Multi-split Inverter Air Conditioner, 60000btu, 220 -240, 16kW

This multi-split inverter air conditioner is published with the manufacturer’s full specification — power supply 220 -240 /1/50 & 208 -230/1/60, 16kW. Made by Tongxing Air Conditioning Technology Co., Ltd. (11 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Multi-Split Inverter Air Conditioner

• Power Supply: 220 -240 /1/50 & 208 -230/1/60
• Cooling Capacity: 16kW
• Capacity Rang: 2.8kW~16kW
• Refrigerant: R-410A
• Warranty: 3 Years
• Place Of Origin: Guangdong, China

Technical Specifications

Product Details

VRF air conditioner system(outdoor units+indoor units)

outdoor units

which are connected to these indoor units,outdoor capacity choosing depend on the total cooling capacity of all indoor units.

indoor units

wall-mounted type,duct type,cassette type,floor ceiling type……or combination of them

floor ceiling type advantages

Model					GMV-ND160ZD/A-T
Capacity	Cooling	kW	16.0
		Heating	kW	18.0
Power supply			V/Ph/Hz	220-240/1/50 & 208-230/1/60
Power consumption			W	200
Airflow volume(H/M/L)			m3/h	2300/2100/1900
Rated hurrent	Cooling	A	1.9
		Heating	A	1.9
		Water heating	A	/
Sound pressure level(H/M/L)			dB(A)	52/49/45
Connecting pipe diameter	Liquid	mm	∅9.52
		Gas	mm	∅19.05
Drain pipe	External dia.	mm	∅17
		Thickness	mm	1.75
Dimension (WxDxH)	Outline	mm	1700x700x245
		Package	mm	1828x828x345
Net weight/Gross weight			kg	60/68
Loading quantity	40' GP	unit	84
		40' HQ	unit	98

GMV5 indoor choose

indoor units including：duct type；cassette type；

wall mounted type；floor ceiling type；console type；

floor standing type；fresh air ventilation……YOU can choose one kind or combination of them to meet your need.

for example ：the duct type

for example：the cassette type

for example：the wall mounted type

for example：the floor ceiling type

for example：the console type

for example：the floor standing type

for example：the fresh air ventilation type

indoor combination

Customer Photos

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Tongxing Air Conditioning Technology Co.,Ltd.(referred to the Tongxing)is a central air conditioner sales and installation,accessories sales,centeal air conditioning repair ,cleaning services for the integration of science and technology enterprise,for office buildings,shopping malls,hotels,dance halls,stations,hospitals , factores and other central air conditioning system to provide integrated solutions.Company dedicated to the world's most advanced central air-conditioning system service concept to china,and work diligently pursue efforts to build the best central air-conditioning system service brand. Tongxing has been pushing with Gree,Midea,Trane,Mcquay,AUX,Galanz and other well-known brand central air conditioning unit installatin,commissioning and maintenance , maintenance , cleaning services.With these well-known brands have established good relations of cooperation.In recent years,according to market demand with the launch of the extrusion duct Tongxing,phenolic duct,glass fiber and magnesium,fiberglass duct ,etc.,throughout the project in Henan has been used in the majonity of users praise,the company welcomes calls to sample inquiry,discussion ,and looks forward to become your loyal partner.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1–9 set: US $2100 / set
  • 10+ set: US $1600 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this multi-split inverter air conditioner?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.

Can the multi-split inverter air conditioner be supplied for my local voltage?

The standard configuration is 220 -240 /1/50 & 208 -230/1/60. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Tongxing Air Conditioning Technology Co., Ltd., based in China. The company 11 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Tongxing Air Conditioning Technology Co., Ltd. range on HVACR Nexus.
