This side channel blower is published with the manufacturer’s full specification — 220 V, airflow 318(m3/h). Made by Dongguan Mingkai Electromechanical Co., Ltd. (9 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Side Channel Blower
- Model Number: 2MV 710 A11
- Power Source: Electric Blower
- Rated Voltage: 220 V
- Voltage: 220V Air Blower
- AirFlow: 318(m3/h)
- Material: Aluminum Alloy
Technical Specifications
| Application | Air Blower |
|---|---|
| Power Source | Electric Blower |
| Rated Voltage | 220 V |
| Pressure | High Pressure |
| Warranty | 1 years |
| Customized Support | OEM |
| Place Of Origin | Guangdong, China |
| Brand Name | MANVAC |
| Model Number | 2MV 710 A11 |
| Product Name | 2.2kw Turbo blower |
| AirFlow | 318(m3/h) |
| Material | Aluminum Alloy |
| Frequency | 50/60 Hz |
| Voltage | 220V Air Blower |
| Color | Silver |
| Usage | High Pressure Blowing |
| Weight | 38Kg |
| Size | 626*576*526(mm) |
| Selling Units | Single item |
| Single Package Size | 62X57X52 cm |
| Single Gross Weight | 38.0 kg |
Product Details
Factory Supply 3.0hp 2.2KW Air Blower For Industrial Oxygen SupplyFactory Outlet 3HP Side Channel Air Blower For Industrial Oxygen Supply
Technical Paramaters
 | Model No. | 2MV 710 A11 | |
| Phase | 1 | ||
| Stage | Single | ||
| Frequency | 50HZ | 60HZ | |
| power | 2.2KW | 2.55KW | |
| Voltage | 220V-240V | ||
| Current | 12.8A | 12.8A | |
| Max Airflow | 318m3/h | 376m3/h | |
| Max Vacuum | -190mbar | -190mbar | |
| Max pressure | 190mbar | 200mbar | |
| Net weight | 38Kg | ||
| Rotation | 2850RPM | 3450RPM | |
| Sound | 72db | 74db | |
| Level of protection | IP55 | ||
| Insulation class | F | ||
High pressure Blower Functional Features:
1. Light weight high pressure big volume low noise.
2. Aluminum alloy material, greatly reduce weight, achieve the goal of lightweight.
3. Design ( 1 HP motor for I . E. C above ) , full close outer fan type aluminum frame,
motor axis of special design, can be suitable for long time use.
4. Special blade design, high pressure, big air volume, low noise, long service life.
5. Special air damper, air volume control stability is high, easy to operate (CX) TB) HTB applicable.
| Model | Phase | Frequency (Hz) | Power (KW) | Voltage (V) | Max airflow (m3/h) | Max pressure (mbar) | Max vacuum (mbar) | Weight (KG) |
| single-phase blower | ||||||||
| 2MV 210 A11 | 1 | 50 | 0.37 | 220-240 | 80 | 110 | -110 | 19 |
| 60 | 0.45 | 220-240 | 96 | 140 | -130 | |||
| 2MV 230 A11 | 1 | 50 | 0.37 | 220-240 | 100 | 110 | -110 | 19 |
| 60 | 0.45 | 220-240 | 120 | 140 | -130 | |||
| 2MV 310 A01 | 1 | 50 | 0.55 | 220-240 | 100 | 120 | -120 | 21 |
| 60 | 0.62 | 220-240 | 120 | 150 | -130 | |||
| 2MV 310 A11 | 1 | 50 | 0.7 | 220-240 | 100 | 150 | -150 | 22 |
| 60 | 0.8 | 220-240 | 120 | 160 | -150 | |||
| 2MV 320 A31 | 1 | 50 | 1.1 | 220-240 | 120 | 280 | -240 | 25 |
| 60 | 1.3 | 220-240 | 145 | 250 | -230 | |||
| 2MV 410 A11 | 1 | 50 | 0.8 | 220-240 | 145 | 160 | -150 | 23 |
| 60 | 0.9 | 220-240 | 175 | 140 | -160 | |||
| 2MV 410 A21 | 1 | 50 | 1.1 | 220-240 | 145 | 190 | -150 | 24 |
| 60 | 1.3 | 220-240 | 175 | 190 | -180 | |||
| 2MV 420 A11 | 1 | 50 | 1.5 | 220-240 | 150 | 290 | -280 | 34 |
| 60 | 1.75 | 220-240 | 180 | 280 | -250 | |||
| 2MV 430 A11 | 1 | 50 | 0.8 | 220-240 | 180 | 110 | -100 | 24 |
| 60 | 0.9 | 220-240 | 210 | 110 | -100 | |||
| 2MV 430 A21 | 1 | 50 | 1.1 | 220-240 | 180 | 210 | -170 | 25 |
| 60 | 1.3 | 220-240 | 210 | 145 | -145 | |||
| 2MV 510 A11 | 1 | 50 | 1.1 | 220-240 | 210 | 160 | -160 | 29 |
| 60 | 1.3 | 220-240 | 255 | 160 | -150 | |||
| 2MV 510 A21 | 1 | 50 | 1.5 | 220-240 | 210 | 200 | -190 | 32 |
| 60 | 1.75 | 220-240 | 255 | 180 | -180 | |||
| 2MV 530 A21 | 1 | 50 | 1.5 | 220-240 | 270 | 120 | -140 | 34 |
| 60 | 1.75 | 220-240 | 330 | 100 | -110 | |||
| 2MV 610 A11 | 1 | 50 | 2.2 | 220-240 | 270 | 250 | -230 | 38 |
| 60 | 2.55 | 220-240 | 315 | 270 | -250 | |||
| 2MV 710 A11 | 1 | 50 | 2.2 | 220-240 | 318 | 190 | -190 | 38 |
| 60 | 2.55 | 220-240 | 376 | 200 | -190 | |||
We have many other models for you choose, please contact with me if you have any further demands.
Performance curves:
Dimensions:
Accessories :
We also have some parts for your application, if you need, welcome to tell me.
Air filter: Filter the dust particles, apply to a bad environment.
Pressure relief valve: Control gas pressure, prevent excessive pressure, damage the machine.
Silencer: reduce blower noise 5-10db, apply to a quiet environment.
Varies Blower Applications:
1. Printing Machines
2. Burning Machines
3. Plastic Extruders, Laminating, Film Making Machines
4. Uniform Temperature Equipment
5. Household Machines
6. Dust Collectors
7. Textile Machines
8. Pollution Machines
9. Hot Air Blowers
10. Dryers Machines
11. Incinerators
12. Machinery for the Food and Beverage Industries
13. Machinery for Cooling
14. Woodworking Machines
15. Grain Elevators
Certificates:
24 hours service online.
1. What is the warranty of your machine?
R: 1 years, any product itself question,you can contact with us.
2. What is the material of your machine , is oil free?
R: our machine is aluminum alloy, motor is 100% copper coil , of course, we are oil free.
3. How to operate your machine?
R: Connect with wire, and turn on the power, so you can use it directly, about the wiring method, we will tell you how to do according to your voltage, so at first , you need to tell us your voltage and phase,its important.
4. You are trading company or manufacture?
R: We are manufacture, we can provide long-term supply with fast speed.
5. How to contact with you?
R: You can send messages to me directly by alibaba trade manager, or add me like below
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $228 / set
- 10+ set: US $220 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this side channel blower?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 years warranty. Spare parts and technical support remain available after the warranty period.
Can the side channel blower be supplied for my local voltage?
The standard configuration is 220 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Dongguan Mingkai Electromechanical Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Dongguan Mingkai Electromechanical Co., Ltd. range on HVACR Nexus.
