This impeller is published with the manufacturer’s full specification — 12V/24V/48V, 820m3/h. Made by Dongguan Kuhong Electronics Co., Ltd. (8 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Impeller
- Model Number: CM601300-LL
- Voltage: 12V/24V/48V
- Air Flow: 820m3/h
- Blade Material: Aluminum Alloy
- Material: Steel , Aluminum Alloy
- Speed: 1800rpm
Technical Specifications
| Voltage | 12V/24V/48V |
|---|---|
| Speed | 1800rpm |
| Mounting | Duct Fan |
| Blade Material | Aluminum Alloy |
| Material | Steel , Aluminum Alloy |
| Customized Support | OEM |
| After-Sales Service Provided | Online support |
| Warranty | 1 Year |
| Place Of Origin | Guangdong, China |
| Brand Name | COOLCOM |
| Model Number | CM601300-LL |
| Product Name | Tangential Fan |
| Bearing Type | NMB Ball Bearing |
| Noise | 54DBA |
| Application | Heater |
| Certification | CCC/CE/ISO9001 |
| Motor | 3phase Dc Brushless Motor |
| Item Name | Cross Flow Fan/impeller 60mm |
| OEM /ODM | Acceptable |
| Air Flow | 820m3/h |
| Selling Units | Single item |
| Single Package Size | 120X15X15 cm |
| Single Gross Weight | 3.0 kg |
Product Details
| MODEL | SIZE(MM) | BEARING TYPE | RATED VOLTAGE(V) | CURRENT(A) | SPEED(RPM) | AIR FLOW(M3/H) | PRESSURE(PA) | NOISE(DB) | WEIGHT/BLOWER |
|---|---|---|---|---|---|---|---|---|---|
| CM60520HB24-LL | A=600 B=535 C=520 | NMB ball | 24V | 0.6A | 1800RPM | 330m3/h | 50Pa | 47dBA | 2.2kg/Single |
| CM60610HB24-LL | A=690 B=625 C=610 | NMB ball | 24V | 0.6A | 1800RPM | 380m3/h | 50Pa | 47dBA | 2.3kg/Single |
| CM60640HB24-LL | A=720 B=655 C=640 | NMB ball | 24V | 0.7A | 1800RPM | 400m3/h | 52Pa | 48dBA | 2.4kg/Double |
| CM60700HB24-LL | A=780 B=715 C=700 | NMB ball | 24V | 0.7A | 1800RPM | 440m3/h | 52Pa | 48dBA | 2.5kg/Double |
| CM60750HB24-LL | A=830 B=765 C=750 | NMB ball | 24V | 0.8A | 1800RPM | 470m3/h | 52Pa | 48dBA | 2.6kg/Double |
| CM60870HB24-LL | A=950 B=885 C=870 | NMB ball | 24V | 1.0A | 1800RPM | 550m3/h | 52Pa | 49dBA | 2.7kg/Double |
| CM601100HB24-LL | A=1185 B=1120 C=1105 | NMB ball | 24V | 1.5A | 1800RPM | 630m3/h | 60Pa | 52dBA | 2.75kg/Triple |
| CM601300HB24-LL | A=1385 B=1320 C=1305 | NMB ball | 24V | 2.2A | 1800RPM | 820m3/h | 60Pa | 54dBA | 2.8kg/Triple |
| Blade Material | Aluminum Alloy |
| voltage | 12V/24V/48V |
| mounting | cross flow fan blower free mounting |
| speed | 1800RPM |
| air flow | 820m3/h |
| customized support | OEM ODM |
| place of origin | China |
| brand name | coolcom |
| warranty | 1 Year |
| After-sales Service Provided | Online support |
| Material | Steel, Aluminum Alloy |
1.The DC Cross Flow Fan Blower is a user-friendly, high-quality fan designed for the Energy & Mining industry. It is available with a blade material of Stainless Steel, ensuring durability and functionality.
2.This efficient fan provides top-notch performance, with a speed of 1800rpm, enabling effective cooling in various applications. It is suitable for use in demanding environments, offering reliable operation.
3.The DC Cross Flow Fan Blower comes with several customization options, including customized support in the form of OEM services. This allows customers to tailor their fan solutions to meet their specific needs.
4.With a warranty period of 1 Year, Motor-blower.com is committed to providing their customers with peace of mind. They offer both online support and 24/7 after-sales support through their dedicated technical team.
Based in 2011, DONGGUAN KUHONG ELECTRONICS CO.,LTD is a distinguished manufacturer of cross flow fans, centrifugal fans, pipeline fans, brushless dc motors, and EC motors. Promoting our own branded product, 'COOLCOM FAN', we provide full support for OEM&ODM. The products are widely utilized in HVAC, ventilation, heating, air conditioning&refrigeration, home appliance, and varied industries.
Our company has a strong R&D and engineering team with 16 years' expertise, developing and implementing product designs independently. We offer tailored, customized solutions to meet each client's unique requirements. Our extensive experience and more than 1,000 varied product ranges and engineering solutions cater to clients around the world.
At COOLCOM FAN, our priority is to satisfy customers with our top-notch service, flexible pricing, and high-quality products. Our ISO9001 certified factory complies with the CE, RSH, EMC, and LVD standards. Our company is an energetic blend of young and dedicated engineers and sales staff, continuously striving to develop innovative, quieter, stronger, and more durable motor and fan products.
COOLCOM FAN: Your trusted partner for advanced motor and fan solutions. We're here to support your inquiries and provide customized solutions on motor and fan products. Connect with us today!
We are based in Guangdong, China, start from 2019,sell to Domestic Market(40.00%),North America(20.00%).
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
cross flow fan,centrifugal fan,ec fan,axial fan,dc motor
4. why should you buy from us not from other suppliers?
we had 16 years RD,manufacture and sales experience, we committed to support customer with high quality product,value-base price and flexible service! our service and quality are top-notch,It's our belief that the margin and our quality will make you happy
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW;
Accepted Payment Currency: USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,PayPal;
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–499 piece: US $144 / piece
- 500–999 piece: US $98 / piece
- 1000+ piece: US $96 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this impeller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this impeller carry?
It is supplied with CCC/CE/ISO9001 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the impeller be supplied for my local voltage?
The standard configuration is 12V/24V/48V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Dongguan Kuhong Electronics Co., Ltd., based in China. The company 8 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Dongguan Kuhong Electronics Co., Ltd. range on HVACR Nexus.
