Temperature humidity rooftop unit — heating capacity 9-200, refrigerant R22/R410a. The complete factory specification follows. Made by Ningbo Longwell Electric Technology Co., Ltd. (8 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Temperature Humidity Rooftop Unit
- Operating Voltage: AC380 3N~50Hz
- Refrigerating Capacity(KW): 12.6-200
- Heating Capacity (Electric Heating/KW): 9-200
- Refrigerant: R22/R410a
- Warranty: More Than 5 Years
- Place Of Origin: Zhejiang, China
Technical Specifications
| Type | Precision Constant Temperature and Humidity Unit |
|---|---|
| Mounting Type | Wall / Window Mount |
| Compressor Brand | Performer, Sanyo, Fusheng, Copeland, Daikin, Hitachi, Bristol |
| Fan Motors Type | Brushless |
| Key Selling Points | With frequency conversion speed regulation function |
| Warranty | More Than 5 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Pressure Vessel, Motor, Other, Bearing, Gear, PLC, Engine, Gearbox, Frequency, High heat transfer efficiency, Good heat dissipation, The compressor has strong liquid carrying capacity, High oil return capacity |
| Place Of Origin | Zhejiang, China |
| Weight (Kg) | 270 |
| Brand Name | LongWell |
| Dimension(L*W*H) | customizable |
| Product Name | Precision Constant Temperature and Humidity Unit |
| Operating Voltage | AC380 3N~50Hz |
| Function | Cooling+Heating |
| Refrigerant | R22/R410a |
| Refrigerating Capacity(KW) | 12.6-200 |
| Heating Capacity (Electric Heating/KW) | 9-200 |
| Air Volume(M³/H) | 2800-370000m³/h |
| Application | factory, hotel, hospital, building, malls, residential communities, |
| Humidity Range /Sensitivity(%) | Humidity control range: 45~70, sensitivity ±4 |
| Temperature Range/Sensitivity(℃) | Temperature control range: 18~25, sensitivity ±0.8 |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Products Description
Product Name | Rooftop Air Conditioing Unit | ||||||
Operating Voltage | 220-240V/50Hz | ||||||
Dimension(L*W*H) | Rooftop Air Conditioing Unit(Customizable) | ||||||
Core Components | Pressure vessel/ Motor/PLC/Pump | ||||||
Cooling capacity | 21.9kw-570kw | ||||||
Heating capacity | 27.5KW-200kw | ||||||
Keyword | Rooftop Air Conditioing Unit | ||||||
Refrigerant | R410a/R22/R32/R290 | ||||||
Power Supply | 380v/3N/50HZ | ||||||
Heating method | heat pump heating / Electric heating /gas heating /Electric heating / hot water heating | ||||||
Humidification method | electrode humidification / dry steam humidification / Electric humidification /High pressure micro mist humidification / Wet film humidification | ||||||
Horizontal return air, horizontal air supply | side return air, end air supply; end return air, end air supply | ||||||
Other air supply and return modes | side return air, bottom air supply; bottom return air, end air supply | ||||||
Application | Restaurant/Hotels/sports arenas/exhibition centers/malls/machinerysteam heating | ||||||
hot and cold source | Comes with hot and cold source | ||||||
Model, speed, power and equipped motor | According to your requirements or help you recommend | ||||||
Technical analysis | ||||||||
Integrated design, easy to install and maintain, suitable for installation directly on the roof of a building or on the groundIntegrated design, easy to install and maintain, suitable for installation directly on the roof of a building or on the ground | ||||||||
Key technical components:High-efficiency compressor system, advanced air filtration system | ||||||||
Performance data report | ||||||||
Energy efficiency ratio(cop):2.8-3.45 | ||||||||
cooling capacity:20kw-200kw Heating capacity:27.5KW-200kw | ||||||||
Electrical appliance requirements: 380v-415v/50Hz/60Hz | ||||||||
Market positioning analysis | ||||||||
Target customer group: tailor-made customers for process refrigeration needs of commercial buildings such as shopping malls,office buildings, and production plants, cooling needs of power distribution rooms, mobile space cooling, etc. | ||||||||
Main application scenarios: Suitable for rapid cooling and heating needs of large spaces | ||||||||
Remarks:
1. Cooling condition: Outdoor ambient temperature: 35°c, indoor dry/wet bulb temperature: 26.7/19.4°C;
2. Heating condition: Outdoor dry/wet bulb temperature: 7/6°c; indoor dry/wet bulb temperature: 20/15°c.
3. Noise level: Measured in a semi-anechoic chamber, with measurement points located 1 meter in front ofthe equipment and abovethe floor (at a height of 1 meter+ equipment height)/2: 4. The above information may be subject to change due to product updates or other reasons.
Company Profile
If you need a clear version, please contact customer service to obtain it.
Customer feedback
Delivery and Packaging
Related Products
Top 10 reasons why customers choose LONGWELL:
1.LONGWELL is a professional manufacturer which is the specialist in HVACR fans, motor and components for the applications of air conditioner, air ex-changer, coolers, heaters, floor convectors, sterilization purifier, air purifiers, medical purifiers, and ventilation ,energy industry, 5G cabinet…
2.We have many authoritative international certifications .
3.Have professional sales team more than 200 person, Set up sites in many countries around the world，to help you solve the problem any time !
4.LONGWELL Promise will never release unqualified products !
5.Rich experience in different fields and word's most comprehensive fan soluions
6.Quality is life ! with strict quality control system,supervise the whole process from raw materials, production, quality inspection, packaging and delivery!
7.Born for High-Quality Breathing, LONGWELL Fans Power Your Equipment
8.LONGWELL have own delivery department, make sure fast delivery and regular feedback of production progress !
9.Professional after-sales team provides 24-hour online service !
10. we makes very quiet noise , and good air performances of fans !
3.Have professional sales team more than 200 person, Set up sites in many countries around the world，to help you solve the problem any time !
4.LONGWELL Promise will never release unqualified products !
5.Rich experience in different fields and word's most comprehensive fan soluions
6.Quality is life ! with strict quality control system,supervise the whole process from raw materials, production, quality inspection, packaging and delivery!
7.Born for High-Quality Breathing, LONGWELL Fans Power Your Equipment
8.LONGWELL have own delivery department, make sure fast delivery and regular feedback of production progress !
9.Professional after-sales team provides 24-hour online service !
10. we makes very quiet noise , and good air performances of fans !
Contact Us
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–1 piece: US $1299 / piece
- 2–9 piece: US $1199 / piece
- 10–19 piece: US $1099 / piece
- 20+ piece: US $999 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this temperature humidity rooftop unit?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a More Than 5 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the temperature humidity rooftop unit be supplied for my local voltage?
The standard configuration is AC380 3N~50Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
