Thawing equipment — material Stainless Steel, type Meat Processing Machinery. The complete factory specification follows. Made by Shandong Zeko Machinery Co., Ltd. (6 years on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Thawing Equipment
- Raw Material: Duck Chicken Meat Fish
- Material: Stainless Steel
- Speed: High efficiency
- Warranty: 1 Year
- Place Of Origin: Shandong, China
- Application Fields: Vegetable Processing Plant, Meat Processing Plants, Commercial Catering, Snack Food Factory, Frozen Food Factory
Technical Specifications
| Application Fields | Vegetable Processing Plant, Meat Processing Plants, Commercial Catering, Snack Food Factory, Frozen Food Factory |
|---|---|
| Type | Meat Processing Machinery |
| Core Components | PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Warranty | 1 Year |
| Weight (Kg) | 100 |
| Place Of Origin | Shandong, China |
| Brand Name | zeko |
| Product Name | meat vacuum tumbler machine |
| Feature | Fully Automatic Efficient Energy Saving |
| Application Scope | Food Industy |
| Raw Material | Duck Chicken Meat Fish |
| Speed | High efficiency |
| Function | Multifunction |
| Usage | Food Processing Equipment |
| Material | Stainless Steel |
| Packing | Wooden Case |
| Advantage | Easy Operation High Efficiency |
| Selling Units | Single item |
| Single Package Size | 60X54X54 cm |
| Single Gross Weight | 56.0 kg |
Product Details
Equipment introduction
The vacuum roller kneading machine is made of high quality stainless steel, with large rolling space, reasonable design and low noise. Blade circular arc, unique design, so that the pigment quickly flavor, fully pickled, will not cause damage to the surface of the product, improve product tenderness, improve product quality. Electrical waterproof control.
Main Technical Specification
The eylinder volume | 50L | 150L | 300L | 500L | 600L | 800L | 1000L | 1200L | 1500L |
Loading Volume(Kg) | 30 | 112 | 225 | 375 | 450 | 600 | 750 | 900 | 1050 |
Vacuum(Mpa) | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 | 0.04-0.08 |
Drum speed(r/min) | 3.5 | 5.5 | 7.5 | 7 | 7 | 6.5 | 6 | 4 | 4 |
Total Power(Kw) | 1.21 | 1.75 | 2.25 | 2.95 | 2.95 | 3.75 | 4.75 | 5.1 | 5.1 |
Overall dimenaion (L*W*H)mm | 840*500*930 | 1200*900*1300 | 1420*920*1450 | 1780*1020*1550 | 1980*1020*1550 | 2000*1230*1800 | 2140*1330*1900 | 2350*1330*1990 | 2400*1440*2100 |
The total weight(Kg) | 100 | 280 | 440 | 500 | 530 | 600 | 630 | 800 | 980 |
Product Advantages
Circular head design
The rolling space is large, the design is reasonable, the running noise is small, the sealing is good, the vacuum rolling effect
is good
is good
According to product process requirements, set rolling kneading time, intermittent time, full rolling kneading, fast flavor
Different rolling strength, suitable for different products, to ensure a soft and uniform rolling strength
The equipment is made of stainless steel, with high strength, good corrosion resistance and long service life
Product Application
A variety of models are available
Refrigeration rolling machine
Vacuum refrigeration rolling kneading machine is in the vacuum state, the use of physical impact principle, so that the meat in the roller roll up and down, impact, is the material evenly absorb the curing liquid, improve the elasticity of meat. The machine is made of high quality stainless steel with reasonable structure. The pressure sealing cap structure is adopted at both ends of the drum to increase the space of the drum, the rolling effect is uniform, the machine has low noise and stable performance
Hydraulic vacuum rolling machine
Hydraulic roll kneading machine has greater loading capacity and more convenient discharge performance. Variable frequency
stepless speed regulation, speed range 3-12RPM, smooth start, reduce the impact of machine pneumatic, extend the service life of
the equipment. Specially equipped with auxiliary vacuum pipews, PLC and touch screen control can divide the total working time into up to six process cycles, each process cycle is divided into two steps, each step is separately set time, speed vacuum state, steering. Meet the processing requirements of diverse products.
stepless speed regulation, speed range 3-12RPM, smooth start, reduce the impact of machine pneumatic, extend the service life of
the equipment. Specially equipped with auxiliary vacuum pipews, PLC and touch screen control can divide the total working time into up to six process cycles, each process cycle is divided into two steps, each step is separately set time, speed vacuum state, steering. Meet the processing requirements of diverse products.
