Monoblock Heat Pump, 12kw, EVI, R290

Monoblock heat pump — power supply 220~240/1/50 (V/Ph/Hz), 12KW. The complete factory specification follows. Made by Sichuan Junling Technology Co., Ltd. (8 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Monoblock Heat Pump

• Power Source: Electric
• Power Supply: 220~240/1/50 (V/Ph/Hz)
• Heating Capacity: 12KW
• Refrigerant: R290
• Warranty: 1 Year
• Certification: CCC/CE

Technical Specifications

Product Details

R290 EVI Full DC Inverter Heating & Cooling Monoblock Heat Pump Features:

● R290 refrigerant,low GWP(GWP=3)
● Energy class: A+++
● Stable operation at -25°C
● Outlet water temperature up to 75℃
● Power Detection Function
● SG-READY Function
● 5-Inch TFT True Color Screen
● 5G/2.4G Compatible WIFI Module
● Dual Temperature Zone
● Reserved RS485 Communication Port
● Linkage Control with PV Function

Low GWP Eco Friendly Refrigerant

R290 3 in 1 heat pump helps to reduce carbon emission to protect the environment and help achieve the global goal of carbon neutrality.

Compare to R410A it can reduce 99% CO2 Emissions to get lower Global Warming Potential(GWP).

ERP A+++ Energy Label

EVI techonology

With top energy rating A+++, the unit is energy efficient and can greatly reduce energy bills for users efficiency, stability and quietness

Products Description

EVI Techonology -25℃ Ambient Temperature Stable Running

Can operate efficiently at -25°C, maintain high COP and reliable stability.
summer cooling, winter heating and hot water all seasons.

R290 smart WIFI control

Can operate their air to water heat pump from their smartphones anytime and anywhere.

Can connect with Touching Control Panel

Easy Control your intelligent household electrical appliance through the panel.

Low Noise

multiple noise reduction technologies to make a comfortable enviroment.

Application

R290 DC Inverter Heating & Cooling Heat Pump Meet All demands

Five Function Mode:
● DHW ( Domestic Hot Water)
● Fan coil cooling
● Fan coil cooling+DHW
● Floor heating/radiator heating
● Floor heating/radiator heating/fan coil heating+DHW

Also can be combined with hybrid solar system optional, more than 80% energy saving.

Product Paramenters

R290 12KW DC Inverter Air to water Heat pump
Power Supply	220~240 V / 1 Ph / 50 Hz
Nominal Heating (Max) (A7/6℃,W30/35℃)
Heating capacity	4.30~15.20 KW
Rated Power Input	0.87~3.73 KW
Input Current	4.02~16.38 W/W
Nominal Heating (Max) (A7/6℃,W47/55℃)
Heating capacity	4.25~14.55 KW
Rated Power Input	1.45~4.28 KW
Input Current	6.71~18.80 W/W
Nominal Cooling (Max) (A35/24℃,W12/7℃)
Cooling capacity	3.65~11.04 KW
Rated Power Input	1.12~3.97 KW
Input Current	5.18~17.44 W/W
ERP Level (Outlet water temp. at 35℃)/SCOP	4.85
ERP Level (Outlet water temp. at 55℃)/SCOP	3.84
Rated Input Power	5.40 kW
Rated Input Current	25.0 A
Refrigerant/Weight/GWP	R290 / 0.90KG / 3
CO2 Equivalent	0.0027 t
Operation pressure(Low side)	0.80 Mpa
Operation pressure(High side)	3.00 Mpa
Electrical Shock Proof	I
Rated Water Flow	2.06 m3/h
Rated Water Pressure Drop	20 Kpa
Min/Max water pressure	0.1 Mpa / 0.3  Mpa
Fan Motor Type	LT Motor/ DC Inveter fan motor
Compressor	HIGHLY/ DC Inverter Compressor
Circulation Pump	SHIMGE / DC Inverter Circulation Pump
IP Class	IPX4
Noise Level	50 dB(A)
Max Outlet Water Temperature	75 °C
Water Piping Connections	G1
Operating Ambient	-25~45 °C
Net Dimensions (L*W*H)	1287*448*904 mm
Net Weight	123 KG
Packaged Weight	138 KG
White color / 6-12kw heat pump / pool heater are also supported. Contact us to get more information.

Company Information

FAQ

Q1: Are you also provide kind of heat pump?

A1: Domestic EVI heat pump(9KW-132KW) /SWIM POOL(5KW-150KW) etc…

Q2: Do you have products in stock in your overseas warehouse?

A2: Sure,we have Germany warehouse.Contact us to check if we can send to your country.

Q3: How long is your Heat Pump delivery time?

A3: Generally it is 1-5 working days if the goods are in stock. or it is 15-30 working days if the goods are not in stock, it is according to quantity.

Q4: Will you provide technical promotion support?
A4: Of course, we can provide corresponding pictures and videos to you.

Q5: Do you accept OEM & ODM?

A5:Yes, we are pretty strong on design and manufacturing of clients' brand, the drawings will be sent to our clients for approval before the samples are made.

Ordering and Pricing

• Minimum order quantity: 1 piece
• Volume pricing:
  • 1–9 piece: US $2268 / piece
  • 10–49 piece: US $2000 / piece
  • 50+ piece: US $1868 / piece
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this monoblock heat pump?

The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Which certifications does this monoblock heat pump carry?

It is supplied with CCC/CE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.

Can the monoblock heat pump be supplied for my local voltage?

The standard configuration is 220~240/1/50 (V/Ph/Hz). Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Sichuan Junling Technology Co., Ltd., based in China. The company 8 years as a verified Alibaba.com supplier, Trading Company. Browse the full Sichuan Junling Technology Co., Ltd. range on HVACR Nexus.
