This outdoor condensing unit is published with the manufacturer’s full specification — 220 V, 380 V, refrigerant R22/R404a. For a binding price and lead time, send the volume you need and where it ships to.
Low noise is the constraint that decides whether an outdoor condensing unit can be sited at all in a commercial premises with neighbours, and the U-type box layout is what allows the acoustic treatment without strangling condenser airflow. Bitzer reciprocating compressor covering -20C to 18C on R22 or R404a, with automatic control and gear-driven components at 220V or 380V.
Key Features of This Outdoor Condensing Unit
- Model Number: 4FC-3.2, 4FC-5.2
- Voltage: 220 V, 380 V
- Refrigerant: R22/R404a
- Warranty: 1 Year
- Place Of Origin: Zhejiang, China
- Compressor Type: Reciprocating
Technical Specifications
| Temperature | -20-8c, 8-18c, 18-20c |
|---|---|
| Compressor Brand | Bitzer |
| Compressor Type | Reciprocating |
| Key Selling Points | Automatic, High-Accuracy, Easy To Operate, Competitive Price, High Productivity, Long Service Life, R410A, Accurate Temperature Control |
| Voltage | 220 V, 380 V |
| Warranty | 1 Year |
| Core Components | Pressure Vessel, Gear, Gearbox |
| Video Outgoing-Inspection | Provided |
| Refrigerant | R22/R404a |
| Place Of Origin | Zhejiang, China |
| Weight (KG) | 115 |
| Model Number | 4FC-3.2, 4FC-5.2 |
| Selling Units | Single item |
Products Description
1, Novel and beautiful appearance, integral assembly
2. The spacious space and humanized design inside the unit greatly facilitate installation, commissioning andafter-sales service.
3. The condenser adopts U-shaped double arrangement design, and the fins adopt hydrophilic aluminum foil.which is acid and alkali resistant. High heat exchange efficiency, large energy and low energy consumption.4. The condensing motor adopts low light level external rotor motor, which has large air volume, low noise and
reliable stability.
Product Paramenters
|
MXJB series box type condensingunit with U type condenser |
||||||||
|
Unit model |
MXJB03LBB(Y) |
MXJB04LBB(Y) |
MXJB05LBB(Y) |
MXJB06LBB(Y) |
MXJB09LBB(Y) |
MXJB12LBB(Y) |
MXJB14LBB(Y) |
|
|
U type condenser |
FNU-30 |
FNU-45 |
FNU-45 |
FNU-60 |
FNU-80 |
FNU-100 |
FNU-120 |
|
|
Refrigerant |
R22(R404A/R507A) |
|||||||
|
Power supply |
380V/3P/50HZ |
|||||||
|
Compressor |
Model |
2CES-3 |
4EES-4 |
4DES-5 |
4CES-6 |
4TES-9 |
4PES-12 |
4NES-14 |
|
Qty |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
|
|
condenser |
Fan Qty |
1 |
1 |
1 |
1 |
2 |
2 |
2 |
|
fan voltage(V) |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
|
|
fan power (W) |
190 |
420 |
420 |
550 |
460 |
840 |
840 |
|
|
Evaporating Temperature |
-30ºC~-5ºC |
|||||||
|
Evap.Temp-25ºC |
Cooling capacity(KW) |
3.78 |
4.96 |
5.83 |
7.55 |
9.25 |
11.3 |
12.36 |
|
Power input(KW) |
2.51 |
3.24 |
3.81 |
4.91 |
5.78 |
6.29 |
7.68 |
|
|
Running current(A) |
5.08 |
5.94 |
7.31 |
9.41 |
10.5 |
11.9 |
13.9 |
|
|
Liquid pipe(mm) |
Φ12 |
Φ12 |
Φ12 |
Φ12 |
Φ12 |
Φ16 |
Φ16 |
|
|
Suction pipe(mm) |
Φ22 |
Φ28 |
Φ28 |
Φ28 |
Φ35 |
Φ35 |
Φ35 |
|
