Industrial Heat Pump, 304, Stainless, Steel

The industrial heat pump listed here carries 220 V, 380 V, capacity 2 ton/batch oven machine, documented exactly as the manufacturer publishes it. Made by Runxiang Machinery HK Co., Limited (1 year on the platform, typical reply ≤2h). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Industrial Heat Pump

• Model Number: Lerford
• Voltage: 220 V, 380 V
• Capacity: 2 ton/batch oven machine
• Material: Carbon Steel, SUS304, SUS304L, Stainless Steel
• Warranty: 1 Year
• Place Of Origin: Henan, China

Technical Specifications

Product Details

Product Description

Application

Raw material can be: powder, particle, crude drug, herbal medicine of Chinese traditional medicine,plaster, drinking agent, pill, packing bottle, pigment, dyestuff, de-watering vegetable, dried fruit slices, sausage, plastic, resin, electric component, baking varnish and etc.

Dried fruits like: apple, lemon, berry, banana, plantain chips, kiwi, figs, pear, peach, pineapple, mango, jujube, plums.
Dried vegetables like: mushroom, pepper, carrot, cabbage, red chilli, onion, tomato, potato, sweet potato, garlic, ginger, etc.
Dried nuts and seafood like: cashew nuts, walnuts, peanuts, sea cucumber, fish, sardines, shrimp, etc.

Working principle

Our heat pump dryer adopts soundproof, thermally stable axial flow fan and automatic temperature control system. When working, it is relatively quiet and does not produce noise that affects the health of workers. The automatic temperature control system can automatically set the time and temperature according to the different materials, making it more labor-saving. The entire circulation system is fully enclosed, which increases the drying efficiency of the tray dryer from 3-7% of traditional tray dryers to 35-45%, and the highest thermal efficiency can reach 50%. So, after technological advancements, our drying speed will be faster. Compared to other manufacturers' dryers, it saves more time and energy in the same amount of time.

Specification

Characteristic

1, Energy saving Adopt heat pump technology, absorb heat from air and recovery waste heat at the same time Adopt close dehumidify + circulating drying type, saving operating cost; 2, Exact control temperature and humidity The drying temperature can be easily controlled by PLC +Touch Screen control system. 3, Uniform drying By using the forced ventilation function, there are partition sheet and fan motors inside the drying chamber to make sure hot air cycle, so the raw materials can be dried evenly 4, The temperature: 10-75°C, Max 75°C, similar nature drying. 5, The baking plate dimensions and materials can customize as customer request. 6, Good drying quality. During drying, the material does not craze, does not distortions, non-discoloring, never degenerate, non-oxidize, drying completely, with good rehydration, keep nutrient content; 7, Safe and reliable operation Automatic intelligent control, 24-hour continuous drying; Without waste gas and waste heat pollution,low noise.

Model	RX-72RD-30L	RX-120RD-60L
Capacity	300-500kg/batch	600-1000kg/batch
Matching pallet	1000*800*20mm（10*10 hole）/30PCS	1000*800*20mm（10*10hole）/60PCS
Overall dimensions	3500x1040x2100mm	4310x1880x2430/7.5cm
Weight	600kg	900kg
Drying room	3300x1040x2100mm	4110*1880*2200mm
Dehydration rate (L/H)	10	16
Moisture discharge volume (L/H)	20	35
Rated temperature (℃)	75	75
Maximum temperature (℃)	80	80
Input power (KW)	4.8	6.3
Outdoor fan Power(KW) and Air volume (M3/H)	0.38/4500	0.38/4500
Internal fan Power(KW) and Air volume (M3/H)	0.25*6/2800*6	0.25*6/2800*6
Controller	7-inch touch screen programmable controller	7-inch touch screen programmable controller

Product Display

Drying time :
1. It will vary depending on different materials, moisture content, sugar content, local climate, etc. 2. Fruits can be dried whole or cut into slices, such as mangoes, papayas, kiwis, etc. Alternatively, they can be chopped after drying to make a paste or concentrated juice. 3. Dried fruits are widely used in the candy, baking, and confectionery industries. 4. Food manufacturers use dried fruits in various sauces, soups, marinades, puddings, etc. We will set different programs according to the different materials. Customers can tell us the specific materials before placing an order. We can achieve automation by inputting the program before packing and shipping.

