Key specification for this square axial exhaust fan: 230 V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Dezhou Spruce Hvac Equipment Co., Ltd. (1 year on the platform, typical reply ≤1h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Square Axial Exhaust Fan
- Power Source: Electric
- Voltage: 230 V
- Material: Carbon Steel
- Blade Material: Carbon Steel
- Speed: 1450RPM
- Warranty: 1 Year
Technical Specifications
| Voltage | 230 V |
|---|---|
| Speed | 1450RPM |
| Type | Wall Mounted Axial Fan |
| Material | Carbon Steel |
| Blade Material | Carbon Steel |
| Bearing Type | Oil Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Place Of Origin | Shandong, China |
| Brand Name | yunshan |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Steel fiberglass wall mounted axial flow fans have the advantages of light weight, low noise, smooth operation, high efficiency, and corrosion resistance. It can be used for ventilation and air exchange in industries such as machinery, chemical, printing and dyeing, electroplating, papermaking, food, medicine, as well as in theaters, hotels, offices, and various residential buildings. The fan impeller is developed using a design method of low speed and high pressure coefficient. It has a large chord length, spatial distortion, and inclined wide blades, which enable it to achieve the required air volume and pressure under low-speed driving. It has obvious advantages such as high efficiency, low noise, small vibration, and smooth operation. The impeller is made of fiberglass material or aluminum alloy and can also be equipped with explosion-proof motors. It can be used to transport flammable and explosive gases. Wall mounted axial flow fan is widely used for wall exhaust in industrial and mining enterprises, civil buildings and other occasions, and has the following characteristics: A: Easy installation, beautiful appearance, and overall square shape. When designing the building, square holes are reserved on the wall according to different models. The fan enters the wall hole from the outside of the wall, and rubber or cork is inserted between the fan shell and the wall. Then, a fixing bracket is used from the inside of the wall to fix the fan to the wall. B: Rainproof and natural wind backflow prevention function: The fan outlet is equipped with a louvered air door on the outer wall side. When the fan is stopped, the air door automatically closes to prevent indoor backflow. When the fan is turned on, the airflow automatically blows open the air door. C: Smooth operation and low noise: The fan inlet is equipped with a flow divider, which not only ensures stable airflow but also serves as a safety net. The square overall installation is firm, with minimal vibration, smooth operation, and low noise.
Brand name | yunshan |
product name | Smoke Exhaust Fan |
Details Images
Application Scenarios
The axial fan suits in ventilation,deliver or exhaust in all kinds of civil and industry architectures. The anticorrosion axial fan is suitable in chemical plant,laboratory,basement,bathing pool and so on,to convey caustic,acid or alkali and high-moisture gas. explosion-proof axial fan is suitable in boiler (oil or gas as fuel),highly concentrated dust workshop,fuel depot,gas storage stands,high explosive cargo warehouse and so on,this situation has the explosion-proof request.
Company Profile
Dezhou SPRUCE HVAC Products Co., Ltd.
Dezhou SPRUCE HVAC Products Co., Ltd., located in Dezhou City, Shandong Province, China's northern industrial base of refrigeration and air conditioning, is a comprehensive company integrating design, production and sales of HVAC products. The company was founded in 2011, covers an area of 100,000 square meters, manufacturing workshop of 60,000 square meters, with more than 400 employees, we are equipped with confidential CNC machine tools and automated production lines, the company mainly produces fire and smoke prevention and exhaust systems, fresh air conditioning systems, industrial dust removal, air purification system related products. This includes a wide range of HVAC products from air handling units, chillers and heat pumps, centrifugal and axial fans, ductwork systems and air distribution systems. SPRUCE HVAC is a leading manufacturer of high-quality HVAC equipment, specializing in energy-efficient heating, ventilation and air conditioning solutions. With years of industry expertise, we are committed to providing reliable, innovative, and customized HVAC systems for chemical, aquaculture, commercial, industrial, and residential applications.
Product Packaging
Certifications
Customer Photos
FAQ
Q 1.What's the payment term?
A. We accept T/T,LC,Western Union,Paypal.
Q 2.What is the delivery time?
A. It depends on order quantity,usually it will take about 3-5 days for sample production.
Q 3.What's the package used for?
A. For the small capacity,will use carton,but for big capacity,we should use honeycomb carton and pallet or wooden case for
protection.
Q 4.Would you accept to use our logo?
A.It's no problem,we accept OEM service.
Q 5. What kind of certificates you have?
A. Our company has ISO9001,CE, RoHS,SGS etc.
A. We accept T/T,LC,Western Union,Paypal.
Q 2.What is the delivery time?
A. It depends on order quantity,usually it will take about 3-5 days for sample production.
Q 3.What's the package used for?
A. For the small capacity,will use carton,but for big capacity,we should use honeycomb carton and pallet or wooden case for
protection.
Q 4.Would you accept to use our logo?
A.It's no problem,we accept OEM service.
Q 5. What kind of certificates you have?
A. Our company has ISO9001,CE, RoHS,SGS etc.
Ordering and Pricing
- Minimum order quantity: 1 set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this square axial exhaust fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the square axial exhaust fan be supplied for my local voltage?
The standard configuration is 230 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Dezhou Spruce Hvac Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Dezhou Spruce Hvac Equipment Co., Ltd. range on HVACR Nexus.
