The split air conditioner listed here carries capacity 9000-24000BTU, power type DC, documented exactly as the manufacturer publishes it. Made by Zhengzhou Top Refrigeration Equipment Co., Ltd. (1 year on the platform, typical reply ≤1h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Split Air Conditioner
- Model Number: TopCold-9000
- Power Type: DC
- Power Source: Electric
- Power (W): 1640 W
- Capacity (Btu): 9000-24000BTU
- Maximum Airflow Rate: 850
Technical Specifications
| Type | Split Wall Mounted Air Conditioners |
|---|---|
| Capacity (Btu) | 9000-24000BTU |
| Cooling/Heating | Cooling/Heating |
| Application | Car, Commercial, Garage, Hotel, Household, Office, Outdoor, RV |
| Energy Efficiency Rating | Class A |
| EER | 2-4 |
| Fixed Frequency/Variable Frequency | Variable Frequency |
| Power Type | DC |
| Power Source | Electric |
| Refrigerant | R410A R32 |
| App-Controlled | Yes |
| Feature | Energy-Saving, Voice Control, Wifi, Remote Control, Sleep Mode, Humidity Adjustment, Air Purification Function |
| Remote Control | Yes |
| Power (W) | 1640 W |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Operating Language | English |
| Private Mold | Yes |
| Packaging Types | Corrugated Box |
| Place Of Origin | Henan, China |
| Recommended Room Size（Square Feet） | 129-193 |
| Brand Name | Topcold |
| Cop | 3.62 |
| Maximum Airflow Rate | 850 |
| Model Number | TopCold-9000 |
| Product Name | Wall Split Air Conditioner |
| Function | Inverter, High Efficiency, Energy Saving |
| Keyword | 9000BTU, 12000BTU, 18000BTU,24000BTU Split Air Conditioner |
| Name | Air Conditioners Split System |
| Our Advantage | Smart, WiFi, App Control, Remote Control |
| Selling Units | Single item |
| Single Package Size | 83X36X60 cm |
| Single Gross Weight | 38.5 kg |
Product Details
9000BTU，12000BTU，18000BTU，22000BTU Split Air Conditioners
Household split air conditioners，Air source heat pumps，Portable air conditioners，Integrated air conditioners，Modular air handling units，Dedicated purification air conditioning systems，Constant temperature and humidity air conditioners，Air-cooled heat pump units，Screw chillers，Centrifugal chillers，DC inverter VRF air conditioning systems，High-efficiency air energy water heaters，High-temperature heat pump drying units
MODEL | TopCold-9000 | TopCold-12000 | TopCold-18000 | TopCold-24000 |
Function | Cooling | Cooling | Cooling | Cooling |
Control type | Remote | Remote | Remote | Remote |
Capacity-Cooling/BTU | 8871.2 | 12000 | 17981 | 22000 |
EER(W/W) | 3.52 | 3.5 | 3.48 | 3.46 |
Power Supply | 1Ph-220-240V~50Hz | 1Ph-220-240V~50Hz | 1Ph-220-240V~50Hz | 1Ph-220-240V~50Hz |
Cooling Rated Power Input(W) | 995 | 1600 | 2450 | 2550 |
Moisture Removal(Liters/h) | 0.8 | 1.2 | 1.8 | 2 |
Cooling Capacity Power/W | 2638 | 3517 | 5270 | 6450 |
Rated Current-Cooling/A | 4.9 | 7.6 | 10.9 | 11.3 |
Airflow Volume-Indoor (m3/h) | 480/420/330/270 | 540/500/430/300/ | 850/800/700/570 | 1300/1100/900/750 |
Sound Pressure Level-Indoor(dB(A)) | 40/37/32 /28 | 41/37/34/28/ | 48/43/39/35 | 49/45/41/37 |
Application Area(㎡) | 12-18 | 16-24 | 23-34 | 27-42 |
Indoor unit Dimension(W*D*H)mm | 744×256×185 | 819×256×185 | 970×300×224 | 1122×329×247 |
Indoor unit Packing (W*D*H)mm | 793×330×260 | 868×330×260 | 1080×378×315 | 1193×410×350 |
Indoor unit Net/Gross weight (Kg) | 8/9.5 | 8.5/10 | 13.5/16.5 | 17.5/21 |
Outdoor Unit Dimension-W*H*D/mm | 782×540×320 | 782×540×320 | 899×596×378 | 912×646×373 |
Outdoor Unit Package Dimension-W*H*D/mm | 823×358×595 | 823×358×595 | 948×420×645 | 963×411×695 |
Outdoor unit Net Weight/Gross Weight (kg) | 26/28.5 | 26/28.5 | 39/42 | 42/45 |
Refrigerant | R410A | R410A | R410A | R410A |
Ambient temperature(℃) | 18~48 | 18～48 | 18～48 | 18～52 |
Our products accept various customizations.
