The pressure shutter bathroom extractor listed here carries 230V, 90 m3/h, documented exactly as the manufacturer publishes it. Made by Foshan Shunde Seicoi Electronic Appliance Manufacture Co., Ltd. (5 years on the platform, typical reply ≤6h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Pressure Shutter Bathroom Extractor
- Model Number: SKAZ04-01D
- Power Source: Electric
- Voltage: 230V
- Air Flow Capacity: 90 m3/h
- Material: Plastic
- Blade Material: ABS Plastic
Technical Specifications
| Voltage | 230V |
|---|---|
| Type | Duct Axial Fan |
| Material | Plastic |
| Blade Material | ABS Plastic |
| Mounting Type | Wall Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 3 Years |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | SEICOI |
| Model Number | SKAZ04-01D |
| Product Name | Bathroom extractor fan |
| Brand | OEM / SEICOI |
| Product Dimensions | 158 W x 120 D x 158 H mm |
| Color | white , black , silver , gold , rose gold |
| Style | Luxurious Design And Energy saving |
| Sound Level @ 3 Metres | 36 dB |
| IP Rate | IP44 |
| Certificate | CE-EMC , CE-LVD, SAA , UKCA ,ROHS, REACH |
| Air Flow Capacity | 90 m3/h |
| Selling Units | Single item |
| Single Package Size | 16.3X13.3X16.8 cm |
| Single Gross Weight | 10.500 kg |
Product Details
Funtion:
Technical Details | ||
Product Dimensions | 158 W x 120 D x 158 H mm | |
Product Weight | 790 g | |
Color | black / white / silver grey | |
Style | Luxuxrious Design | |
Material | tempered glass + ABS plastic | |
Install | Wall Mount or Ceiling Mount | |
Electric Current Type | AC | |
Voltage | 230 Volts | |
Wattage | 10 watts | |
Air Flow Capacity | 100 m3/h | |
Sound Level @ 3 metres | 31 dB | |
IP rate | IP45 | |
Warranty | 3 years | |
Certificate | CE-EMC , CE-LVD, SAA , UKCA ,ROHS, REACH | |
Packing size for outer box (16 pcs) | 549*341*356 mm | |
Weight for outer box | 14.5 kg | |
Packing size for gift box (1 pc ) | 163*133*168mm | |
Ordering and Pricing
- Minimum order quantity: 20 piece
- Volume pricing:
- 20–99 piece: US $17.5 / piece
- 100+ piece: US $13.9 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this pressure shutter bathroom extractor?
The standard minimum order quantity is 20 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this pressure shutter bathroom extractor carry?
It is supplied with CE-EMC , CE-LVD, SAA , UKCA ,ROHS, REACH documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the pressure shutter bathroom extractor be supplied for my local voltage?
The standard configuration is 230V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Shunde Seicoi Electronic Appliance Manufacture Co., Ltd., based in China. The company 5 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Foshan Shunde Seicoi Electronic Appliance Manufacture Co., Ltd. range on HVACR Nexus.