Refrigeration vacuum rolling machine
Vacuum refrigeration rolling kneading machine is in the vacuum state, the use of physical impact principle, so that the meat in
the roller roll up and down, impact, is the material evenly absorb the curing liquid, improve the elasticity of meat. The machine
is made of high quality stainless steel with reasonable structure. The pressure sealing cap structure is adopted at both ends of
the drum to increase the space of the drum, the rolling effect is uniform, the machine has low noise and stable performance
the roller roll up and down, impact, is the material evenly absorb the curing liquid, improve the elasticity of meat. The machine
is made of high quality stainless steel with reasonable structure. The pressure sealing cap structure is adopted at both ends of
the drum to increase the space of the drum, the rolling effect is uniform, the machine has low noise and stable performance
Title goes here.
Vacuum roller kneading machine is in the vacuum state, the use of physical impact principle, so that the meat in the roller roll
up and down, impact, is the material evenly absorb the curing liquid, improve the elasticity of meat. The machine is made of high
quality stainless steel with reasonable structure. The pressure sealing cap structure is adopted at both ends of the drum to
increase the space of the drum, the rolling effect is uniform, the machine has low noise and stable performance
up and down, impact, is the material evenly absorb the curing liquid, improve the elasticity of meat. The machine is made of high
quality stainless steel with reasonable structure. The pressure sealing cap structure is adopted at both ends of the drum to
increase the space of the drum, the rolling effect is uniform, the machine has low noise and stable performance
Company Profile
Shandong Zeko Machinery Co., Ltd. is a global supplier of meat processing machine and fruit and vegetable equipment. The company focuses on the research and development,manufacturing and sales of meat bowl chopper, air bubble washing machine, vacuum packaging machine, frozen meat grinder, meat stuffing mixing machine, sausage machine, fruit and vegetable washing machine,vacuum meat tumbler machine, meat ball machine and so on, the company also provides customers with a full set of solutions.
Certificate
Our clients
After-sales service
1.One year warranty
The company has a one-year warranty and lifetime service system for its products.
2.About the equipment
If the device fails or encounters difficulties during use, read the product manual as reference.
3.About service
If the device fails and cannot resolve itself, please contact us in time and we will provide you with remote video guidance and
professional technical support.
The company has a one-year warranty and lifetime service system for its products.
2.About the equipment
If the device fails or encounters difficulties during use, read the product manual as reference.
3.About service
If the device fails and cannot resolve itself, please contact us in time and we will provide you with remote video guidance and
professional technical support.
Packing&Delivery
FAQ
Q:Are you a trading company or a factory？
A:We are a factory with more than 10 years of experience in food machinery technology.
Q:How do you guarantee the quality of the machine？
A: We have export experience for 6 years and customers who bought our machine have tested the machine before it was shipped .
Q:Can the voltage of the machine be adapted ?
A:We can adapt the machine to your needs to match your local voltage.
Q:Can you ship the machine to my address?
A:Yes, we support shipping and air transportation, as well as door-to-door service.
Q:Can I go to China and visit your factory?
A:Sure, we are in Shandong, China, welcome to our factory.
Q:Do you have operation manual with the machine?
A:Yes, of course, it is in English version.
Q:Can you offer us the necessary paper to do the customs clearance?
A: Yes, we will send you the contract, packing list and bill of lading, and we will also meet your other requirements.
Q:How about the packing?
A:Outside Package: Wooden packing case as export standard ; Inside Package: Stretch film
Q: What is the warranty period for the equipment?
A:One year upon you receive the goods.
A:We are a factory with more than 10 years of experience in food machinery technology.
Q:How do you guarantee the quality of the machine？
A: We have export experience for 6 years and customers who bought our machine have tested the machine before it was shipped .
Q:Can the voltage of the machine be adapted ?
A:We can adapt the machine to your needs to match your local voltage.
Q:Can you ship the machine to my address?
A:Yes, we support shipping and air transportation, as well as door-to-door service.
Q:Can I go to China and visit your factory?
A:Sure, we are in Shandong, China, welcome to our factory.
Q:Do you have operation manual with the machine?
A:Yes, of course, it is in English version.
Q:Can you offer us the necessary paper to do the customs clearance?
A: Yes, we will send you the contract, packing list and bill of lading, and we will also meet your other requirements.
Q:How about the packing?
A:Outside Package: Wooden packing case as export standard ; Inside Package: Stretch film
Q: What is the warranty period for the equipment?
A:One year upon you receive the goods.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $3793 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this thawing equipment?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
