybrid models offer the flexibility to operate on both solar power and traditional AC power, ensuring reliable cooling in any situation. Switch seamlessly between power sources as needed!
Eco-Friendly: By utilizing renewable energy, our air conditioners help reduce your carbon footprint and contribute to a cleaner environment, making them an ideal choice for eco-conscious consumers.
Easy Installation: Designed for window installation, these units can be easily integrated into most spaces. The compact design ensures a perfect fit while maintaining aesthetic appeal.
Wide Application: Suitable for residential, commercial, and recreational use, our air conditioners are ideal for cabins, RVs, small businesses, and more. Enjoy comfort in any setting!
Specifications:
· Cooling Capacity: 4,000 BTU to 24,000 BTU
· Voltage Options: 24V and 48V DC
· Type: Off-grid VDC and AC/DC Hybrid
· Installation: Window-type design for easy setup
Product SPECS:
| Remote control | 4000BTU | 9000BTU / 0.75Ton | 12000BTU / 1Ton-15000BTU /1.25TON | 18000BTU / 1.5Ton-24000BTU /2TON | ||||
| BTU | 0.3TON | 6000BTU | 9000BTU | 12000BTU | 15000BTU | 18000BTU | 24000BTU | |
| Model | T2(R)-11Y/DC | T2(R)-17Y/DC | T2(R)-25Y/DC | T2(R)-35Y/DC | T2(R)-45Y/DC | T2(R)-52Y/DC | T2(R)-72Y/DC | |
| Power Supply | DC12V/24V | DC12V/24V | DC24V/48V | DC48V | DC48V | DC48V | DC48V | |
| Refrigerant | R134A | R134A | R134A | R134A | R134A | R134A | R134A | |
| Capacity | 1100W/4000BTU | 1700W/6000BTU | 2500W/9000BTU | 3500W/12000BTU | 4000W/14000BTU | 5000W18000BTU | 7200W/24000BTU | |
| lnput Power | Cooling | 250W | 350W | 500W | 750W | 900W | 1000W | 1500W |
| Heating | 200W | 300W | 470W | 730W | 880W | 1100W | 1460W | |
| Currency (Amp) | Cooling | 5.1A | 7.3A | 11.1A | 15.6A | 18.5A | 19.6A | 31.5A |
| Heating | 4.5A | 6.5A | 10.8A | 14.8A | 18.3A | 19.8A | 28.3A | |
| EER | 4.85 | 4.85 | 4.88 | 4.79 | 4.75 | 4.79 | 4.75 | |
| Air flow (m3/hour) | 350 | 350 | 390 | 450 | 520 | 520 | 900 | |
| Noise(dBA) | 52-55 | 52-55 | 52-55 | 54-58 | 56-60 | 58-65 | 60-65 | |
| Weight ( Net/Gross ) | 28kg/30kg | 30kg/32kg | 31kg/33kg | 42kg/44kg | 45kg/47kg | 48kg/50kg | 52kg/55kg | |
| Product Dimension | 450*540*350mm | 450*540*350mm | 450*540*350mm | 560*650*400mm | 560*650*400mm | 560*1100*400mm | 670*1100*455mm | |
| Package Dimension | 550*620*440mm | 550*620*440mm | 550*620*440mm | 620*700*445mm | 620*715*445mm | 620*1180*445mm | 730*1180*500mm | |
| Quantity(20ft/40HQ)/pcs | 200/500 | 200/500 | 200/500 | 110/340 | 110/340 | 90/230 | 70/160 | |
Ordering and Pricing
- Minimum order quantity: 2 unit
- Volume pricing:
- 2+ unit: US $399 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this hybrid solar air conditioner?
The standard minimum order quantity is 2 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 5 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the hybrid solar air conditioner be supplied for my local voltage?
The standard configuration is 20~50V DC/200-240V/50Hz 60Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangdong Tunto Green Power Technology Co., Limited, based in China. The company 14 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Guangdong Tunto Green Power Technology Co., Limited range on HVACR Nexus.