Working principle

Drying principle of heat pump Dryer Machine :

The heat pump drying room utilizes the inverse Carnot principle to absorb heat from the air and transfer it into the room, thereby increasing the temperature of the drying room and cooperating with corresponding equipment to achieve material drying. The heat pump dryer consists of a circulation system consisting of a compressor, a heat exchanger (internal unit), a throttle, a heat absorber (external unit), a compressor, and other devices. The refrigerant circulates in the system under the action of the compressor. It completes the process of gas pressure rise and temperature rise (up to 100 ℃) inside the compressor. It enters the internal unit and releases high-temperature heat to heat the air in the drying room. At the same time, it is cooled and converted into a liquid state. When it runs to the external unit, the liquid state quickly absorbs heat and evaporates back into a gas state. At the same time, the temperature drops to minus 20 ℃ -30 ℃. At this time, the air around the heat absorber will continuously transfer heat to the refrigerant. The continuous circulation of refrigerant transfers heat from the air to the drying room and heats up the air temperature inside.

Pictures

Packaging

We will install and debug the machine before shipment. After receiving the machine, the client does not need to install them again. All machines will be packaged in professional export wooden boxes that are free from fumigation. We will also provide the packing list to the clients.

Company Profile

Established in 2006, Zhengzhou Runxiang Machinery Equipment Co.,ltd(Golden Machinery Equipment Co.,Limited) is one professional manufacturer integrating R&D,manufacturing and trading,we are committed to feed machine,pellet machine,hammer mill,grinder mill,briquette machine,snakc food extruder machine,coal process machine line,straw briquette machine line,food machine line,farming,agriculture equipments for years.We have 80 staff members and 16 technicians of research team. So we have more competitive strength,advanced processing technology and scientific management.And we are located in Zhengzhou city,Henan province,which is the business and economy center with easy transportation.Our international airport name is Zhengzhou Xinzheng International Airport. Our feature products:hammer mill,briquette machine,feed pellet machine,vegetable&fruit processing machine,snack machine,packing machine,farm agriculture machine,dryer machine and so on.Moreover, our products have attained ISO9000 Certificate. Taking "Sincerity makes trust, Quality wins market"as our business philosophy, Our company always put quality in the first place and meet our customers' needs by ensuring high quality products and the most professional services, Therefore, our products have been exported to almost the whole world and enjoyed a good reputation from our customer for years. We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success. Welcome everyone!

FAQ

1. who are we?
We are based in Henan, China, start from 2016,sell to Africa(30.00%),North America(20.00%),Western Europe(9.00%),Mid East(7.00%),Eastern Asia(6.00%),South America(6.00%),Oceania(5.00%),Southern Europe(5.00%),Northern Europe(5.00%),Southeast Asia(5.00%),South Asia(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Briquette Brick Machine Line, Farm Agriculture Machines, Vegetable Fruit Processing Machines, Nuts Processing Machines, Packing Machine Line

4. why should you buy from us not from other suppliers?
Established in 2006, Zhengzhou Runxiang Machinery Equipment Co.,ltd(Golden Machinery Equipment Co.,Limited) is one professional manufacturer integrating R&D,manufacturing and trading,Taking "Sincerity makes trust, Quality wins market"as our philosophy.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian etc.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1–4 set: US $4850 / set
  • 5–49 set: US $3999 / set
  • 50+ set: US $3580 / set
• Ships from: HK
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this industrial heat pump?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the industrial heat pump be supplied for my local voltage?

The standard configuration is 220 V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Runxiang Machinery HK Co., Limited. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Runxiang Machinery HK Co., Limited range on HVACR Nexus.
