Key specification for this inverter heat pump: 20kw, power source Electric. Everything below is reproduced from the factory data sheet. Made by Dongguan Lehao Energy Saving Technology Co., Ltd. (2 years on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Inverter Heat Pump
- Model Number: HR-24S/BPLN
- Power Source: Electric
- Heating Capacity: 20kw
- Housing Material: Metal
- Refrigerant: R410A
- Refrigerant Type: R410A
Technical Specifications
| Type | Air Source Heat Pump |
|---|---|
| Heating Capacity | 20kw |
| Energy Efficiency Rating | A+++ |
| Application | Commercial, Car, Garage, Hotel, Household, Restaurant, Outdoor |
| Refrigerant | R410A |
| Storage / Tankless | Instant / Tankless |
| Compressor | Scroll Compressor |
| Installation | Freestanding |
| App-Controlled | Yes |
| Housing Material | Metal |
| Feature | Easy Installation, Easy Operation, Eco-Friendly, Energy-Saving, High Efficiency, Safe |
| Power Source | Electric |
| Warranty | 2 Years |
| After-Sales Service Provided | Free Spare Parts |
| Operating Language | English |
| Private Mold | Yes |
| Packaging Types | corrugated box |
| Place Of Origin | Guangdong, China |
| Brand | LOCKHOOT |
| Model Number | HR-24S/BPLN |
| After-Sales Service | provided Free spare parts, Return and Replacement |
| Logo/Pattern | Laser Printing |
| Brand Name | LOCKHOOT |
| Refrigerant Type | R410A |
| Selling Units | Single item |
| Single Package Size | 127X55X167 cm |
| Single Gross Weight | 183.0 kg |
Product Details
Product appearance is subject to change without notice. The actual product received will be as ordered.
R410A Inverter Heat Pump works efficiently with floor heating, water fan coils or radiators for heating/cooling and domestic hot water
OEM/ODM Services Available.
Wide Application
Residential heating/cooling, hot water, house, apartments, villas, etc.
Inverter EVI Technology
Being the smart heat pump elite, perfectly combines eco-friendly R410A refrigerant and inverter EVI technology to produce efficient house heating and 60℃ hot water even under extreme cold climate.
-35℃ Low Temperature Running
According to the characteristics of the cold climate in areas with low temperature such as northern Europe, north America and Canada, the ultra-low temperature air source heat pump with strong and efficient heating capacity under -35℃ is developed. The unit is suitable for the most extreme cold area and truly realizes the stable operation under extreme temperature conditions.
42dB(A) Low Noise
Unique low noise fan motor with external rotor, LOCKHOOT concentrated and constant development to reduce sound levels has resulted in the heat pumps amazingly quiet running at 42dB(A) with good performance.
| Unit Model | HR-24S/BPLN |
| Heating Capacity A (kW) | 24 |
| Heating Capacity B (kW) | 14.1 |
| Nominal Heating Capacity (kW) | 18 |
| Nominal Cooling Capacity (kW) | 19.8 |
| Heating Input Power A (kW) | 7 |
| Heating Input Power B (kW) | 7.1 |
| Nominal Heating Input Power (kW) | 7.4 |
| Nominal Cooling Input Power (kW) | 7.1 |
| Heating Performance Coefficient A | 3.43 |
| Heating Performance Coefficient B | 1.98 |
| Nominal Heating Performance Coefficient | 2.43 |
| Nominal Cooling Performance Coefficient | 2.79 |
| IPLV(H)/IPLV(C) | 3.21/4.14 |
| Capacity Adjustment Range | 15%~120% |
| Power Supply Type | 380V/3N/50Hz |
| Maximum Input Power (kW) | 9.9 |
| Maximum Input Current (A) | 16.9 |
| Power Cable Diameter (mm²) | 3×6+2×4 |
| Air Switch Selection (A) | 32 |
| Compressor Quantity | 1 |
| Compressor Type | Rotary |
| Fan Quantity | 2 |
| Fan Speed (r/min) | 750 |
| Air Outlet Direction | Side Discharge |
| Refrigerant Type | R410A |
| Water Pump Power (kW) | / |
| External Static Pressure (m) | / |
| Unit Water Pressure Drop (kPa) | 50 |
| Noise [dB(A)] | 58 |
| Inlet/Outlet Pipe Diameter | DN32/DN32 |
| Water Flow Rate (m3/h) | 3.4 |
| Main Unit Dimensions (L/W/H) (mm) | 1170/455/1560 |
| Unit Total Mass (kg) | 173 |
| Heating Operating Range (℃) | −35∼43 |
| Cooling Operating Range (℃) | 21∼52 |
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–4 set: US $2260 / set
- 5–9 set: US $2230 / set
- 10+ set: US $2200 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this inverter heat pump?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