Click the button below to contact us and let us know your customization needs
We proudly collaborate with a selection of the world's most renowned brands, such as
LG, Midea, Gree, Mitsubishi, Haier, Hisense, and TCL.
We have a proven track record in handling major HVAC installation and maintenance projects, successfully serving clients both in China and across the globe.
Backed by multiple international certifications for both our manufacturing facility and products, we guarantee customized airconditioners that fully comply with the regulations and standards of your country.
Trusted by Distributors. Direct-from-Factory Prices. Superior Quality. Get Your Custom Quote Now!
Product packaging
Our air conditioners are highly praised by distributors worldwide. As a leading OEM manufacturer, we offer genuine
direct-from-factory pricing without compromising on quality. Contact us today to get your competitive quote.
FAQ
1. What products do you offer?
We specialize in a complete range of high-quality refrigeration and air conditioning equipment. Our main product categories
include:
Residential & Commercial AC:Household Split ACs, Portable ACs, DC Inverter VRF Systems.
Heating & Heat Pumps:Air Source Heat Pumps, High-Efficiency Air Energy Water Heaters, High-Temperature Heat Pump Drying Units.
We specialize in a complete range of high-quality refrigeration and air conditioning equipment. Our main product categories
include:
Residential & Commercial AC:Household Split ACs, Portable ACs, DC Inverter VRF Systems.
Heating & Heat Pumps:Air Source Heat Pumps, High-Efficiency Air Energy Water Heaters, High-Temperature Heat Pump Drying Units.
Industrial & Precision AC:Modular Air Handling Units, Dedicated Purification Systems, Constant Temperature and Humidity ACs.
Large Chiller Units:Air-Cooled Heat Pump Units, Screw Chillers, Centrifugal Chillers.
Home Appliances:Refrigerators, Washing Machines, and Electrical Spare Parts.
With over 50 product series, we deliver tailored solutions for diverse applications.
2. Why should you choose us over other suppliers?
Choosing Zhengzhou Top Refrigeration means benefiting from three key advantages:
Expertise & Quality:We bring together a strong R&D and management team, utilizing state-of-the-art equipment and expert
craftsmanship to ensure superior product reliability.
Comprehensive Product Range:Our extensive portfolio allows us to provide the perfect solution for your specific needs, from
standard to specialized applications.
Robust Support Network:Backed by a widespread sales and service network across China, we are committed to delivering efficient, reliable, and comprehensive support.
3. What are your after-sales service and support policies?
We are dedicated to providing full support throughout our product's lifecycle:
Warranty:All products come with a standard one-year warranty.
Continued Technical Support:We provide ongoing technical assistance even after the warranty period has expired.
24/7 Online Support:Our team is available online 24 hours a day to address your inquiries and provide timely technical help.
4. What are your accepted payment terms and delivery options?
We offer flexible transaction methods for our global clients' ease of business.
Accepted Delivery Terms:FOB, CIF, EXW, CIP, DDP, DDU, Express Delivery.
Accepted Payment Currencies:USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF.
Accepted Payment Types:T/T, L/C, D/P, D/A, Credit Card, PayPal, Western Union, Cash.
5. What languages are spoken by your team?
To ensure smooth communication, our team can assist you in multiple languages,
2. Why should you choose us over other suppliers?
Choosing Zhengzhou Top Refrigeration means benefiting from three key advantages:
Expertise & Quality:We bring together a strong R&D and management team, utilizing state-of-the-art equipment and expert
craftsmanship to ensure superior product reliability.
Comprehensive Product Range:Our extensive portfolio allows us to provide the perfect solution for your specific needs, from
standard to specialized applications.
Robust Support Network:Backed by a widespread sales and service network across China, we are committed to delivering efficient, reliable, and comprehensive support.
3. What are your after-sales service and support policies?
We are dedicated to providing full support throughout our product's lifecycle:
Warranty:All products come with a standard one-year warranty.
Continued Technical Support:We provide ongoing technical assistance even after the warranty period has expired.
24/7 Online Support:Our team is available online 24 hours a day to address your inquiries and provide timely technical help.
4. What are your accepted payment terms and delivery options?
We offer flexible transaction methods for our global clients' ease of business.
Accepted Delivery Terms:FOB, CIF, EXW, CIP, DDP, DDU, Express Delivery.
Accepted Payment Currencies:USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF.
Accepted Payment Types:T/T, L/C, D/P, D/A, Credit Card, PayPal, Western Union, Cash.
5. What languages are spoken by your team?
To ensure smooth communication, our team can assist you in multiple languages,
Including:English, Chinese, Spanish, Japanese, Portuguese, German, Arabic, Russian, Korean, Hindi, and Italian.
Ordering and Pricing
- Minimum order quantity: 2 set
- Volume pricing:
- 2–99 set: US $218 / set
- 100–999 set: US $198 / set
- 1000+ set: US $178 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this split air conditioner?
The standard minimum order quantity is 2 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Zhengzhou Top Refrigeration Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Zhengzhou Top Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
